® SITEX ST (all steel) GEAR COUPLINGS 01 25
an excellence in engineering www.jbj.co.uk/couplings.html ® patented Elika profile is everything 01737 767493 info@jbj.co.uk www.jbj.co.uk You Tube - registered in England No: 1185469 - jbj Techniques Limited is ISO certificated, committed to international coordination & unification of industrial standards. A range of products ATEX certificated to directive 94/9/E requirements
www.jbj.co.uk/couplings.html #DriveLineHarmony Contents SITEX® Gear Couplings Page ® SITEX STIntroduction.......................................................................... 1 ® SITEX STModelTypes......................................................................... 2 Type“C” ..................................................................................... 3 Type“CV” .................................................................................... 4 Type“CF”A-B-C(AGMA)........................................................................ 5 Type “CF” D-E-F. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 CouplingSelection ............................................................................. 7 Installation and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 9 #DriveLineHarmony............................................................................ 10 I The details contained within this catalogue are reproduced in accordance with the latest information at publication of this catalogue. Errors & Omissions Excepted Last update: 01/07/2020
www.jbj.co.uk/couplings.html #DriveLineHarmony Introduction ® SITEX ST Gear Couplings 1 Description ® SITEX ST couplings are fully manufactured in high quality steel. They are made of 1 or 2 geared hubs which are coupled with one sleeve through which the torque is transmitted. The special OPTIGEAR profile allows very high torque transmission and the compensation of axial, angular and radial misalignment (only in the version with 2 hubs). The maximum recommended working temperature is -10°C to + 80°C. For special applications special materials should be used. Please contact jbj Techniques Limited technical office, telephone: +44 (0)1737 767493 or email info@jbj.co.uk for information. Features With the special design of the OPTIGEAR crown, the contact surface area under misalignment is larger than conventional crown. This results in the surface stresses being reduced resulting in a longer coupling life. Therefore, backlash is reduced to a minimum, reducing impact load in reverse application, and allowing optimum torque transmission and low vibration. All this results in an improved machine design. OPTIGEAR Profile ® SITEX ST couplings are machined with the unique OPTIGEAR profile, ensuring backlash is reduced to a minimum reducing impact load in reverse applications and allowing optimum torque transmission and low vibration. The result is a compact coupling keeping the application machine design optimized in size and work capacity. Interchangeability The range GST CF “A-B-C” conforms to AGMA specification in flange dimensions, type and positions of the screws. They are therefore interchangeable with ® any other AGMA coupling half. The most compact solution due to the exceptional torque transmission capability, SITEX ST couplings are the most compact solution in weight and dimensions for a safe torque transmission. Hub Sleeve Seal Snap ring Grease nipple
www.jbj.co.uk/couplings.html #DriveLineHarmony Model Types ® SITEX ST Gear Couplings 2 Special Model Types Special executions are available for any application need. Accurate finite element analysis can be made for special high demanding applications. Corrosion Protection ® SITEX ST couplings are protected against corrosion with a special surface treatment. Mounting and dismounting are, therefore, guaranteed even after many years of use in difficult environment conditions. GST Type C Standard type with 2 hubs and one sleeve. Allows for axial, angular, and radial misalignment. Long hub version also available. Offers compact, powerful design, and easy assembly. GST Type CV Standard type made of a single hub and one sleeve. It is also available in long hub execution. Offers an economical solution to an application without radial misalignment. GST Type CF Flanged type made of 2 semi couplings. Flanges dimensions are according to AGMA standards (type A-B-C). They will fit any AGMA standard half. SITEX® ST Model Types
www.jbj.co.uk/couplings.html #DriveLineHarmony STC_CL Note: set screw position 90° from the keyway. Ordering Code DH E Fmax M l Type 1Type 2Type 3 Hubs GST 082 M F40 ® SITEX ST Size M: Std hub Bore (mm) ML: Long hub Sleeve GST 082 AD Size AD: std sleeve Setscrews Type 28 70 3 28 40 61 12 41 31 60 85 104 123 600 1200 7700 0,13 2 x 1° 9,8 1,4 38 85 3 38 55 65 17,5 48,5 49 80 100 131,5 163 850 1700 5800 0,13 2 x 1° 22,7 2,2 48 95 3 48 65 82 16,5 56 40,5 80 115 139 163 1300 2600 5100 0,22 2 x 1° 43 3,1 62 120 4 62 85 90 25 68 57 100 140 172 204 2200 4400 4000 0,22 2 x 1° 124 5,7 82 145 4 82 110 96 28,5 74,5 73,5 119,5 153 198 243 3800 7600 3200 0,24 2 x 1° 285 8,8 98 175 5 98 130 113 28,5 82,5 86,0 140 170 227,5 285 7000 14000 2750 0,39 2 x 1° 693 14,6 110 198 6 110 150 130 43 105 112,5 174,5 216 285,5 355 10000 20000 2300 0,48 2 x 1° 1327 23,3 133 230 8 133 180 175 56,5 140 124 207,5 288 355,5 423 15000 30000 2000 0,79 2 x 1° 3260 39,7 155 270 10 155 210 214 58 160 123 225 330 395 460 24000 48000 1650 1,05 2 x 1° 7606 66,5 170 300 10 170 230 240 65 180 130 245 370 435 500 34000 68000 1550 1,31 2 x 1° 13235 94,0 Lt LM LMO1 L1 LMO Dimensions (mm) TKN TKmax Torque (Nm) nmax (min-1) Kr (mm) K *w Moment of inertia -4 2 x10 kg.m W (kg) Coupling** Technical Data Size Type “C” ® SITEX ST Gear Couplings Type 1 Type 2 Type 3 LMO LMO LMO LMO1 LMO1 LMO1 ØM ØDH ØM ØDH ØM ØDH ØF ØP t l l LM Lt E t l LM Lt l ØP E t L1 LM Lt L1 E ØP Standard type with 2 hubs and one sleeve. Allows for axial, angular and radial misalignment. Long hub version is also available. Offers compact, powerful design, and easy assembly. Maximum bore in the table is valid for keyway seat DIN 6885/1. Bore size Ø P t (mm) (mm) (mm) up to 38 M8 14 > 38 - 44 M10 14 > 44 - 50 M12 14 > 50 - 55 M14 14 over 55 M16 14 Floating shaft designs and special executions are available upon request *Maximum static misalignment for a correct mounting. **Considering maximum bore T Coupling nominal torque Nm KN T Coupling maximum torque Nm Kmax W Weight kg ΔK Maximum radial misalignment mm r ΔK Maximum angular misalignment ° w n Maximum rpm min-1 max SITEX ST C execution ® 3
www.jbj.co.uk/couplings.html #DriveLineHarmony Ordering Code TKN TKmax Torque (Nm) nmax (min-1) DK *w Moment of inertia -4 2 x10 kg.m W (kg) Coupling** Technical Data Size Type 1 Type 2 Type 3 LMA LMO ØM1 ØDH t LM Lt E Standard type made of a single hub and one sleeve. It is also available in long hub execution. Offers an economical solution in applications without radial misalignment. Maximum bore in the table is valid for keyway seat DIN 6885/1. *Maximum static misalignment for a correct mounting. **Considering maximum bore T Coupling nominal torque Nm KN T Coupling maximum torque Nm Kmax W Weight kg ΔK Maximum radial misalignment mm r ΔK Maximum angular misalignment ° w n Maximum rpm min-1 max 4 G H l ØM2 ØF Lt LM1 t G1 H LMA1 LMO E l LMA LMO1 E G H t Lt LM L1 t G1 H Lt LM1 L1 LMO1 LMA1 E Type 4 LMA G1 LMA1 Dimensions (mm) Type “CV” ® SITEX ST Gear Couplings DH E Fmax H M1 M2 I LMO L1 LMO1 G t Sleeve GSTV 082 AD F40 Size AD: std hub-sleeve Bore (mm) ADL: long hub-sleeve Hub GST 082 M F40 ® SITEX ST Size M: Std hub Bore (mm) ML: Long hub 28 70 3 28 43 42 40 13 41 32 60 29 41 48 60 14 600 1200 7700 1° 7,1 1,1 38 85 3 38 49 55 55 16 48,5 47,5 80 35 48,5 66,5 80 14 850 1700 5800 1° 17,9 1,9 48 95 3 48 54,5 65 65 18,5 56 42,5 80 42 56 66 80 14 1300 2600 5100 1° 31,5 2,5 62 120 4 62 60 85 85 27 68 59 100 45 60 85 100 14 2200 4400 4000 1° 95 4,7 82 145 4 82 63 110 110 31 74,5 76 119,5 46 61,5 104 119,5 14 3800 7600 3200 1° 212 6,9 98 175 5 98 76 130 130 26 82,5 83,5 140 51 65,5 123,5 138 14 7000 14000 2750 1° 511 11,2 110 198 6 110 92 150 150 38 105 107,5 174,5 71 90 143 162 14 10000 20000 2300 1° 1080 19 SITEX® ST CV execution
www.jbj.co.uk/couplings.html #DriveLineHarmony Ordering Code Type A Type B Type C STCF A-B-C range conforms to AGMA specifications with regard to flange dimensions, type, and positions of the screws. They are interchangeable with any AGMA coupling half. T Coupling nominal torque Nm KN T Coupling maximum torque Nm Kmax W Weight kg ΔK Maximum radial misalignment mm r ΔK Maximum angular misalignment ° w n Maximum rpm min-1 max 5 ØDH Type “CF” A-B-C (AGMA) ® SITEX ST Gear Couplings ØDMA ØM ØFmax LMO LMO E1 G G LMA Lt LMO LMO E2 Lt l l LMO LMO E3 Lt l Size Dimensions (mm) Technical data Fmax (mm) DH DMA M LMO LMA G* Type A Type B Type C Torque (Nm) max -1 (min ) Kw Kr l LtE1 l LtE2 l Lt E3 TKN TKmax Type A** Moment of inertia -4 2 x10 kg.m W (kg) (mm) 48 48 117 83 65 43 42 74 55 89 3 55 98 12 55 107 21 1300 2600 5100 2 x 0,5° 0,48 53 3,1 62 62 152 107 85 50 48 84 59 103 3 59 109 9 59 115 15 2200 4400 4000 2 x 0,5° 0,51 193 6,6 82 82 178 129,5 110 62 59 104 79 127 3 79 141 17 79 155 31 3800 7600 3200 2 x 0,5° 0,69 423 10,6 98 98 213 156 130 76 69 123 93 157 5 93 169 17 93 181 29 7000 14000 2750 2 x 0,5° 0,81 1009 17,5 110 110 240 181 150 90 82 148 109 185 5 109 199 19 109 213 33 10000 20000 2300 2 x 0,5° 0,95 1822 25,3 133 133 280 211 180 105 98 172 128 216 6 128 233 23 128 250 40 15000 30000 2000 2 x 0,5° 1,12 4257 42,5 155 155 318 249,5 210 120 107 192 144 246 6 144 264 24 144 282 42 24000 48000 1650 2 x 0,5° 1,26 7920 61,4 170 170 347 274 230 135 120 216 164 278 8 164 299 29 164 320 50 34000 68000 1550 2 x 0,5° 1,43 11132 75,6 *Maximum static misalignment for a correct mounting. **Considering maximum bore. Maximum static misalignment for a correct mounting ΔKw = 2 x 1° Floating shaft designs and special executions are available upon request. Flanges (2 pcs for coupling) GST F 082 AD SITEX® ST CF Execution Size Flange Set of screw (1 kit for coupling) GST F 082 KIT SITEX® ST CF Execution Size set of screws Hubs (2 pcs for coupling) GST F 082 M F40 SITEX® ST CF Execution Size Hub Bore (mm) Special execution with intermediate shaft
www.jbj.co.uk/couplings.html #DriveLineHarmony Size Dimensions (mm) Technical data Type D Type E Type F Torque (Nm) DKW Lt E1 TKN TKmax Type A** Moment of inertia -4 2 x10 kg.m W (kg) Lt E2 Lt E3 nmax -1 (min ) Fmax (mm) DMA DH M LMO G* Double-cardanic crowned gear coupling. Allows for axial, angular, and radial shaft misalignment. ØDH Type “CF” D-E-F ® SITEX ST Gear Couplings ØDMA ØFmax LMO LMO E1 G G Lt l ØM Lt Lt E2 E3 Type E Type F *Maximum static misalignment for a correct mounting. **Considering maximum bore. Maximum static misalignment for a correct mounting ΔKw = 2 x 1° Seal flange sizes from 325 to 475. T Coupling nominal torque Nm KN T Coupling maximum torque Nm Kmax W Weight kg ΔK Maximum radial misalignment mm r ΔK Maximum angular misalignment ° w n Maximum rpm min-1 max Special execution with intermediate shaft 6 Ordering Code Type D GST 75 F40 GST: SITEX® ST coupling Size F...: hub bore 1 end execution (mm) Coupling L F50 L: long hub F...: hub bore 2 end execution (mm) “CF” execution type D FD 50 50 111 82,5 69 43 58 89 3 91 5 93 7 1800 4200 6000 2 x 0,5° 50 4 60 60 142 104,5 85 50 68 103 3 108 8 113 13 2700 6400 4620 2 x 0,5° 120 8 75 75 168 130,5 107 62 87 127 3 138 14 149 25 5500 13000 4140 2 x 0,5° 320 13 95 95 200 158,5 133 76 95 157 5 164 12 171 19 8600 21000 4000 2 x 0,5° 850 26 110 110 225 183,5 152 90 120 185 5 204 24 223 43 13500 34000 3860 2 x 0,5° 1620 37 130 130 265 211,5 178 105 130 216 6 237 27 258 48 22200 54000 3720 2 x 0,5° 3760 59 155 155 300 245,5 209 120 135 246 6 272 32 298 58 34200 83000 3190 2 x 0,5° 7280 91 170 170 330 275 234 135 155 278 8 307 37 336 66 43500 101000 2900 2 x 0,5° 12260 123 190 190 370 307 254 150 195 308 8 350 50 392 92 69200 156000 2570 2 x 0,5° 20990 170 210 210 406 335 279 175 220 358 8 403 53 448 98 82500 196000 2330 2 x 0,5° 34010 234 230 230 438 367 305 190 236 388 8 438 58 488 108 150500 349000 2150 2 x 0,5° 50520 295 280 280 505 423 355 220 273 450 10 512 72 574 134 198200 480000 1800 2 x 0,5° 103200 455 325 325 580 475 400 250 - 512 12 - - - - 275000 551000 1200 2 x 0,5° 206000 685 370 370 630 520 450 275 - 562 12 - - - - 381000 762000 980 2 x 0,5° 335000 920 400 400 700 556 490 305 - 622 12 - - - - 492000 984000 900 2 x 0,5° 533000 1210 430 430 760 615 550 330 - 672 12 - - - - 658000 1315000 800 2 x 0,5° 835000 1590 475 475 825 680 580 355 - 722 12 - - - - 835000 1669000 700 2 x 0,5° 128400 2060
www.jbj.co.uk/couplings.html #DriveLineHarmony Coupling Selection ® SITEX ST Gear Couplings 7 1) Select the coupling according to the largest shaft diameter 2) Calculate the nominal torque TN to be transmitted: TN = 9550 P n With P = nominal power installed (kW), n = rpm in the drive (1/min) 3) Select the correct service factors k1 and k2 4) Verify the nominal torque of the coupling is greater than the corrected machine nominal torque: Tkn ≥ TN ∙ k1 ∙ k2 With k1 application service factor and k2 angular misalignment (per hub) service factor. 5) Verify the machine peak or starting torque Ts is lower than the coupling maximum torque T . kmax 6) Verify the maximum misalignments are respected. 7) Verify the hub shaft connection could bear the transmission peak torque. If necessary change the hub shaft connection type. 8) Verify the maximum RPM of the coupling is respected. Application service factor k1 Hydraulic motors, gears drivers Electrical generators Centrifugal pumps and compressors Light fans, escalators, belt and chain conveyors. Multistage centrifugal blowers, Steel wire machine Reciprocating pumps, Large fans, Agitators (liquids) Machine tools main drive Conveyor and elevators not uniform loaded. Reciprocating compressors and pumps Cranes, Agitators (solids) Hoisting equipment, Calenders for rubber or plastic Winding machine (paper industry). Laundry machines, Mixers for rubber and plastic Road and rail machines/equipment, Cranes ( heavy duty) Pulp grinders and refiners, paper presses Marine drives, mine fans, Wire drawing, Metal mills drives Heavy duty drives in steel mills, Hammer mills, rubber and plastic mills, Stone crushers. Continuous duty without overloads, occasional starts up. Continuous duty with light overloads and shocks for a short time and not frequent. Intermittent duty with frequent light shocks, medium overloads (short time). Duty with very high and frequent shocks, frequent load reversal. Load Type Type of Service Application Driven Machine Driver machine Reciprocating engine electric motors frequent starts UNIFORM 1 1,25 1,5 LIGHT peak torque 1,4 1,75 2 MEDIUM peak torque 1,75 2 2,5 HEAVY peak torque 2 2,5 3 0 0,1 0,2 0,3 0,4 0,5 0,6 0,7 0,8 0,9 1 0,0 0,1 0,2 0,3 0,4 0,5 0,6 0,7 0,8 0,9 1,0 Angular misalignement Kd [] ° Service factor k2 n= 0,06 • nmax n = 0,10 • nmax n = 0,16 • nmax n = 0,25 • nmax n = 0,45 • nmax n = 0,65 • nmax n = n max Service factor k2 for angular misalignment Angular misalignment ± (°) Electric motors or turbines Hydraulic motors, gears drivers
www.jbj.co.uk/couplings.html #DriveLineHarmony Installation and Maintenance Good alignment of the shafts help to reduce reaction forces on shafts and bearing and is important for the coupling life. In case the hubs are machined by the user in order to adapt them to the machine, it is user responsibility: » to control all parameters regarding balancing, bore concentricity and any other parameter which may affect coupling life and a safe transmission, are respected. » to verify the hub length and corresponding keyway seat are compatible with the necessary toque transmission considering the peak loads. Maximum bore diameters allowed in hubs as described in dimensional tables. » to verify the hub material is adequate for the clamping system. During compensation of misalignments, axial forces are generated. These forces must be considered when sizing machine bearing. For a calculation, please consult our technical office. It is also recommended that hubs are axially secured in order to avoid axial forces on the seals which may cause lubricant leakage and, therefore, shorter coupling life. It is recommended to secure the set screw with Loctite, use an end plate, or interference fit. Warning Gear couplings are rotating parts and potentially dangerous. It is recommended to protect the rotating parts and comply with existing safety regulations in order to keep personnel and equipment safe. Mounting SITEX® ST couplings must be stored in a non-corrosive environment prior to installation. In case of environments with high humidity it is the user’s, responsibility to protect the couplings, or to ask for a special surface treatment. Prior to starting the mounting operation, it is recommended to: » verify there are no missing or damaged components » have the necessary mounting instructions and tools required for mounting and shaft alignment. » make sure the machine is shut down and there is no risk of accidental start up » be careful in handling the coupling components. Particular care should be taken with the geared crown. 1) Check all components to be assembled are clean. 2) Position one snap ring and one seal on every shaft. 3) Position the hubs on the respective shafts. If necessary in order to facilitate the mounting operation, it is possible to heat the hubs (max. 120 °C). In such cases avoid contact between hub and seal until room temperature is reached. For a safe mounting hub must be positioned flush with the shaft. Mount the set screws and tighten properly. In order to avoid accidental screws loosening due to vibration, use some Loctite glue. 4) Mount the sleeve on the longer shaft. 5) Position the units to be connected respecting the dimension“E” between the shafts. 6) Align the 2 shafts being careful that the catalogue values are respected. It is possible to use the SIT LINE-LASER® to facilitate the operation. 7) Couplings are delivered without lubricant. Lightly grease the geared parts of hubs and sleeve. Lightly lubricate the seal and position them on the respective hubs. 8) Position the sleeve on the hubs. Insert the seals and the snap rings on the proper groove. 9) Remove the grease nipple and properly fill the chamber with grease. For the CF type, repeat the operation on the second half coupling. Position the grease nipple and tighten properly. Inspect and maintain. It is recommended to make a regular inspection which may detect abnormal noise, vibration, or leakage. Every 5.000 hours, or once a year, remove grease nipples, position the coupling with one nipple at 45° with respect to the rotation axis, force grease from the bottom hole until clean grease flows. Reinsert the nipples and tighten properly. Every 10.000 hours or every 2 years, remove snap rings and seals, clean and inspect seals and geared parts, verify alignments and mount the coupling. Low viscosity oil may be used to clean the coupling from used grease. Installation and Maintenance ® SITEX ST Gear Couplings 8
www.jbj.co.uk/couplings.html #DriveLineHarmony Recommended lubricants Coupling lubrication is important for a long coupling duration. 1. Standard speed and load Agip GR MV/EP 1 Amoco coupling grease API: API grease PGX-0 Caltex Coupling Grease Castrol Impervia MDX Chevron Polyurea grease EP0 Esso Fibrax 370 Fina Marson EPL 1 Kübler Klüberplex GE 11-680 IP: ATHESIA-EPO Mobil Mobilux EP0, Mobilgrease XTC Q8 Rembrandt EP0 Shell Alvania grease EP R-0 or EP 1 Albida GC Texaco Coupling Grease Total Specis EPG Tribol 3020/1000-1 Unirex RS 460, Pen-0- Led EP 2. High speed (> 50 m/s), high loads Caltex Coupling Grease Klüber Klüberplex GE 11-680 Mobil Mobilgrease XTC Shell Albida GC1. Installation and Maintenance ® SITEX ST Gear Couplings 9
www.jbj.co.uk/couplings.html #DriveLineHarmony ® JUBOFLEX Couplings One elastic element made of pre-compressed, natural rubber, reinforced with steel to be fitted with fixing screws and a metallic band (to be removed after mounting) and two metallic hubs made of forged steel (size 120 produced in cast iron). ® They are also available for mounting with SER-SIT taper bushing from size 4 to 25; solid hub from size 35 to 120. Brass Couplings Hubs made in brass and spider in rubber. Suitable for low power. ® TRASCO Spider Couplings The flexible and omocinetic coupling that assures the best performance in relation to the physical space occupied in its class. It has a very compact design and allows safe power transmission by absorbing peak loads and torsional vibrations. The elastomeric design of the polyurethane gear ring compensates for angular, radial and axial misalignments. ® METALDRIVE Disc Couplings Made of steel and are used in all applications where high reliability, precision, and no maintenance are required. ® All the components of the METALDRIVE couplings are completely machined (spacer excluded) and balanced in class DIN ISO 1940-1 Q 6,3. ® TRASCO ES Spider Couplings » “Zero-backlash” motion transmission. » Dampening (up to 80%) of vibrations from motor shaft. » Low heat and electrical conductivity. » Easy and fast installation. » Perfect balance (A & AP type). » Low moment of inertia (due to compact design and types of materials used). ® SITEX Gear Couplings Two steel gear hubs, connected with one internally toothed sleeve of stabilized 6.6 super polyamide resin. ® ® SITEX NYLEX couplings are made of 100% Polyamide. Designed for light applications, low cost and available with finished bore keyway and thread for set screw. ® The SITEX FL couplings are designed to optimize the connections between diesel engines and driven equipment such as hydraulic pumps. * Summary Mechanical Power Transmission Couplings
www.jbj.co.uk/couplings.html #DriveLineHarmony Bolt Couplings The bolt coupling is a rigid coupling. It is made of two halves, which are cast iron grade GG25 connected by means of bolts. It is maintenance and lubrication free. Additionally, its construction prevents fretting corrosion and allows for easy mounting and dismounting. The bolt coupling is designed to connect horizontal shafts with similar diameters. For different applications please contact our technical department. Universal Joints High precision universal joint, manufactured according to DIN 808/7551. Every model type is made of 2 hubs with forks and a central block. Between pins and bores there are: » P series: 4 bearings with solid pins. » E series: with sliding bushes. » H series: with needle roller bearings. ® SITEX ST Couplings Fully manufactured in high quality steel. They are made of 1 or 2 geared hubs which are coupled with one sleeve through which the torque is transmitted. The special OPTIGEAR profile allows very high torque transmission and the compensation of axial, angular and radial misalignment (only in the version with 2 hubs). The maximum recommended working temperature is -10°C a + 80 °C. ® SAFEMAX Torque Limiters Prevents damage to machinery happening through instant disengagement of the motor side from the driven side in case of torque overload, thus eliminating the risk of expensive downtime. In addition, these torque limiters, being torsionally rigid and backlash free, allow a rapid and accurate resumption of machine operations once the cause of the overload has been eliminated. ® SERVOPLUS Bellows Couplings An innovative modular type coupling perfect in all servo motor applications where high torsional rigidity, backlash free torque transmission, low inertia, and superior reliability are required. Wear and maintenance free. Working temperature up to 300°C. ® SERVOMATE Disc Couplings Specially designed for servomotor applications. The aluminum hubs and the compact design provide low mass moment of inertia resulting in a reliable and maintenance free coupling for high speeds. The double disk pack execution has been designed for applications where radial misalignment exists. * Summary Mechanical Power Transmission Couplings ALL IMAGES ARE LINKS
Getting the most out of your machinery often depends on close integration between all components. An organisation that manufactures and integrates all the diverse components of a drivetrain provides the experience to help you select the best component combination for your application. jbj Techniques’ in-house design team and manufacturing facility provide tailored solutions for your applications at competitive prices with quick delivery. The following examples are a simplistic view of how jbj Techniques assists customers. Hydraulic Adaptors Designed primarily to allow the close coupling of hydraulic pumps to a variety of prime movers, such as diesel / petrol engines, electric, air or hydraulic motors, they can also be used in the connection from prime mover to alternative driven parts i.e. gear boxes, generators, water or vacuum pumps etc. An additional range of engine front PTO adaptors, which provide additional connection between the engine pulley and the driven part are also available. The kit comprises of a and flexible bellhousing drive that are fully machined to suit the coupling driving and driven components. These can be to suit either shaft to shaft, flange (flywheel) to shaft or even flange to flange connections. Getting the most out of your equipment will demand close integration between all components. In specifying jbj Techniques as your preferred supplier, you will have selected a company with the experience to specify, manufacture and integrate all of the diverse components that will ensure the best component combination for your application. jbj's in house design team and manufacturing facility provide tailored solutions for your applications at competitive pricing and on-time deliveries. Pump shaft alignment is key to preventing unnecessary wear and damage to the pump shaft seal and bearing. Improper alignment may lead to premature pump failure. Also to be considered are unwanted torsional resonant frequencies in the system which can quickly cause damage to components in the drivetrain and reduce system life and performance. Improper pump installation can lead to premature failure, increased maintenance costs and reduced production levels of final product. jbj Techniques can advise on the correct installation of into Industrial / hydraulic pumps mobile / marine / machine tool / agricultural / offshore industries and can specify complete driveline systems from their extensive range of components which are available from stock or manufactured to order, albeit simple or complex, standard or bespoke. Electric Motor – Hydraulic Pump Adaptors (safe area) jbj Techniques Limited offer the most comprehensive range of in Europe. bellhousings Designed to connect electric motors with frame size IEC D56 - D400 (0.06kW – 750kW) and can be compatible with electric motor 'B5' or 'B14' flange configurations. Accompanying the metric frame units above is a complete range of mountings to suit Nema and imperial frame motors with 'C' face or 'D' flange fitments. With fully machined , torsionally flexible couplings or available, jbj ensure torsionally rigid couplings the most suitable combination is selected for the application in hand. As an example spider couplings are available in various materials including aluminium, grey cast iron, nodular iron, steel and stainless steels and can be finish machined with parallel, taper or splined bores to DIN, SAE, ANSI or ISO standards. Bellhousings can be manufactured in aluminium or cast iron material as standard, however, units can be produced in a variety of exotic materials on request. The aluminium product range is produced in either monoblock or composite formats giving great flexibility in design and allows for early delivery time, often with same or next day delivery possibilities. For applications where low noise levels are a quality products for mechanical & fluid power #DriveLineHarmony www.jbj.co.uk an excellence in engineering
ensuring a continuing high quality service in which customers can have complete confidence. “ “ requirement then a complete range of antivibration and noise reduction components add to the range. Electric motor – Hydraulic Pump Adaptors (hazardous area) Designed to meet the exacting safety standards of the offshore and chemical process industries, jbj Techniques produce certificated to adaptor kits Directive 2014/34/EU II2GD-IM2-TX -50 C< Service Temp < +105 C. Harmonised standards BS EN 1127:1, BS EN 13463:1, BS EN13463:5, BS EN 50303, BS EN 1834-1,BS EN 1834-3. Generally manufactured in Cast or Nodular iron, bellhousings can be produced in steel, stainless steel or alternative exotic materials on customer request. Couplings supplied for these applications are the jbj Techniques 'JXL' pin and bush range which provide an anti-static and flameproof drive which meet zone 1 area requirements, conforming to all of the above standards. Also available are spider and gear couplings which are certified to zone 2 standards. (Contact jbj Techniques for details). An important development of equipment for use within hazardous areas is the wet mount series of bellhousings. Commissioned to research and develop a product that would control the high temperature generated by a piston pump shaft seal when working within cycling applications. A little considered issue is the frictional heat generated at the shaft seal when the application requires the pump to cycle between different pressures causing the seal temperature to increase. This process will often take the seal temperature out and above the levels required by the relevant ATEX standards requirement. This specially designed assembly allows a pumped cooling flow to be passed over the seal face and through an auxiliary cooler, this in turn reduces the seal face temperature which can be maintained at an acceptable level. With a vast array of components to select from, jbj are well placed to provide all required components to support the required cooling system. Diesel Engine – Hydraulic Pump Adaptors A complete range of bellhousing and couplings exist for the connection of a diesel engine flywheel to a specified driven component, be it an oil hydraulic pump, water pump, generator or similar device. With the bellhousing available in various materials to suit all application areas. With a standard range to connect Diesel engines with SAE dimensions from SAE '6' to SAE '0' jbj are well placed to satisfy the majority of customer requirements. Couplings to complete the assembly are available in either torsionally flexible or torsionally rigid design ad can be supplied to suit SAE flywheel dimensions from SAE 6.5” to SAE 18”. For hydraulic pumps to be mounted to engines that do not conform to SAE dimensions, we offer a full range of assembly parts, some of which (but not all) are shown here » for diesel engines All bellhousings within this range can be finished machined to accept any, piston, vane or gear pump interfaces requested by customer. As with the electric motor range of product jbj offer complete solutions for ATEX environments, using our well proven 'JXL' coupling range which has standard design to connect to the engine flywheel. Directive 2014/34/EU II2GD-IM2-TX -50°C ≤ Service Temp ≤ +105°C. Harmonised Standards: BS EN 1127:1 BS EN 13463:1 BS EN 13463:5 BS EN 50303. Petrol Engine – Hydraulic Pump Adaptors Petrol engine adaptors have been developed for use with industrial petrol engines. Design exists to suit Honda, Briggs and Stratton, Kawasaki, Kubota, Hatz, Mag, Robin, Suzuki, Winsconsin, to name but a few, all adaptors can be finished to accept most hydraulic pumps. Adaptors to suit engine crankshaft drives and for vertical mounting are available on request. #DriveLineHarmony www.jbj.co.ukl to Large Combinations Small Individual Components
Anti-Static/Flameproof Couplings Torque Limiting Couplings Torsional Couplings Screw Pumps Low Noise Helical Gear Pumps Gear Pumps/Gear Motors Pressure Intensifiers Flow Dividers Mini Power Packs Electromagnetic Clutches & Brakes BDS Clutches Coolers/Heat Exchangers Bellhousings Spider/Jaw Couplings Gear Couplings Fillers/Breathers/Filters Flame Proof Option Level Indicators Tanks/Reservoirs/Accessories www.jbj.co.uk/ .html productlist
Thermostatic Valves & Controls Torsionally Highly Flexible Couplings Torsionally Flexible Couplings Torsionally Rigid Couplings Planetary Gearboxes Multiple PTOs/Splitter Gearboxes Hydraulic Power Take-off Units Vane Pumps LSHT Motors/Hydraulic Geared Motors Pneumatic Starters & Motors Mechanical Power Take-off Units Oil Bath Clutches BD Clutches & Gearboxes Engine Adaptor Kits Dampers Bearing Supported Stub Shafts Quick Maintenance ‘QM’ Flange Flanges www.jbj.co.uk/ .html productlist
jbj Techniques Limited 28 Trowers Way Holmethorpe Industrial Estate Redhill Surrey RH1 2LW. UNITED KINGDOM 01737 767493 info@jbj.co.uk www.jbj.co.uk quality products for mechanical & fluid power You Tube registered in England No: 1185469 jbj Techniques Limited is ISO certificated, committed to international coordination & unification of industrial standards. A range of products ATEX certificated to directive 94/9/EC requirements set by James Harris, jbj Techniques Limited
