STRAIGHT JAW SPIDER COUPLINGS 08 21 Quality Products for Mechanical & Fluid Power
Advantages of the Lovejoy Grid Coupling » High tensile, shot-peened alloy steel grid springs and precision machined hubs ensure superior coupling performance and long life. » Lovejoy’s grid couplings with tapered grids are designed to be interchangeable with other industry standard grid couplings with both horizontal and vertical grid covers. » Lovejoy grid couplings are designed for ease of installation and maintenance reducing labour and downtime costs. » The torsional flexibility and resilience of Lovejoy grid couplings helps reduce vibration and cushions shock and impact loads. » Cover fasteners can be provided in either Inch or Metric sizes. » Excellent for use in applications where the equipment is close coupled or spaced apart requiring a spacer style coupling arrangement. » Stock spacer designs are available or requests for custom spacer lengths can be addressed by jbj Techniques Limited. #DriveLineHarmony www.jbj.co.uk/spider-couplings.html
Page Overview ...................................................................... 4 Elastomers overview ............................................................... 5 Selection process ................................................................. 6 Selection calculation ............................................................... 7 Application service factors ............................................................ 8 Performance data ................................................................. 9 L series ....................................................................... 10 - 12 LC series ...................................................................... 13 - 14 AL and SS series ................................................................. 15 AL series ...................................................................... 16 RRS and RRSC series .............................................................. 17 RRS series ..................................................................... 18 C series ....................................................................... 19 H series ....................................................................... 20 RRC series ..................................................................... 21 Performance data ................................................................. 22 Dimensions of spiders .............................................................. 23 Mechanical Power Transmission Straight Jaw Spider Couplings Contents #DriveLineHarmony www.jbj.co.uk/spider-couplings.html The details contained within this catalogue are reproduced in accordance with the latest information at publication of this catalogue. Errors & Omissions Excepted Last update: 06/08/2021
#DriveLineHarmony www.jbj.co.uk/spider-couplings.html jbj Techniques are the UK distributor of R & L Hydraulics power transmission products. Mechanical Power Transmission Couplings UK Distributor 2
www.jbj.co.uk/spider-couplings.html 3 Mechanical Power Transmission Couplings Safety Warning SafetyWarning. When using any of these products, you must follow these instructions and take the following precautions. Failure to do so may cause the power transmission product to break and parts to be thrown with sufficient force to cause severe injury or death. Refer to this catalogue for proper selection, sizing, kW, torque range, and speed range of power transmission products, including elastomeric elements for couplings. Follow the installation instructions included with the product, and in the individual product catalogues for proper installation of power transmission products. Do not exceed catalogue ratings. During start up and operation of power transmission product, avoid sudden shock loads. Coupling assembly should operate quietly and smoothly. If coupling assembly vibrates or makes a knocking sound, shut down immediately, and recheck alignment. Shortly after initial operation and periodically thereafter, where applicable, inspect coupling assembly for: alignment, wear of elastomeric element, bolt torques, and flexing elements for signs of fatigue. Do not operate coupling assembly if alignment is improper, or where applicable, if elastomeric element is damaged, or worn to less than 75%of its original thickness. For all power transmission products, you must install suitable safety guards. Do not start power transmission product before suitable guards are in place. Failure to properly guard these products may result in severe injury or death from personnel contacting moving parts or from parts being thrown from assembly in the event the power transmission product fails. Do not use any of these power transmission products for elevators, personnel lifts, or other devices that carry people. If the power transmission product fails, the lift device could fall resulting in severe injury or death. If you have any questions please contact the jbj Techniques technical office telephone: +44 (0)1737 767493 email: info@jbj.co.uk
Jaw Type Couplings The Jaw Type couplings from Lovejoy are offered in the industry’s largest variety of stock bore/keyway combinations. These couplings require no lubrication and provide highly reliable service for light, medium, and heavy duty electrical motor and internal combustion power transmission applications. Features ■ Fail-safe – will still perform if elastomer fails ■ No metal to metal contact ■ Resistant to oil, dirt, sand, moisture and grease ■ More than 850,000 combinations of bore sizes ■ Most types available from stock in 24 hours Applications include power transmission to industrial equipment such as pumps, gear boxes, compressors, blowers, mixers, and conveyors. Lovejoy’s Jaw Type couplings are available in 24 sizes from a minimum torque rating of 3.5 in–lbs to a maximum torque rating of 170,004 in–lbs and a bore range of .125 inches to 7 inches. Lovejoy’s standard bore program covers AGMA, SAE, and DIN bore/ keyway and spline bore combinations. The Lovejoy Jaw Type coupling is available in a variety of metal hub and insert materials. Hubs are offered in sintered metal, aluminum, bronze, steel, stainless steel, and ductile iron. L Type ■ Coupling offers standard shaft-to-shaft connection for general industrial duty applications ■ Standard L Type coupling hub materials are either sintered iron (L035-L190) or cast iron (L225-L276) LC Type ■ Uses the standard L Type hubs with a snap wrap spider and retaining ring ■ Suited for applications over 1,750 RPM AL Type ■ Aluminum hubs offer light weight with low overhung load and low inertia ■ Excellent resistance to atmospheric conditions, perfect for corrosive environment applications SS Type ■ The SS Type coupling provides maximum protection against harsh environmental conditions ■ Sizes SS075-SS150 available from stock, other sizes available on request RRS Type ■ Center “drop out” section of this coupling provides proper shaft separation, while also allowing easy elastomer installation without disturbing the hubs or requiring the realignment of shafts ■ Accommodates American and European industry standard pump/motor shaft separations ■ The spacer is made of glass reinforced plastic, cast iron, or aluminum SW Type ■ Standard L Type coupling with a snap wrap elastomer with retaining ring ■ Well suited for standard shaft to shaft connection in general industrial purpose applications under 1,750 RPM C & H Types ■ Couplings provide standard shaft-to-shaft connection for medium (C) and Heavy (H) duty range applications ■ Standard C coupling hub is made of cast iron, while the H is constructed of ductile iron L Type AL Type Jaw SW Type RRS Type LC Type SS Type C & H Types 4 #DriveLineHarmony www.jbj.co.uk/spider-couplings.html Straight Jaw Spider Couplings Overview
Elastomers In Compression Lovejoy offers four types of elastomer designs to allow for additional flexibility in addressing specific application requirements. One piece designs are used in the “L” and “AL” models (referred to as spiders) and multiple part “load cushions” are used in the “C” and “H” model couplings. The load cushions are in sets of 6 to 14 pieces depending on coupling size. Solid Center Spider ■ The solid center design is commonly used design when shafts of the driver and driven equipment can be kept separate by a standard gap Open Center Spider ■ The open center design allows for the shafts of the driver and driven to be positioned within a short distance ■ Open center spiders offer shaft positioning flexibility but have a lower RPM capacity (1,750 RPM maximum for NBR, 3,600 maximum for Urethane/Hytrel ®) Cushions ■ Used exclusively for the C and H Type couplings ■ Load cushions are held in place radially by a steel collar which is attached to one of the hubs Snap Wrap Flexible Spider ■ Design allows for easy removal of the spider without moving the hubs ■ Allows for close shaft separation all the way up to the hubs maximum bore ■ Maximum RPM is 1,750 RPM with the retaining ring, but if used with the LC Type (with collar) the normal RPM rating of the coupling applies ■ Style is available in NBR and Urethane only, and in limited sizes Note: Complete technical data for the new Jaw In-Shear elastomer is contained in the next section of this catalog, labeled “JIS” on the page tabs. Spider Materials SOX (NBR) Rubber ■ The standard material that is highly flexible material that is oil resistant ■ Resembles natural rubber in resilience and elasticity, and operates effectively in temperature ranges of -40° to 212° F (-40° to 100° C) Urethane ■ Has 1.5 times greater torque capacity than NBR ■ Good resistance to oil and chemicals ■ Material provides less dampening effect and operates at a temperature range of -30° to 160° F Hytrel ■ Flexible elastomer designed for high torque and high temperature operations ■ Operates in temperatures of -60° to 250° F (-51° to 121° C) Bronze ■ Rigid, porous, oil-impregnated metal insert exclusively for low speed (max 250 RPM) applications requiring high torque capabilities ■ Not affected by water, oil, dirt, or extreme temperatures – operates in temperatures of -40° to 450° F (-40° to 232° C) 5 #DriveLineHarmony www.jbj.co.uk/spider-couplings.html Straight Jaw Spider Couplings Elastomer Overview
Jaw Type Coupling Selection Process The selection process for determining the proper jaw coupling size and elastomer requires using the charts shown on the following pages. There are three components to be selected, two hubs and one elastomer. When the shaft size of the driver and driven of the application are of the same diameter, the hubs selected will be the same. When shaft diameters differ, hubs selected will differ accordingly. Information necessary before a coupling can be selected: ■ HP (or KW) and RPM or Torque of driver ■ Shaft sizes of driver and driven equipment and corresponding keyways ■ Application description ■ Environmental conditions (i.e. extreme temperature, corrosive conditions, space limitations) Steps In Selecting A Jaw Coupling Step 1: Determine the Nominal Torque of your application by using the following formula: Nominal Torque = in-lb = (HP x 63025) RPM Nm = (KW x 9550) RPM Step 2: Using the Application Service Factors Chart 1 (page 8) select the service factor which best corresponds to your application. Step 3: Calculate the Design Torque of your application by multiplying the Nominal Torque calculated in Step 1 by the Application Service Factor determined in Step 2. Design Torque = Nominal Torque x Application Service Factor Step 4: Using the Spider Performance Data Chart 2 (page 9), select the elastomer material which best corresponds to your application. Step 5: Using the Jaw Nominal Rated Torque Chart 3 (page 9), locate the appropriate elastomer material column for the elastomer selected in Step 4. Scan down this column to the first entry where the Torque Value in the appropriate column is greater than or equal to the Design Torque calculated in Step 3. Once this value is located, refer to the corresponding coupling size in the first column of the Jaw Nominal Rated Torque Chart 3 (page 9). List of Charts provided for Selection: ■ Chart 1– Application Service Factors (page 8) ■ Chart 2 – Spider Performance Data (page 9) ■ Chart 3 – Jaw Nominal Rated Torque (page 9) ■ Jaw Type Performance Ratings (page 22) Formulas: Nominal Torque = in-lb = (HP x 63025) RPM Nm = (KW x 9550) RPM Design Torque = Nominal Torque x Application Service Factor Refer to the maximum RPM value (page 22) for this elastomer torque capability to ensure that the application requirements are met. If the requirement is not satisfied at this point, another type of coupling may be required for the application. Please consult Lovejoy engineering for assistance. Step 6: Compare the application driver/driven shaft sizes to the maximum bore size available on the coupling selected. If coupling bore size is not large enough for the shaft diameter, select the next largest coupling that will accommodate the driver/driven shaft diameters. Refer to Chart 3 (page 9). Step 7: Using the UPC number selection table (pages 11 or 12), find the appropriate Bore and Keyway sizes required and locate the Lovejoy UPC number. 6 #DriveLineHarmony www.jbj.co.uk/spider-couplings.html Straight Jaw Spider Couplings Selection Process
A coupling is needed to connect a 20 HP standard electric motor rated at 1,800 RPM to a rotary pump. The shaft size of the electric motor (driver) is 2.0 inches and the pump (driven) is 1.75 inches. There are no special environmental conditions and the general operating temperature is normal room temperature of 72° F. Less than 1° of misalignment is expected. Step 1: Determine the Nominal Torque: Nominal Torque = (HP x 63025) RPM = (20 x 63025) 1800 = 700.28 in-lb Step 2: Using the Application Service Factors Chart 1 (page 8), select the service factor which best corresponds to your application. The Application Service Factor for an electric motor with standard torque driving a rotary pump is 1.25. The value of 1.25 is found under the application category Pumps, Rotary, column: Electric Motor w/Standard Torque in Chart 1. Step 3: Calculate the Design Torque of your application: Design Torque = Nominal Torque x Application Service Factor = 700.28 x 1.25 = 875.35 in-lb Step 4: Using the Spider Performance Data Chart 2 (page 9), select the elastomer material which best corresponds to your application. Since there are no special environmental conditions, the operating temperature is 72° F and less than 1° of angular misalignment is required, the NBR elastomer material is selected. Step 5: Using the Jaw Nominal Rated Torque Chart 3 (page 9), the NBR elastomer column is used to determine the proper coupling size. Scanning down the NBR column, the first entry to accommodate the Design Torque value of 875.35 in-lb is the size L150 with a nominal torque rating of 1,240 in-lb. Referring to page JW-20, the maximum RPM of 1,800 on the electric motor of the application does not exceed the 5,000 RPM maximum allowed for the L150 size coupling with an NBR elastomer. Step 6: Compare the application driver/driven shaft size to the maximum bore available in the coupling selected (page 9). The electric motor (driver) of this application has a shaft size of 2.0 inches and the pump (driven) has a shaft size of 1.75 inches. The L150 coupling has a maximum bore less than the driver shaft size. Continuing down the Maximum Bore column, in Chart 3 (page 9), the L190 size is found to have a maximum bore size of 2.125 and is able to accommodate the driver/driven shaft sizes. Therefore, the proper coupling size for this application is a Lovejoy L190 with an NBR elastomer. Step 7: Using the UPC number Selection table, locate the appropriate Lovejoy UPC numbers. The L Type Spider Table (page 10), and the L Type hub table (page 11), provides easy reference to the Lovejoy UPC numbers. Locate the L Type Spider Table (page 10). The spider is selected by scanning down the type column and locating the NBR (Solid) entry. Read across to the L190 column and locate the Lovejoy UPC number of 12274. This number should be prefixed with the Lovejoy UPC number of 685144. Locate the L Type Hub Table (page 11). The first bore size to be located is for the 2 inch shaft on the electric motor. Scan down the Bore/Keyway column to the 2 inch bore entry. Read across to the L190 column to locate the Lovejoy UPC number of 12303. This number should be prefixed with the Lovejoy UPC number of 685144. The second bore size to be located is for the 1.75 inch shaft on the pump. Scan down the Bore/Keyway column to the 1-3/4 inch bore entry. Read across to the L190 column to locate the Lovejoy UPC number of 12299. This number should be prefixed with the Lovejoy UPC number of 685144. Selection Example 7 #DriveLineHarmony www.jbj.co.uk/spider-couplings.html Straight Jaw Spider Couplings Selection Process
Straight Jaw Spider Couplings Application Service Factors Application Service Factors Chart 1 8 #DriveLineHarmony www.jbj.co.uk/spider-couplings.html
Characteristics Temperature Range Misalignment Shore Hardness 1 Dampening Capacity Chemical Resistance Color Angular Degree Parallel Inch SOX (NBR) Rubber – Nitrile Butadiene (Buna N) Rubber is a flexible elastomer material that is oil resistant, resembles natural rubber in resilience and elasticity and operates effectively in temperature range of -40° to 212° F (-40° to 100° C). Good resistance to oil. Standard elastomer. (Also applies to SXB Cushions.) -40° to 212° F -40° to 100° C 1° 0.015 80A HIGH GOOD BLACK URETHANE – Urethane has greater torque capability than NBR (1.5 times), provides less dampening effect, and operates at a temperature range of -30° to 160° F (-34° to 71° C). Good resistance to oil and chemicals. Not recommended for cyclic or start/stop applications. -30° to 160° F -34° to 71° C 1° 0.015 55D L050-L110 90-95A L150-L225 LOW VERY GOOD BLUE HYTREL ® – Hytrel is a flexible elastomer designed for high torque and high temperature operations. Hytrel can operate in temperatures of -60° to 250° F (-51° to 121° C) and has an excellent resistance to oil and chemicals. Not recommended for cyclic or start/stop applications. -60° to 250° F -51° to 121° C 1/2° 0.015 55D LOW EXCELLENT TAN BRONZE – Bronze is a rigid, porous oil-impregnated metal insert exclusively for slow speed (maximum 250 RPM) applications requiring high torque capabilities. Bronze operations are not affected by extreme temperatures, water, oil, or dirt. -40° to 450° F -40° to 232° C 1/2° 0.010 — NONE EXCELLENT BRONZE Spider Performance Data Chart 2 Jaw Nominal Rated Torque Data Max Bore Spider Material SOX (NBR) Torque Urethane Torque Hytrel Torque Bronze Torque Size in mm in-lbs Nm in-lbs Nm in-lbs Nm in-lbs Nm L035 0.375 9 3.5 0.4 — — — — — — L/AL050 0.625 16 26.3 3.0 39 4.5 50 5.60 50 5.60 L/AL070 0.750 19 43.2 4.9 65 7.3 114 12.90 114 12.90 L/AL075 0.875 22 90.0 10.2 135 15.3 227 25.60 227 25.60 L/AL090 1.000 25 144.0 16.3 216 24.4 401 45.30 401 45.30 L/AL095 1.125 28 194.0 21.9 291 32.9 561 63.40 561 63.40 L/AL099 1.188 30 318.0 35.9 477 53.9 792 89.50 792 89.50 L/AL100 1.375 35 417.0 47.1 626 70.7 1,134 128.00 1,134 128.00 L/AL110 1.625 42 792.0 89.5 1,188 134.0 2,268 256.00 2,268 256.00 L150 1.875 48 1,240.0 140.0 1,860 210.0 3,708 419.00 3,706 419.00 AL150 1.875 48 1,450.0 163.8 — — — — — — L190 2.125 55 1,728.0 195.0 2,592 293.0 4,680 529.00 4,680 529.00 L225 2.625 65 2,340.0 264.0 3,510 397.0 6,228 704.00 6,228 704.00 L276 2.875 73 4,716.0 533.0 — — — — 12,500 1 412.00 C226 2.500 64 2,988.0 338.0 — — 5,940 671.00 5,940 671.00 C276 2.875 73 4,716.0 533.0 — — 9,432 1 066.00 — — C280 3.000 76 7,560.0 854.0 — — 13,866 1 567.00 — — C285 4.000 102 9,182.0 1 038.0 — — 16,680 1 882.00 — — C295 3.500 89 11,340.0 1 281.0 — — 22,680 2 563.00 22,680 2 563.00 C2955 4.000 102 18,900.0 2 136.0 — — 37,800 4 271.00 37,800 4 271.00 H3067 4.500 114 33,395.0 3 774.0 — — 47,196 5 333.00 47,196 5 333.00 H3567 5.000 127 46,632.0 5 269.0 — — 63,000 7 119.00 63,000 7 119.00 H3667 5.629 143 64,812.0 7 323.0 — — 88,200 9 966.00 88,200 9 966.00 H4067 6.250 159 88,224.0 9 969.0 — — 126,000 14 237.00 126,000 14 237.00 H4567 7.000 178 119,700.0 13 525.0 — — 170,000 19 209.00 170,000 19 209.00 Chart 3 Note: Bronze has a maximum RPM capability of 250 RPM. Notes: 1 indicates: NBR standard shore hardness is 80A ±5A – Except L035=60A. Other softer or harder designs are available in NBR material. Straight Jaw Spider Couplings Performance Data 9 #DriveLineHarmony www.jbj.co.uk/spider-couplings.html
L Type Coupling ■ Sizes range from L035 to L276 ■ Ordering requires selecting UPC numbers for two standard L hubs and one standard open or solid center elastomer (spider) SW Type Coupling ■ Sizes range from L090 to L190 ■ Ordering requires selecting UPC numbers for two standard L hubs and one snap wrap spider with snap ring ■ Both L and SW Type couplings, select hubs from the standard bore and keyway chart (pages 11 to 12) maximum RPM for SW + Ring is 1,750 RPM. ■ Jaw In-Shear Coupling ■ Ordering requires selecting item numbers for two standard hubs, one In-Shear elastomer and one In-Shear ring. See pages 1 to 4. L Type Spider UPC Number Selection Table Spider Type Coupling Size L035 L050 L070 L075 L090/095 L110 L150 L190 L225 L276 SOX (NBR) (Solid) 10118 10194 10406 10621 11070 11494 11724 12001 12274 12409 — SOX (NBR) (open center) — — 10393 10620 10968 11492 11711 37880 37881 12406 12612 Urethane (Solid) — 37786 10395 — — — — — — 12417 — Urethane (open center) — — 10411 10626 11075 11499 11729 12006 12280 — — Hytrel® (Solid) — 25307 — — — — 11717 11993 12265 12401 — Hytrel® (open center) — — 25308 25309 25310 11486 38097 38098 38099 12400 — Bronze (open center) — 10198 10409 10624 11073 11497 11727 12004 12277 34517 25767 Snap Wrap (NBR) w/ring — — — — 24669 24670 24671 24672 24673 — — Snap Wrap (NBR) w/o ring — — — — 11071 11495 11725 12002 12275 — — SOX (NBR) Bulk - pk 25 50115 50116 50117 50118 50119 — — — — — — SOX (NBR) Bulk - pk 10 — — — — — 51020 50121 50122 — — — Snap Wrap Urethane - solid ring — — — — — 41170 41171 — 28284 26093 — In-Shear Elastomer — — — — 67576 67577 67578 67579 67580 68559 67581 In-Shear Ring — — — — 67584 67585 67586 67587 67588 68560 67589 Note: When referencing the Lovejoy UPC number in this table, include 685144 as a prefix to the number shown. L Type Hub - Spline Bore UPC Number Selection Table Teeth Pitch SAE Spline Bore Diameters Major Coupling Size Major Minor Dia L090 L095 L099 L100 L110 L150 L190 L225 L276 9 16/32 A 0.651 0.509 0.625 38568 37900 38571 37904 — — — — — 11 16/32 0.776 0.631 0.750 38569 37901 38572 37905 37909 37917 37925 — — 13 16/32 B 0.901 0.754 0.875 38570 37902 38573 37906 37910 37918 37926 37935 — 13 8/16 D, E 1.798 1.506 1.750 — — — — 37915 37923 37931 37940 38576 14 12/24 C 1.289 1.087 1.250 — — — — 37912 37920 37928 37937 38577 15 16/32 BB 1.026 0.877 1.000 — — 38574 37907 37911 37919 37927 37936 38578 21 16/32 1.401 1.250 1.375 — — — — 37913 37921 37929 37938 — 23 16/32 1.526 1.375 1.500 — — — — 37914 37922 37930 37939 — 27 16/32 1.776 1.625 1.750 — — — — 37916 37924 37932 37941 38579 15 8/16 F 2.048 1.753 2.000 — — — — — — 37933 37942 — Notes: All pressure angles on above splines = 30°. Class 5 fit is standard, unless otherwise specified. All stock spline bore hubs are supplied standard with Lovejoy’s exclusive L-LOC Clamping Feature. See page T-7 for description. When referencing the Lovejoy UPC number in this table, include 685144 as a prefix to the number shown. L099/100 Straight Jaw Spider Couplings L Type Spiders / Hub Spline Bores 10 #DriveLineHarmony www.jbj.co.uk/spider-couplings.html LC coupling uses a snap wrap spider with a collar instead of a retaining ring
ED SLD R VSD UJ SP T D GD HP G MC SF CJ JIS JW Bore Keyway L035 L050 L070 L075 L090 L095 L099 L100 L110 L150 L190 L225 L276 1/8 No Keyway 10124 — — — — — — — — — — — — 3/16 No Keyway 10126 — — — — — — — — — — — — 1/4 No Keyway 10127 10206 10416 10680 10766 — — — — — — — — 1/4 1/8 x 1/16 — — — 35744 — — — — — — — — — 5/16 No Keyway 10128 10207 10417 10681 26209 — — — — — — — — 3/8 No Keyway 24687 10208 10418 10682 10767 — — — — — — — — 3/8 3/32 x 3/64 — 46121 41985 37234 37235 — — — — — — — — 3/8 1/8 x 1/16 — 44136 48829 35745 37236 — — — — — — — — 7/16 No Keyway — 10209 10419 10683 10768 11082 31297 11505 — — — — — 7/16 3/32 x 3/64 — 44713 44007 28089 28877 27613 38198 37237 — — — — — 7/16 1/8 x 1/16 — — 44066 28875 28878 28879 38199 37238 — — — — — 1/2 No Keyway — 10210 10420 10684 10769 11083 11333 11506 — — — — — 1/2 1/8 x 1/16 — 10211 10421 10685 26087 26088 11334 26089 — — — — — 9/16 No Keyway — 10212 52338 10686 24976 37239 11335 11508 — — — — — 9/16 1/8 x 1/16 — 10213 10423 10687 28876 11084 38200 11509 — — — — — 5/8 No Keyway — 10214 24771 44322 46052 41911 44174 44291 11733 12101 — — — 5/8 5/32 x 5/64 — — 51104 37240 37241 37242 38201 37243 37244 37245 — — — 5/8 3/16 x 3/32 — — 10424 10688 10771 11085 11336 11510 26211 26212 — — — 11/16 3/16 x 3/32 — — 10425 10689 10772 11086 11337 11511 11734 12102 — — — 3/4 No Keyway — — 46116 56140 54282 56887 49705 45212 — — 12285 12422 — 3/4 1/8 x 1/16 — — 51719 35881 37246 37074 38202 37247 37248 37249 37250 — — 3/4 3/16 x 3/32 — — 10426 10690 10773 11087 11338 11512 11735 12103 38468 35882 — 13/16 3/16 x 3/32 — — — 10691 10774 11088 11339 11513 11736 12104 37252 37255 — 7/8 No Keyway — — — 56941 — — 59063 — — — — — 12582 7/8 3/16 x 3/32 — — — 10692 10775 11089 11340 11514 11737 12105 12286 12423 12585 7/8 1/4 x 1/8 — — — — 38188 35747 38203 35686 35749 35750 37256 35753 54883 15/16 1/4 x 1/8 — — — — 32332 11090 11341 11515 11738 12160 12287 12424 — 1 1/4 x 1/8 — — — — 31296 11091 11342 11516 11739 12107 12288 12425 12586 1 3/16 x 3/32 — — — — 37257 37258 38204 37259 37260 37261 37262 37263 — 1-1/16 1/4 x 1/8 — — — — — 11092 11343 11517 11740 12108 12289 12426 — 1-1/8 1/4 x 1/8 — — — — — 11093 11344 11518 11741 12109 12290 12427 12587 1-3/16 1/4 x 1/8 — — — — — — 11345 11519 11742 12110 12291 12428 — 1-1/4 1/4 x 1/8 — — — — — — — 11520 11743 12111 12292 12429 12588 1-1/4 5/16 x 5/32 — — — — — — — 35748 35752 35751 37294 35754 12589 1-5/16 5/16 x 5/32 — — — — — — — 11521 11744 12112 12293 26090 — 1-3/8 5/16 x 5/32 — — — — — — — 11522 11745 12113 12294 12430 12590 1-3/8 3/8 x 3/16 — — — — — — — 44348 37265 37266 37267 37568 46758 1-7/16 3/8 x 3/16 — — — — — — — — 11746 12114 12295 12431 12591 1-1/2 5/16 x 5/32 — — — — — — — — 37269 37270 37271 37272 — 1-1/2 3/8 x 3/16 — — — — — — — — 11747 12115 12296 12432 12592 1-9/16 3/8 x 3/16 — — — — — — — — 11748 12116 37273 12433 45689 1-5/8 3/8 x 3/16 — — — — — — — — 11749 12117 12297 12434 12593 1-11/16 3/8 x 3/16 — — — — — — — — — 12118 12298 12435 60057 1-3/4 3/8 x 3/16 — — — — — — — — — 12119 12299 13436 12594 1-3/4 7/16 x 7/32 — — — — — — — — — 37274 37275 37276 48250 1-13/16 1/2 x 1/4 — — — — — — — — — 12120 12300 26091 — 1-7/8 1/2 x 1/4 — — — — — — — — — 12121 12301 12437 12595 1-15/16 1/2 x 1/4 — — — — — — — — — — 12302 12438 49762 2 1/2 x 1/4 — — — — — — — — — — 12303 12439 12596 2-1/16 1/2 x 1/4 — — — — — — — — — — 12304 26092 — 2-1/8 1/2 x 1/4 — — — — — — — — — — 12305 12440 12597 2-3/16 1/2 x 1/4 — — — — — — — — — — — 12441 12598 2-1/4 1/2 x 1/4 — — — — — — — — — — — 12442 12599 2-3/8 5/8 x 5/16 — — — — — — — — — — — 12443 12602 2-5/8 5/8 x 5/16 — — — — — — — — — — — 41809 12605 2-7/8 3/4 x 3/8 — — — — — — — — — — — — 12607 Notes: Tolerances for bore and keyways are found in Engineering Data section (pages ED-10 and ED-11). All hubs supplied standard with one set screw. Non-standard bores available. When referencing the Lovejoy UPC number in this table, include 685144 as a prefix to the number shown. The L Type coupling consists of two standard L Type hubs and one spider. (pages 10 to 12) 11 #DriveLineHarmony www.jbj.co.uk/spider-couplings.html Straight Jaw Spider Couplings L Type Inch Bore / Keyway
ED SLD R VSD UJ SP T D GD HP G MC SF CJ JIS JW JIS CJ SF MC G HP GD D T SP UJ VSD R SLD ED L Type Hub - Metric Bore and Keyway UPC Number Selection Table Bore Keyway L035 L050 L070 L075 L090 L095 L099 L100 L110 L150 L190 L225 L276 4 No Keyway 41850 — — — — — — — — — — — — 5 No Keyway 47419 46214 — — — — — — — — — — — 6 No Keyway 45872 50351 — — — — — — — — — — — 7 No Keyway 60679 10215 58803 — — — — — — — — — — 8 No Keyway 55169 41460 46151 — 60945 — — — — — — — — 9 3 x 1.4 — 41313 56177 44298 — — — — — — — — — 10 No Keyway — 10216 41452 41456 — — — — — — — — — 10 3 x 1.4 — 41450 49870 41457 52828 — — — — — — — — 11 4 x 1.8 — 41314 41453 50811 — 49424 — — — — — — — 12 No Keyway — 48510 51562 — 48276 — — — — — — — — 12 4 x 1.8 — 41315 41454 44153 44329 44832 — 55195 — — — — — 14 No Keyway — 58036 47505 — 41461 41465 — — — — — — — 14 5 x 2.3 — 41316 41317 41321 51231 41466 60094 45101 — — — — — 15 No Keyway — 60708 — 10693 — 46561 52697 41469 — — — — — 15 5 x 2.3 — 41451 41455 41454 52096 45778 46972 47123 — — — — — 16 5 x 2.3 — 56176 41318 41322 49198 41325 52098 55534 52092 52471 — — — 17 5 x 2.3 — — 45333 49398 — 49704 — 56178 60067 60156 — — — 18 6 x 2.8 — — 59724 41884 46433 46626 44647 41926 44288 — — — — 19 No Keyway — — — — 10777 — — — 41471 — — — — 19 6 x 2.8 — — 41319 41323 41462 41326 44157 14329 49700 48821 46717 — — 20 6 x 2.8 — — — 41459 41925 41467 47122 52093 41804 61218 61497 — — 22 6 x 2.8 — — — 58246 41968 44827 41959 44467 45214 44720 — — — 24 8 x 3.3 — — — — 41463 41327 41990 41330 48301 48182 59109 — — 25 8 x 3.3 — — — — 41464 41468 45055 41470 41906 46751 52153 — — 28 No Keyway — — — — — — — — — 56179 56182 — — 28 8 x 3.3 — — — — — 41328 50103 41331 41333 45679 52976 — — 30 8 x 3.3 — — — — — — 47132 48317 45681 41738 44471 48982 — 32 No Keyway — — — — — — — — — 41472 41473 48319 56232 32 10 x 3.3 — — — — — — — — 41334 41873 45562 41849 41885 35 No Keyway — — — — — — — 41332 — 56180 56183 56184 — 35 10 x 3.3 — — — — — — — 49925 45682 46562 58035 52197 — 38 10 x 3.3 — — — — — — — — 41335 41337 41474 49664 52961 40 12 x 3.3 — — — — — — — — 45683 48318 48320 49605 59308 42 12 x 3.3 — — — — — — — — 41336 41338 41475 47492 45609 45 14 x 3.8 — — — — — — — — — 45102 56017 52674 50292 48 No Keyway — — — — — — — — — 56181 — — — 48 14 x 3.8 — — — — — — — — — 56227 48322 47569 61202 50 No Keyway — — — — — — — — — — 56228 56230 56233 50 14 x 3.8 — — — — — — — — — — 44392 48797 45062 55 No Keyway — — — — — — — — — — 56229 56231 56234 55 16 x 4.3 — — — — — — — — — — 47006 44089 56067 60 No Keyway — — — — — — — — — — — 56185 56235 60 18 x 4.4 — — — — — — — — — — — 44598 56236 65 No Keyway — — — — — — — — — — — — 56237 65 18 x 4.4 — — — — — — — — — — — 56544 50102 70 20 x 4.9 — — — — — — — — — — — — 58268 Notes: Tolerances for bore and keyways are found in Engineering Data section (pages ED-10 and ED-11). All hubs supplied standard with one set screw. Non-standard bores available. When referencing the Lovejoy UPC number in this table, include 685144 as a prefix to the number shown. 12 #DriveLineHarmony www.jbj.co.uk/spider-couplings.html Straight Jaw Spider Couplings L Type Metric Bore / Keyway The L Type coupling consists of two standard L Type hubs and one spider. (pages 10 to 12)
Features ■ Radially removable insert ■ Collar allows for maximum speed of 3,600 RPM ■ Collar manufactured from 1018 Steel LC Type Hub - Inch Bore and Keyway UPC Number Selection Table Bore Keyway LC090 LC095 LC099 LC100 LC110 LC150 LC190 LC225 1/4 No Keyway 45321 — — — — — — — 3/8 No Keyway 45322 — — — — — — — 1/2 No Keyway 45323 11133 — 11575 — — — — 1/2 1/8 x 1/16 — — — 48768 — — — — 5/8 No Keyway — — — — 11828 45412 — — 5/8 3/16 x 3/32 45324 11134 48886 11577 — — — — 3/4 No Keyway — — — — — — 12322 12456 3/4 1/8 x 1/16 — — — 55466 — — — — 3/4 3/16 x 3/32 45325 11135 — 41920 11829 — 12323 — 13/16 3/16 x 3/32 — 11136 — — 11830 — — — 7/8 3/16 x 3/32 45326 11137 — 11578 11832 — — — 7/8 1/4 x 1/8 — — 56567 49553 56566 60343 — — 15/16 1/4 x 1/8 — 11138 — — 11834 — — — 1 1/4 x 1/8 45327 11139 52825 11579 11836 12069 44161 50125 1 3/16 x 3/32 — — — — 55552 — — — 1-1/8 1/4 x 1/8 — 44156 — 11580 11838 12071 44160 50126 1-3/16 1/4 x 1/8 — 11140 — — 11840 — — — 1-1/4 1/4 x 1/8 — — — 11581 11841 12073 12327 12462 1-1/4 5/16 x 5/32 — — — 59046 — 48273 — — 1-3/8 5/16 x 5/32 — — — 45257 11842 12075 12329 50127 1-7/16 3/8 x 3/16 — — — — 11844 — — 12465 1-1/2 5/16 x 5/32 — — — — — 12077 — — 1-1/2 3/8 x 3/16 — — — — 11846 — 12332 12466 1-9/16 3/8 x 3/16 — — — — 11848 — 12332 — 1-5/8 3/8 x 3/16 — — — — 11849 12079 12334 12468 1-3/4 3/8 x 3/16 — — — — — 44159 12336 46818 1-7/8 1/2 x 1/4 — — — — — 12082 12337 12472 1-15/16 1/2 x 1/4 — — — — — — 12339 — 2 1/2 x 1/4 — — — — — — 12341 14276 2-1/8 1/2 x 1/4 — — — — — — 44064 12477 2-1/4 1/2 x 1/4 — — — — — — — 12480 2-3/8 5/8 x 5/16 — — — — — — — 12482 Notes: These “LC” hubs are drilled and tapped to accept collar mounting screws but the collar and hardware are not included. See L Type (inch or metric) coupling chart for standard hub. Tolerances for bore and keyways are found in Engineering Data section (pages ED-10 and ED-11). All hubs are supplied standard with one set screw. When referencing the Lovejoy UPC number in this table, include 685144 as a prefix to the number shown. 13 #DriveLineHarmony www.jbj.co.uk/spider-couplings.html Straight Jaw Spider Couplings LC Type Inch Bore / Keyway The LC Type coupling consists of one standard L Type hub (without collar attachment), one LC Type hub (provides collar attachment), one standard snap wrap center and one collar with screws (pages 11 to 13)
Features ■ Radially removable insert ■ Collar allows for maximum speed of 3,600 RPM ■ Collar manufactured from 1018 Steel LC Type Wrap Spider / Collar UPC Number Selection Table LC090 LC095 LC099 LC100 LC110 LC150 LC190 LC225 Snap Wrap Spider/No Ring 11071 11071 11495 11495 11725 12002 12275 26093 1 Collar Only w/Screws 48340 48340 45258 45258 47932 47933 47934 47935 LC Type Hub - Metric Bore and Keyway UPC Number Selection Table Bore Keyway LC090 LC095 LC099 LC100 LC110 LC150 LC190 LC225 12 No Keyway 58596 — — — — — — — 12 4 x 1.8 58597 — — — — — — — 14 No Keyway 58598 58592 — — — — — — 14 5 x 2.3 58556 58559 — — — — — — 15 5 x 2.3 58599 — — — — — — — 16 5 x 2.3 — 58593 — — — — — — 19 6 x 2.8 58557 58560 56197 58563 58566 — — — 20 6 x 2.8 — 58594 — — — — — — 24 8 x 3.3 58558 58561 58588 58564 58567 — — — 25 8 x 3.3 58600 58595 58589 — — — — — 28 8 x 3.3 — 58562 58590 58565 58568 58571 58575 — 32 10 x 3.3 — — — 52806 58587 58585 58586 — 38 10 x 3.3 — — — — 58569 58572 58576 58580 42 12 x 3.3 — — — — 58570 58573 58577 58581 48 14 x 3.8 — — — — — 58574 58578 58582 55 16 x 4.3 — — — — — — 58579 58583 65 No Keyway — — — — — — — 58584 Notes: These “LC” hubs are drilled and tapped to accept collar mounting screws but the collar and hardware are not included. See L Type (inch or metric) UPC Number Selection Table for standard hub (pages 10 to 11). Tolerances for bore and keyways are found in Engineering Data section (pages ED-17 and ED-18). All hubs are supplied with one set screw. When referencing the Lovejoy UPC number in this table, include 685144 as a prefix to the number shown. Notes: 1 indicates: L225 snap wrap spider is urethane, solid ring. When referencing the Lovejoy UPC number in this table, include 685144 as a prefix to the number shown. 14 #DriveLineHarmony www.jbj.co.uk/spider-couplings.html Straight Jaw Spider Couplings LC Type Metric Bore / Keyway The LC Type coupling consists of one standard L Type hub (without collar attachment), one LC Type hub (provides collar attachment), one standard snap wrap center and one collar with screws (pages 11 to 13)
AL Type Hub - Inch Bore and Keyway UPC Number Selection Table Bore Keyway AL050 AL070 AL075 AL090 AL095 AL099 AL100 AL110 AL150 1⁄4 No Keyway 10252 10463 10630 10791 — — — — — 5⁄16 No Keyway 10253 10464 10631 10792 — — — — — 3⁄8 No Keyway 10254 10466 10632 10793 — — — — — 7⁄16 No Keyway 10256 10469 10633 10794 — — — — — 1⁄2 No Keyway 10257 10471 10634 10795 17847 17880 17914 — — 1⁄2 1/8 x 1/16 49706 10473 10635 10796 17848 17881 17915 — — 9⁄16 No Keyway — — 10637 10797 — — 56473 — — 9⁄16 1/8 x 1/16 — — 10638 4412 37994 44323 17917 — — 5⁄8 No Keyway 10259 10480 61817 44004 — — — 17977 18035 5⁄8 3/16 x 3/32 — 10482 10639 10798 17855 17882 17918 38888 44828 11⁄16 3/16 x 3/32 — — 45227 10799 17851 45494 17919 44059 46642 3⁄4 1/8 x 1/16 — — 47835 47725 46295 — — — — 3⁄4 3/16 x 3/32 — 10491 10640 10800 17852 17883 17920 17978 18036 13⁄16 3/16 x 3/32 — — 10641 10801 17853 17884 17921 — — 7⁄8 3/16 x 3/32 — — 10642 10802 17854 17885 17922 17979 18037 15⁄16 1/4 x 1/8 — — — — 17855 17886 17923 17980 18038 1 1/4 x 1/8 — — — — 17856 17887 17924 17981 18039 1-1⁄16 1/4 x 1/8 — — — — 17857 17888 17925 26094 18040 1-1⁄8 1/4 x 1/8 — — — — 17858 17889 17926 17982 18041 1-3⁄16 1/4 x 1/8 — — — — — 17890 17927 17983 18042 1-1⁄4 1/4 x 1/8 — — — — — — 17928 17984 18043 1-5⁄16 5/16 x 5/32 — — — — — — 17929 17985 18044 1-3⁄8 5/16 x 5/32 — — — — — — 17930 17986 18045 1-7⁄16 3/8 x 3/16 — — — — — — 45508 17987 18046 1-1⁄2 3/8 x 3/16 — — — — — — — 17988 18047 1-9⁄16 3/8 x 3/16 — — — — — — — 17989 18048 1-5⁄8 3/8 x 3/16 — — — — — — — 17990 18049 1-11⁄16 3/8 x 3/16 — — — — — — — — 18050 1-3⁄4 3/8 x 3/16 — — — — — — — — 18051 1-13⁄16 1/2 x 1/4 — — — — — — — — 18052 1-7⁄8 1/2 x 1/4 — — — — — — — — 18053 Notes: Tolerances for bore and keyways are found in Engineering Data section (page ED-10). Lovejoy does not recommend reboring AL hubs. All hubs are supplied standard with one set screw, except the AL150 which is provided with two set screws. When referencing the Lovejoy UPC number in this table, include 685144 as a prefix to the number shown. Note: When referencing the Lovejoy UPC number in this table, include 685144 as a prefix to the number shown. The AL Type coupling consists of two hubs and one spider. Features ■ Interchangeable with all hub sizes standard for the L-Line and AL-Line products ■ Available in a variety of different finished bore and keyway combinations ■ Finished bores passivated for additional rust protection SS Type Hub - Inch Bore and Keyway UPC Number Selection Table Size RSB 1/4 1/2 5/8 3/4 7/8 1 1-1/8 1-3/8 1-1/2 SS075 70001 70006 70007 70008 70009 70010 — — — — SS095 70002 70011 70011 70012 70013 70014 70015 70016 — — SS100 70003 — — — 70017 70018 70019 70020 70022 — SS110 70004 — — — — — 70023 70024 70026 70027 SS150 70005 — — — — — 70029 70030 70032 70033 Straight Jaw Spider Couplings AL & SS Type Inch Bore / Keyway 15 #DriveLineHarmony www.jbj.co.uk/spider-couplings.html
Notes: AL Type couplings use the same spiders as L Type couplings, except AL150 which has four jaws instead of three. When referencing the Lovejoy UPC number in this table, include 685144 as a prefix to the number shown. The AL Type coupling consists of two hubs and one spider. Refer to page 10 Features ■ Aluminum material is corrosion resistant ■ Lightweight ■ Hubs compatible with standard Lovejoy hub design (except AL150) AL Type Spider UPC Number Selection Table Spider Type AL050 AL070 AL075 AL090/095 AL099/100 AL110 AL150 SOX (NBR) (solid) 10194 10406 10621 11070 11494 11724 18027 SOX (NBR) (open center) — 10393 10620 10968 11492 11711 — Urethane (solid) 37786 10395 — — — — — Urethane (open center) — 10411 10626 11075 11499 11729 — Hytrel (solid) 25307 — — — — 11717 — Hytrel (open center) — 25308 25309 25310 11486 38097 — Bronze (open center) 10198 10409 10624 11073 11497 11727 — Snap Wrap w/ring — — — 24669 24670 24671 — Snap Wrap no ring — — — 11071 11495 11725 — AL Type Hub - Metric Bore and Keyway UPC Number Selection Table Bore Keyway AL050 AL070 AL075 AL090 AL095 AL099 AL100 AL110 AL150 8 No Keyway — — 48973 — — — — — — 10 3 x 1.4 — — 41924 56514 — — — — — 11 4 x 1.8 — 65694 51098 58620 — — — — — 12 4 x 1.8 — 56487 64655 60429 — — — — — 14 5 x 2.3 — 65696 47302 58621 56800 58624 — — — 15 5 x 2.3 — 62906 49633 58622 56801 — 49629 — — 16 5 x 2.3 — — 52221 — 47014 — 45012 — — 17 5 x 2.3 — — — 60887 44712 — 59164 — — 19 6 x 2.8 — 65698 47427 44679 47012 58625 47253 59064 — 20 No Keyway — — 56137 — — — — — — 20 6 x 2.8 — — 59394 61478 48347 49634 49630 49631 60878 22 6 x 2.8 — — — — 47013 — — — — 24 8 x 3.3 — — — — 45736 58626 44058 45690 64634 25 8 x 3.3 — — — — 65469 49709 55687 45933 64633 28 8 x 3.3 — — — — 47015 58627 47393 45463 — 30 8 x 3.3 — — — — — 52048 58266 49632 45063 32 10 x 3.3 — — — — — — — 54417 44347 35 10 x 3.3 — — — — — — — 46215 64803 36 10 x 3.3 — — — — — — — — 51737 38 10 x 3.3 — — — — — — — 52692 58215 42 12 x 3.3 — — — — — — — — 45404 46 14 x 3.8 — — — — — — — — 64119 Notes: Tolerances for bore and keyways are found in Engineering Data section (page ED-17). Lovejoy does not recommend reboring AL hubs. All hubs are supplied standard with one set screw, except the AL150 which is provided with two set screws. When referencing the Lovejoy UPC number in this table, include 685144 as a prefix to the number shown. Straight Jaw Spider Couplings AL & SS Type Metric Bore / Keyway 16 #DriveLineHarmony www.jbj.co.uk/spider-couplings.html
Notes: RRS inch hubs are standard with two set screws, including those with no keyway. When referencing the Lovejoy UPC number in this table, include 685144 as a prefix to the number shown. Notes: RRS inch hubs are standard with two set screws and are drilled to accept retaining collar. Collars are supplied with spacers. When referencing the Lovejoy UPC number in this table, include 685144 as a prefix to the number shown. Notes: RRS inch hubs are standard with two set screws and are drilled to accept retaining collar. Collars are supplied with spacers. When referencing the Lovejoy UPC number in this table, include 685144 as a prefix to the number shown. RRS and RRSC Type Radially Removable Spacer Couplings RRS Type Hub - Inch Bore and Keyway UPC Number Selection Table Bore Keyway RRS090 RRS095 RRS099 RRS100 RRS110 RRS150 RRS190 RRS225 7⁄16 No Keyway — 41229 52184 41231 — — — — 1⁄2 No Keyway 41227 50357 41230 52199 — — — — 1⁄2 1/8 x 1/16 56512 38145 — 38151 — — — — 9⁄16 3/16 x 3/32 — 44474 — — — — — — 5⁄8 No Keyway — — — — 38159 45265 — — 5⁄8 3/16 x 3/32 38143 38146 38168 38152 — 50163 — — 3⁄4 No Keyway — — — — — — 45273 45290 3⁄4 3/16 x 3/32 38144 38147 38169 38153 38160 45266 — 45292 7⁄8 1/4 x 1/8 — — — 52966 — — — — 7⁄8 3/16 x 3/32 41228 38148 38170 38154 38161 45267 45274 45291 1 1/4 x 1/8 51672 38149 38171 38155 38162 45268 45275 45294 1-1⁄8 1/4 x 1/8 — 38150 38172 38156 38163 45153 45276 45295 1-1⁄8 5/16 x 5/32 — — — — — 48104 — — 1-1⁄4 1/4 x 1/8 — — — 38157 38164 45392 48503 50743 1-3⁄8 5/16 x 5/32 — — — 38158 38165 44002 44725 45296 1-7⁄16 3/8 x 3/16 — — — — 51579 49659 48933 49658 1-1⁄2 3/8 x 3/16 — — — — 40816 49638 46628 45297 1-5⁄8 3/8 x 3/16 — — — — 38166 41880 45277 45298 1-3⁄4 3/8 x 3/16 — — — — — 45162 45278 45299 1-7⁄8 1/2 x 1/4 — — — — — 44214 45279 41953 2 1/2 x 1/4 — — — — — — 45280 45300 2-1⁄8 1/2 x 1/4 — — — — — — — 44724 2-3⁄8 5/8 x 5/16 — — — — — — — 45106 RRS / RRSC Type Hub - Inch Bore and Keyway UPC Number Selection Table Bore Keyway RRSC150 RRSC190 RRSC225 5⁄8 No Keyway 45269 — — 3⁄4 No Keyway — 45281 45301 3⁄4 3/16 x 3/32 45312 — 45303 7⁄8 3/16 x 3/32 45270 45282 45293 1 1/4 x 1/8 45271 45283 45305 1-1⁄8 1/4 x 1/8 44779 45284 45105 1-3⁄8 5/16 x 5/32 44006 45285 45306 1-1⁄2 3/8 x 3/16 46939 — 45307 1-5⁄8 3/8 x 3/16 14881 45286 45308 1-3⁄4 3/8 x 3/16 — 45287 45309 1-7⁄8 1/2 x 1/4 45272 45288 41954 2 1/2 x 1/4 — 45289 45310 2-1⁄8 1/2 x 1/4 — — 45311 Bore Keyway RRSC150 RRSC190 RRSC225 32 No Keyway 55675 55679 55683 38 10 x 3.3 55676 55680 — 40 12 x 3.3 55677 55681 — 42 12 x 3.3 55678 55682 RRS Type couplings range from sizes RRS090 to RRS225. The RRS Type coupling consists of: RRS090 – RRS110: 2 Standard RRS Hubs 1 Spacer Assembly consisting of: ■ 2 snap wrap spiders w/o ring ■ 2 collars with screws ■ 1 spacer RRS150 – RRS225: 1 Standard RRS Hub 1 Standard RRSC Hub – Drilled for collar 1 Spacer Assembly consisting of: ■ 2 snap wrap spiders w/o ring ■ 2 collars with screws ■ 1 spacer Straight Jaw Spider Couplings RRS & RRSC Type Inch Bore / Keyway RRS / RRSC Type Hub - Metric Bore and Keyway UPC Number Selection Table 17 #DriveLineHarmony www.jbj.co.uk/spider-couplings.html
Note: When referencing the Lovejoy UPC number in this table, include 685144 as a prefix to the number shown. RRS Type Radially Removable Spacer Couplings Features ■ Standard API based spacers available ■ Radially removable inserts ■ Standard Lovejoy hub design with additional set screw at 90° RRS Type Spacer UPC Number Selection Table Description RRS090 RRS095 RRS099 RRS100 RRS110 RRS150 RRS190 RRS225 3-1/2 in Spacer Assembly 12620 12620 12630 12630 12644 12660 12676 12685 5 in Spacer Assembly 26119 26119 26123 26123 26128 26770 27046 27041 7 in Spacer Assembly 26120 26120 26124 26124 26129 27044 27043 27039 100mm Spacer Assembly 55563 55563 55567 55567 55570 61056 61057 61058 140mm Spacer Assembly 55281 55281 55569 55569 55571 55572 55573 55574 180mm Spacer Assembly 61055 61055 55575 55575 55576 55577 55578 55579 RRS Type Hub - Metric Bore and Keyway UPC Number Selection Table Bore Keyway RRS090 RRS095 RRS099 RRS100 RRS110 RRS150 RRS190 RRS225 12 No Keyway 48276 — — — — — — — 14 No Keyway 41461 41465 — — — — — — 14 5 x 2.3 51231 41466 60094 45101 — — — — 15 No Keyway — 46561 52697 41469 — — — — 15 5 x 2.3 52096 45778 46972 47123 — — — — 16 5 x 2.3 49198 41325 52098 55534 52092 52471 — — 19 No Keyway 10777 — — — 41471 — — — 19 6 x 2.8 41462 41326 44157 41329 49700 48821 46717 — 20 6 x 2.8 41925 41467 47122 52093 41804 — 61497 — 23 8 x 3.3 50135 — — — — — — — 24 8 x 3.3 41463 41327 41990 41330 48301 48182 59109 — 25 8 x 3.3 41464 41468 45055 41470 41906 46751 52153 — 28 8 x 3.3 — 41328 50103 41331 41333 45679 52976 — 30 8 x 3.3 — — 47132 48317 45681 41738 44471 48982 32 No Keyway — — — — — 41472 41473 48319 32 10 x 3.3 — — — 41332 41334 41873 45562 41849 35 10 x 3.3 — — — 49925 45682 46562 58035 52197 38 10 x 3.3 — — — — 41335 41337 41474 49664 40 12 x 3.3 — — — — 45683 48318 48320 49605 42 12 x 3.3 — — — — 41336 41338 41475 47492 Notes: Spacer length denotes separation between shaft ends. Assembly includes spacer, two snap wrap spiders w/o ring, and two collars with screws. See page 10 for ordering information on spiders. When referencing the Lovejoy UPC number in this table, include 685144 as a prefix to the number shown. RRS090 – RRS110: 2 Standard RRS Hubs 1 Spacer Assembly consisting of: ■ 2 snap wrap spiders w/o ring ■ 2 collars with screws ■ 1 spacer RRS150 – RRS225: 1 Standard RRS Hub 1 Standard RRSC Hub – Drilled for collar 1 Spacer Assembly consisting of: ■ 2 snap wrap spiders w/o ring ■ 2 collars with screws ■ 1 spacer Note: RRS Type Inch Hubs provided standard with two set screws at 90°. RRS Type couplings range from sizes RRS090 to RRS225 The RRS Type coupling consists of: Straight Jaw Spider Couplings RRS & RRSC Type Metric Bore / Keyway 18 #DriveLineHarmony www.jbj.co.uk/spider-couplings.html
Notes: Chemical resistance and compatibility for cushions is described in Engineering Data section (page ED-9). When referencing the Lovejoy UPC number in this table, include 685144 as a prefix to the number shown. Notes: RSB (Rough Stock Bore) hub has no keyway or set screw hole, it is not useable as shown and must be machined to proper bore tolerances. Hub includes inside sleeve and is drilled and tapped for collar bolts. Non-standard bores available – consult jbj Techniques Limited For RSB hub part numbers see the C Type Inch Hub table. When referencing the Lovejoy UPC number in this table, include 685144 as a prefix to the number shown. Notes: RSB (Rough Stock Bore) hub has no keyway or set screw hole, it is not useable as shown and must be machined to proper bore tolerances. Hub includes inside sleeve and is drilled and tapped for collar bolts. Non-standard bores available – consult jbj Techniques Limited When referencing the Lovejoy UPC number in this table, include 685144 as a prefix to the number shown. C Type Couplings The C Type coupling consists of two standard hubs, one cushion set and collar with hardware. Features ■ Greater torque and bore capacity than the L-Line series jaw coupling ■ Elastomeric cushions are radially removable ■ Cushions available in SXB rubber and Hytrel C Type Hub - Metric Bore and Keyway UPC Number Selection Table Bore Keyway C226 C276 C280 C285 C295 C2955 30 8 x 3.3 62792 — — — — — 35 10 x 3.3 60243 47386 — — — — 38 10 x 3.3 45348 62160 — — — — 40 12 x 3.3 49379 54037 — — — — 42 12 x 3.3 — 45219 — — — — 45 14 x 3.8 52550 44723 58265 — — — 48 14 x 3.8 54288 — 52205 — — — 55 16 x 4.3 58011 58444 49012 — — — 60 18 x 4.4 — 47265 49378 — — — 65 18 x 4.4 — 52008 — — — 58676 70 20 x 4.9 — 59032 — 56794 54355 58677 75 22 x 5.4 — — — — 47913 58678 80 22 x 5.4 — — — 44487 58675 58679 90 25 x 5.4 — — — 54363 — — 95 25 x 5.4 — — — — — 62695 C Type Hub - Inch Bore and Keyway UPC Number Selection Table Bore Keyway C226 C276 C280 C285 C295 C2955 7⁄8 RSB No Keyway 40125 40126 — — — — 1-1⁄8 1/4 x 1/8 26036 26050 — — — — 1-1⁄4 RSB No Keyway — — 20607 41036 — — 1-1⁄4 1/4 x 1/8 26037 26051 48988 47173 — — 1-3⁄8 5/16 x 5/32 26038 26052 46278 55546 — — 1-7⁄16 3/8 x 3/16 26039 — — — — — 1-1⁄2 RSB No Keyway — — — — 41037 — 1-1⁄2 3/8 x 3/16 26040 26053 46277 48366 44824 — 1-5⁄8 3/8 x 3/16 26041 26054 46194 41892 56078 — 1-3⁄4 RSB No Keyway — — — — — 41038 1-3⁄4 3/8 x 3/16 26042 26055 44011 52311 45780 — 1-7⁄8 1/2 x 1/4 26043 26056 44012 51533 47080 49075 2 1/2 x 1/4 26044 26057 48194 — — — 2-1⁄8 1/2 x 1/4 26045 26058 44370 49809 44711 — 2-1⁄4 1/2 x 1/4 26046 44547 — — — — 2-3⁄8 5/8 x 5/16 26047 26060 44014 47288 44825 52703 2-1⁄2 5/8 x 5/16 26048 46120 51998 56779 45249 48454 2-5⁄8 5/8 x 5/16 — 46755 44013 — 50145 54549 2-7⁄8 3/4 x 3/8 — 26064 51525 49456 52702 48108 3 3/4 x 3/8 — — 48193 — — — 3-3⁄8 7/8 x 7/16 — — — 47171 45402 49077 3-1⁄2 7/8 x 7/16 — — — 46844 52988 44545 3-5⁄8 7/8 x 7/16 — — — — — 50106 3-3⁄4 7/8 x 7/16 — — — — — 58378 3-7⁄8 1 x 1/2 — — — 48247 — 49351 4 1 x 1/2 — — — — — 55016 C Type Cushions / Collar UPC Number Selection Table Size C226 C276 C280 C285 C295 C2955 Number of Cushions 6 6 6 6 6 10 SXB (NBR) cushion set 14547 14633 14712 14771 14805 14856 Hytrel® cushion set 27529 14637 14716 14774 14808 14859 Bronze cushion set 14545 — — — 51914 51915 Collar with hardware 40122 40123 40124 40292 40293 40293 C Type Cushions / Collar and Inch / Metric Bore / Keyway 19 #DriveLineHarmony www.jbj.co.uk/spider-couplings.html
