PETROL ENGINE ADAPTORS Part no: Ped 1/- - -/110 To suit: Honda, Briggs & Stratton, Kawasaki, Mag, Robin, Suzuki, Winsconsin, etc. Units can be machined to suit most hydraulic pump mountings. Adaptors to suit engine camshaft drives and for vertical mounting available on request. Please contact jbj Techniques technical office, telephone: 01737 767493 or email: info@jbj.co.uk www.jbj.co.uk/hydraulic-adaptors.html#for-petrol-engines #DriveLineHarmony For pump mounting machine codes and adaptors please refer to back page of this leaflet.
Part no: lto 414/- - -/140 To suit: Honda, Briggs & Stratton, Kubota, etc. Units can be machined to suit most hydraulic pump mountings. Adaptors to suit engine camshaft drives and for vertical mounting available on request. Please contact jbj Techniques technical office, telephone: 01737 767493 or email: info@jbj.co.uk PETROL ENGINE ADAPTORS www.jbj.co.uk/hydraulic-adaptors.html#for-petrol-engines #DriveLineHarmony For pump mounting machine codes and adaptors please refer to back page of this leaflet.
For pump mounting machine codes and adaptors please refer to back page of this leaflet. Part no: Ped 3/- - -/160 (std spigot), Ped 3X/- - -/160 (optional spigot) To suit: Honda, Briggs & Stratton, Kawasaki, Mag, Robin, Suzuki, Winsconsin, etc. Units can be machined to suit most hydraulic pump mountings. Adaptors to suit engine camshaft drives and for vertical mounting available on request. Please contact jbj Techniques technical office, telephone: 01737 767493 or email: info@jbj.co.uk PETROL ENGINE ADAPTORS www.jbj.co.uk/hydraulic-adaptors.html#for-petrol-engines #DriveLineHarmony
For pump mounting machine codes and adaptors please refer to back page of this leaflet. Part no: ltoC95/- - -/140 To suit: Kubota OC95 engine. Units can be machined to suit most hydraulic pump mountings. Adaptors to suit engine camshaft drives and for vertical mounting available on request. Please contact jbj Techniques technical office, telephone: 01737 767493 or email: info@jbj.co.uk PETROL ENGINE ADAPTORS www.jbj.co.uk/hydraulic-adaptors.html#for-petrol-engines #DriveLineHarmony
Part no: lto1B40/- - -/140 .. To suit: Hatz 1B40 engine Units can be machined to suit most hydraulic pump mountings. Adaptors to suit engine camshaft drives and for vertical mounting available on request. Please contact jbj Techniques technical office, telephone: 01737 767493 or email: info@jbj.co.uk PETROL ENGINE ADAPTORS www.jbj.co.uk/hydraulic-adaptors.html#for-petrol-engines #DriveLineHarmony For pump mounting machine codes and adaptors please refer to back page of this leaflet.
Pump face machining codes (- - -) www.jbj.co.uk/hydraulic-adaptors.html#for-petrol-engines #DriveLineHarmony PETROL ENGINE ADAPTORS
Pump face machining codes (- - -) continued . . . www.jbj.co.uk/hydraulic-adaptors.html#for-petrol-engines #DriveLineHarmony PETROL ENGINE ADAPTORS Additional reference catalogues Compatible couplings - catalogue and catalogue. P u p r or i m D ive Components T s onal Couplings Diesel engine adaptors - catalogue and catalogue. Pu p r o m D ives T rsional Couplings
Getting the most out of your machinery often depends on close integration between all components. An organisation that manufactures and integrates all the diverse components of a drivetrain provides the experience to help you select the best component combination for your application. jbj Techniques’ in-house design team and manufacturing facility provide tailored solutions for your applications at competitive prices with quick delivery. The following examples are a simplistic view of how jbj Techniques assists customers. Hydraulic Adaptors Designed primarily to allow the close coupling of hydraulic pumps to a variety of prime movers, such as diesel / petrol engines, electric, air or hydraulic motors, they can also be used in the connection from prime mover to alternative driven parts i.e. gear boxes, generators, water or vacuum pumps etc. An additional range of engine front PTO adaptors, which provide additional connection between the engine pulley and the driven part are also available. The kit comprises of a and flexible bellhousing drive that are fully machined to suit the coupling driving and driven components. These can be to suit either shaft to shaft, flange (flywheel) to shaft or even flange to flange connections. Getting the most out of your equipment will demand close integration between all components. In specifying jbj Techniques as your preferred supplier, you will have selected a company with the experience to specify, manufacture and integrate all of the diverse components that will ensure the best component combination for your application. jbj's in house design team and manufacturing facility provide tailored solutions for your applications at competitive pricing and on-time deliveries. Pump shaft alignment is key to preventing unnecessary wear and damage to the pump shaft seal and bearing. Improper alignment may lead to premature pump failure. Also to be considered are unwanted torsional resonant frequencies in the system which can quickly cause damage to components in the drivetrain and reduce system life and performance. Improper pump installation can lead to premature failure, increased maintenance costs and reduced production levels of final product. jbj Techniques can advise on the correct installation of into Industrial / hydraulic pumps mobile / marine / machine tool / agricultural / offshore industries and can specify complete driveline systems from their extensive range of quality products for mechanical & fluid power an excellence in engineering components which are available from stock or manufactured to order, albeit simple or complex, standard or bespoke. Electric Motor – Hydraulic Pump Adaptors (safe area) jbj Techniques Limited offer the most comprehensive range of in Europe. bellhousings Designed to connect electric motors with frame size IEC D56 - D400 (0.06kW – 750kW) and can be compatible with electric motor 'B5' or 'B14' flange configurations. Accompanying the metric frame units above is a complete range of mountings to suit Nema and imperial frame motors with 'C' face or 'D' flange fitments. With fully machined , torsionally flexible couplings or available, jbj ensure torsionally rigid couplings the most suitable combination is selected for the application in hand. As an example spider couplings are available in various materials including aluminium, grey cast iron, nodular iron, steel and stainless steels and can be finish machined with parallel, taper or splined bores to DIN, SAE, ANSI or ISO standards. Bellhousings can be manufactured in aluminium or cast iron material as standard, however, units can be produced in a variety of exotic materials on request. The aluminium product range is produced in
ensuring a continuing high quality service in which customers can have complete confidence. “ “ either monoblock or composite formats giving great flexibility in design and allows for early delivery time, often with same or next day delivery possibilities. For applications where low noise levels are a requirement then a complete range of antivibration and noise reduction components add to the range. Electric motor – Hydraulic Pump Adaptors (hazardous area) Designed to meet the exacting safety standards of the offshore and chemical process industries, jbj Techniques produce certificated to adaptor kits Directive 2014/34/EU II2GD-IM2-TX -50 C< Service Temp < +105 C. Harmonised standards BS EN 1127:1, BS EN 13463:1, BS EN13463:5, BS EN 50303, BS EN 1834-1,BS EN 1834-3. Generally manufactured in Cast or Nodular iron, bellhousings can be produced in steel, stainless steel or alternative exotic materials on customer request. Couplings supplied for these applications are the jbj Techniques 'JXL' pin and bush range which provide an anti-static and flameproof drive which meet zone 1 area requirements, conforming to all of the above standards. Also available are spider and gear couplings which are certified to zone 2 standards. (Contact jbj Techniques for details). An important development of equipment for use within hazardous areas is the wet mount series of bellhousings. Commissioned to research and develop a product that would control the high temperature generated by a piston pump shaft seal when working within cycling applications. A little considered issue is the frictional heat generated at the shaft seal when the application requires the pump to cycle between different to Large Combinations Small Individual Components pressures causing the seal temperature to increase. This process will often take the seal temperature out and above the levels required by the relevant ATEX standards requirement. This specially designed assembly allows a pumped cooling flow to be passed over the seal face and through an auxiliary cooler, this in turn reduces the seal face temperature which can be maintained at an acceptable level. With a vast array of components to select from, jbj are well placed to provide all required components to support the required cooling system. Diesel Engine – Hydraulic Pump Adaptors A complete range of bellhousing and couplings exist for the connection of a diesel engine flywheel to a specified driven component, be it an oil hydraulic pump, water pump, generator or similar device. With the bellhousing available in various materials to suit all application areas. With a standard range to connect Diesel engines with SAE dimensions from SAE '6' to SAE '0' jbj are well placed to satisfy the majority of customer requirements. Couplings to complete the assembly are available in either torsionally flexible or torsionally rigid design ad can be supplied to suit SAE flywheel dimensions from SAE 6.5” to SAE 18”. For hydraulic pumps to be mounted to engines that do not conform to SAE dimensions, we offer a full range of assembly parts, some of which (but not all) are shown here » for diesel engines All bellhousings within this range can be finished machined to accept any, piston, vane or gear pump interfaces requested by customer. As with the electric motor range of product jbj offer complete solutions for ATEX environments, using our well proven 'JXL' coupling range which has standard design to connect to the engine flywheel. Directive 2014/34/EU II2GD-IM2-TX -50°C ≤ Service Temp ≤ +105°C. Harmonised Standards: BS EN 1127:1 BS EN 13463:1 BS EN 13463:5 BS EN 50303. Petrol Engine – Hydraulic Pump Adaptors Petrol engine adaptors have been developed for use with industrial petrol engines. Design exists to suit Honda, Briggs and Stratton, Kawasaki, Kubota, Hatz, Mag, Robin, Suzuki, Winsconsin, to name but a few, all adaptors can be finished to accept most hydraulic pumps. Adaptors to suit engine crankshaft drives and for vertical mounting are available on request.
