Pipe Flanges SAE - T Connection Hochdruckfl nsche Type Connection A Connection B Connection C G L Weight kg Size A 1 M Size A2 Size A3 T 301 A-301 G-301 G 1/ 2" 30.2 M8 x 30 1/ 2" 30.2 1/ 2" 30.2 133 67 0.97 T 302 A-302 G-302 G 3/ 4" 38.1 M10 x 35 3/ 4" 38.1 3/ 4" 38.1 160 80 1.20 T 302 A-302 G-302 G 3/ 4" 38.1 M10 x 35 3/ 4" 38.1 3/ 4" 38.2 160 67 1.14 T 303 A-303 G-303 G 1" 44.4 M10 x 35 1" 44.4 1" 44.4 177 88 1.63 T 303 A-303 G-302 G 1" 44.4 M10 x 35 1" 44.4 3/ 4" 38.1 177 80 1.50 T 303 A-303 G-301 G 1" 44.4 M10 x 35 1" 44.4 1/ 2" 30.2 177 67 1.39 T 304 A-304 G-304 G 11/ 4" 50.8 M10 x 30 11/ 4" 50.8 11/ 4" 50.8 208 103 2.25 T 304 A-304 G-303 G 11/ 4" 50.8 M10 x 30 11/ 4" 50.8 1" 44.4 208 88 2.05 T 304 A-304 G-302 G 11/ 4" 50.8 M10 x 30 11/ 4" 50.8 3/ 4" 38.1 208 80 1.94 T 305 A-305 G-305 G 11/ 2" 60.3 M12 x 35 11/ 2" 60.3 11/ 2" 60.3 230 114 3.50 T 305 A-305 G-304 G 11/ 2" 60.3 M12 x 35 11/ 2" 60.3 11/ 4" 50.8 230 103 3.03 T 305 A-305 G-303 G 11/ 2" 60.3 M12 x 35 11/ 2" 60.3 1" 44.4 230 88 2.94 T 306 A-306 G-306 G 2" 71.4 M12 x 35 2" 71.4 2" 71.4 244 122 4.20 T 306 A-306 G-305 G 2" 71.4 M12 x 35 2" 71.4 11/ 2" 60.3 244 118 4.05 T 306 A-306 G-304 G 2" 71.4 M12 x 35 2" 71.4 11/ 4" 50.8 244 115 3.87 T 307 A-307 G-307 G 21/ 2" 84.1 M12 x 40 21/ 2" 84.1 21/ 2" 84.1 270 135 4.70 T 307 A-307 G-306 G 21/ 2" 84.1 M12 x 40 21/ 2" 84.1 2" 74.1 270 128 4.30 T 307 A-307 G-305 G 21/ 2" 84.1 M12 x 40 21/ 2" 84.1 11/ 2" 60.3 270 125 4.10 T 308 A-308 G-308 G 3" 101.6 M16 x 50 3" 101.6 3" 101.6 293 146 8.20 T 308 A-308 G-307 G 3" 101.6 M16 x 50 3" 101.6 21/ 2" 84.1 293 141 7.50 T 308 A-308 G-306 G 3" 101.6 M16 x 50 3" 101.6 2" 71.4 293 133 7.20 T 309 A-309 G-309 G 31/ 2" 114.3 M16 x 50 31/ 2" 114.3 31/ 2" 114.3 293 146 9.55 T 309 A-309 G-308 G 31/ 2" 114.3 M16 x 50 31/ 2" 114.3 3" 101.6 293 146 9.20 T 309 A-309 G-307 G 31/ 2" 114.3 M16 x 50 31/ 2" 114.3 21/ 2" 84.1 293 146 8.50 T 310 A-310 G-310 G 4" 127.0 M16 x 50 4" 127.0 4" 127.0 332 165 12.10 T 310 A-310 G-309 G 4" 127.0 M16 x 50 4" 127.0 31/ 2" 114.3 332 158 11.60 T 310 A-310 G-308 G 4" 127.0 M16 x 50 4" 127.0 3" 101.6 332 158 10.95 T 311 A-311 G-311 G 5" 152.4 M16 x 50 5" 152.4 5" 152.4 370 185 14.70 T 311 A-311 G-310 G 5" 152.4 M16 x 50 5" 152.4 4" 127.0 370 177 13.95 T 311 A-311 G-309 G 5" 152.4 M16 x 50 5" 152.4 31/ 2" 114.3 370 170 13.10 63 Material: ST37/ST52.....................................carbon steel ordering code: T-connection only T-... All connections can be supplied as shown with o-ring grooves (type A) or without o-ring grooves (type C)
