GHM Series Gear Motors The GHM series offer identical configurations to the ALM series but more robust thanks to the cast iron front flange and rear cover. ALM Series Gear Motors For medium to high pressure rates the ALM series is ideal for mobile and industrial sectors. Mono-directional and bi-directional with internal and external drain available. ALPC/GHPC Series Short Multiple Gear Pumps For reduced axial layout. Available with both flanges and covers in aluminium or cast iron. High production rates, performance consistency and absolute reliability ensure this a benchmark product for the hydraulic power pack market. 1P Series Gear Pumps Extensive range and very high performance of these pumps integrated in to micro power packs make them ideal for many applications from aerospace to marine, medical to automotive. 0.25 - 0.5 Series Micro Gear Pumps This product range includes pumps of displacements (up to 200cc/rev) in a full aluminium configuration, able to withstand medium to high pressures and using different versions of flanges (European, German and SAE), porting and shafts. Mono-directional as well as reversible. ALP Series Gear Pumps The GHP series offer identical configurations to theALP series and guarantees extreme reliability in very high pressure applications. Ideal for mobile applications from agricultural to construction machines as the cast iron allows more flange, cover and port options. GHP Series Gear Pumps Modularity and flexibility are the characteristics of these pumps. They allow the assembly of pump modules of the ALP and GHP (from 0.25 to 4) enabling solutions to a wide range of application requirements. Ideal pump for applications which require a fast approach and/or return of the actuator at low loads and slow motion of the actuator at high loads. e.g. log splitters, compactors & presses. Volumetric andmechanical efficiencies as well as low noise levels are further benefits of this range. High/Low 2-Pass Gear Pumps ALP/GHP Series Multiple Modular Gear Pumps ELIKA® The low noise, low pulsation helical gear pump. Groups 2, 3, 4 and multiple pumps. Reduces the noise level by up to 20 dBA. www.jbj.co.uk/gear-pumps.html #DriveLineHarmony 01737 767493 info@jbj.co.uk www.jbj.co.uk - registered in England No: 1185469 - jbj Techniques Limited is ISO certificated, committed to international coordination & unification of industrial standards. A range of products ATEX certificated to directive 94/9/E requirements jbj Techniques Limited, UK distributor for www.jbj.co.uk/ .html gear-pumps 5
Gear Pumps Basic Design External gear pumps are the most popular pumps used in modern hydraulic systems. They feature versatility, strength and long useful life. Their simple construction ensures limited purchase costs and servicing. Thanks to these basic concepts, together with ever improving product design and features, research based on many years of experience, accuracy in material selection, production process followed in great detail and tests onmass-produced parts, our gear pumps have reached top quality standards. For this reason, our products can work under heavy duty operating conditions and transmit high hydraulic power. Furthermore, these hydraulic gear pumps feature good hydraulic, mechanical and volumetric efficiency, low noise level and, last but not least, compact dimensions and lowweight/power ratio. Marzocchi Pompe thus specialized their production in low-power oil-operated pumps for auxiliary services. This product is called 1P and it is widely used in power units. 0.25 and 0.5 micro gear pumps usually consists of a gear pair supported by two aluminum bushes, a body, a securing flange and a cover. Shaft of the driving gear projecting beyond the flange mounts a twin-lip seal ring (the inner lip being a seal and the outer being a dust seal). An elastic securing ring secures the ring in place. Pump body, flange and cover are made of special hi-resistant aluminum alloys for minimized deformation even when subject to high pressure, be it continuous or intermittent or peak pressure. The body is profiled by means of extrusion, whereas flange and cover are obtained by means of die-casting or gravity casting. Gears are made of special steel. Their manufacturing process includes case-hardening and quench hardening. Then gears are ground and fine finished so to have a high degree of surface finishing. Proper tooth profile design and geometric proportions ensure low pulsation levels and low noise levels during pump operation. Bushings are made of special low-friction and hi-resistant aluminum alloy and manufactured from die-casting. They are equipped with antifriction DU bearings (except for ALP1 pumps). Special compensation zones onto bushings, insulated by special preformed seals with antiextrusion ring, allow fully free axial and radial movement to the bushings, which is proportional to pump operating pressure. In this way, internal dripping is BASIC PUMP PARTS 1 - Drive Gear 2 - Driven gear 3 - Bushings 4 - Body 5 - Flange 6 - Cover 7 - Rotary shaft seal 8 - Compensation seals 9 - Anti-extrusion seals - Stop ring 10 6 www.jbj.co.uk/gear-pumps.html #DriveLineHarmony 1 9 8 6 3 4 2 3 9 8 5 7 10
Marzocchi gear micropumps are available in two different groups: 0.25 and 0.5, they differ only for the tooth profile. Different pump displacements within each group can be obtained by changing the thickness of the gear toothed band. Within the same group, different flanges, shafts, inlet and pressure ports are available. The following items are also available: - micropumps suitable for high pressure applications; - bi-rotational micropumps; - micropumps with check valves; - modular multiplemicropumps. Available displacements are indicated below: Gear Pumps Micro 0.25 & 0.5 Series Product Range 7 Special Versions The following 1Pmodels for special uses are available: V” - Version suitable for fluid hi-temperature applications. Range between –10°C and +120°Cwith P1, P2 and P3 as per product table. Range until +150°Cwithmax. pressure = 20 bar (please indicate actual values when ordering). “ST” - Version suitable for fluid at hi- or low-temperature applications. Range between –40°C and +120°C. “TR” - Version suitable for inlet pressure up tomax. 6 bar absolute. Contact jbj Techniques technical office for assistance in selection of correct pump for your application, telephone: +44 (0)1737 767493, email: info@jbj.co.uk As far as special versions are concerned, Marzocchi Pompe’s thirty-years experience in designing, developing and manufacturing mechanical micro fuel pumps, micro-pumps and integrated systems for "Racing" and "Automotive" applications will stand you in good stead. www.jbj.co.uk/gear-pumps.html #DriveLineHarmony 0 0,2 0,4 0,6 0,8 1,0 1,2 1,4 1,6 0,19 0,26 0,32 0,38 0,51 0,64 0.25 0,50 0,63 0,88 1,00 1,25 1,50 0.5
It is essential for correct running, top performance and longer life of the ALP series hydraulic gear pumps to follow the installation and running information provided in this catalogue. Some general considerations should be made regarding the hydraulic system, in which the pump is to be fitted. Special attention should be given to hydraulic system design and assembly, especially to intake, delivery, return and drain pipes and position of system parts (valves, filters, tanks, heat exchangers and accumulators). Proper safety devices and reliable instruments to avoid fluid turbulence and prevent air, water or foreign bodies from entering into the system are of major importance. It is also very important to equip the hydraulic systemwith a proper filtering unit. InstallationNotes Before starting the systemon a continuous basis, we suggest to adopt some simple precautions. In the case of amono-directional motor check for the direction of rotation of the pump to be consistent with the drive shaft (in case of single rotation pump). Check for the proper alignment of pump shaft andmotor shaft. It is necessary that the connection does not induce axial or radial loads. Protect drive shaft seal during pump painting. Check if contact area between seal ring and shaft is clean: dust could cause quicker wear and leakage. Remove all dirt, particles and all foreign bodies from flanges connecting inlet and delivery ports. Ensure that intake and return pipes ends are always below fluid level and as far fromeach other as possible. Install the pump below head if possible. Fill the pump with fluid, and turn it by hand. Disconnect pump drain during startup to bleed air off the circuit. At first startup, set pressure limiting valves at min. value possible. Avoid lower rotation speed thanmin. allowed with pressure higher than P1. Do not start the systemat low temperatures under load conditions or after long stops (always avoid or limit load starting for pump longer life). Start the system for a fewminutes and turn on all components; bleed air off the circuit to check its proper filling. Check fluid level in the tank after loading all components. At last, gradually increase pressure, continuously check fluid and moving parts temperature, check rotation speed until you reach set operating values that shall be within the limits indicated in this catalogue. CleaningAnd Filtering The System It is widely known that most pump early failures are due to contaminated fluids. The extreme reduction of the tolerances required in the design of the pumps, and therefore their operation with minimum clearances, are heavily influenced by a fluid that is not perfectly clean. It is proved that particles circulating in the fluid act as abrasive agents, damaging the surfaces they touch and increasing the quantity of contaminant. For this reason, ensure that system is perfectly clean during startup and keep it clean for its whole operating life. Regular checks should be made for contamination of the oil. Preventive actions include: proper cleaning of the system during assembly, deburring, eliminating the welding scumand fluid filtering before filling up. Starting contamination level of system fluid should not exceed class 18/15 (ref. ISO 4406). Even fresh fluids might exceed this contamination level; therefore Gear Pumps Micro Series Installation and Running Information 8 www.jbj.co.uk/gear-pumps.html #DriveLineHarmony
Gear Pumps Micro Series Installation and Running Information 9 always pre-filter the fluid when filling up or topping up the system. Fit a proper tank; its capacity should be proportional to the volume displaced in one working minute. Fluid contamination levels should be monitored by use of correct filter types. Two parameters tell which filter is most suitable: absolute filtering power and b filtering ratio. Low absolute filtering power and high b filtering ratio for small particles help ensuring good filtration. It is then very important to limit not only the size of particulate, but also the number of smaller particles that pass through the filter. It goes without saying that with an operating pressure increase and according to the system sophistication degree, filtering should becomemore andmore efficient. The filtering system shall always ensure contamination levels not exceeding the values indicated below: Pressure <140 bar 140 to 210 bar >210 bar NAS 1638 Class 10 9 8 ISO4406 Class 19/16 18/15 17/14 Ratio bx = 75 25-40 μm 12-15 μm 6 -12 μm It is recommended to use a filtering systemhaving absolute filtering capability of 5 μmor lower in the systems using sophisticated valve slaves. Hydraulic Fluids Use specific mineral oil based hydraulic fluids of good anti-wear, anti-foaming (rapid deaeration), antioxidant, anti-corrosion and lubricating properties. Fluids should also comply with DIN 51525 and VDMA24317 standards and compliant with 11th stage of FZG test. For the standardmodels, the temperature of the fluid should be between -10°C and +80°C. Fluid kinematic viscosity ranges are of following: allowed value (upon verification) 6 to 500 cSt recommended value 10 to 100 cSt value allowed at startup <2000 cSt If fluids other than the above mentioned type are used, please always indicate type of used fluid and operating conditions so that jbj Techniques technical office can advise of possible problems with compatibility or useful life of systemparts. Inlet Pressure Under standard working conditions, intake pipe pressure is lower than atmospheric pressure. The operating inlet pressure should range between 0.7 and 3 bars (absolute). In case the pump must work with higher pressure in the intake pipe, a special “TR” version is available. Please call jbj Techniques technical office tel: +44 (0)1737 767493 or email: info@jbj.co.uk for values other than those indicated. Min. Rotation Speed Marzocchi 1P pump versatility can be perceived from the wide range of rotation speeds they can be subject to: max. values are indicated in product tables and change according to themodel, whilemin. values are as follows: Group 0.25 0.5 Size 18 24 30 36 48 60 0.5 0.75 1.0 1.3 1.6 2.0 Min. Speed (rpm) 1500 1000 800 www.jbj.co.uk/gear-pumps.html #DriveLineHarmony
Gear Pumps Micro Series Installation and Running Information 10 Pressure Definition Product tables show threemax. pressure levels (P1, P2 and P3) to which each pump can be used. P3 = peak max pressure. P2 = intermittent max. pressure. P1 = continuous max. pressure. Pressure diagramas a function of time. P1, P2 and P3 values can be attained only if systemdoes not go over the following rotation speeds: P3 P2 P1 t (sec) Max. 20 sec. Max. 2 sec. p(bar) www.jbj.co.uk/gear-pumps.html #DriveLineHarmony Group 0.25 0.5 Size 18 24 30 36 48 60 0.5 0.75 1.0 1.3 1.6 2.0 Min. Speed (rpm) 3000 2500 2000 Please contact jbj Techniques technical department, email: info@jbj.co.uk or telephone: +44 (0)1737 767493 for system operating conditions other than indicated in the product tables. Supply &Delivery Lines Hydraulic systempipes should show no sudden changes of direction, sharp bends and sudden differences in cross-section. They should not be too long or out of proportion. Pipe cross-section should be sized so that fluid velocity does not exceed recommended values. It is advisable to carefully consider the possible diameter reduction of the inlet or outlet pipes fitted on flange fittings. Reference values are the following: Intake line 0.5 to 1.6m/s Delivery line 2 to 6m/s Return line 1.6 to 3m/s
Direction of Rotation The P1 series gear pumps are available as single rotation and bi-rotational. The direction of rotation is defined in the following way: looking at the front of the pump with the driver shaft positioned upward and sticking toward the observer, it will be a mono-directional right "D". ALP...D pump therefore with right. "D" rotation, if its rotation will be clockwise and therefore the inlet port will be on the left while the outlet port will be on the right. Vice-versa it will be a monodirectional left ALP...S therefore with left "S" rotation when looking at it from the same angle.. S = counter-clockwise rotation D = clockwise rotation R = reversible rotation The bi-rotational Micro series pumps, "R" have both functional characteristics of the mono-directional motors with clockwise and counterclockwise rotation. Drive Connect the pump to the motor using a mechanical power transmission coupling so that no radial and/or axial force is transmitted to the pump shaft during rotation, otherwise pump efficiency will dramatically drop due to early wear of inner moving parts. jbj Techniques have a wide range of suitable couplings to suit a wide range of applications and we can advise on which coupling depending on the circumstances of the application. In case of driving through gears, pulleys or chains, the T option is recommended. This option allow radial and/or axial loads on the pump shaft. For further details contact jbj Techniques technical office, email: info@jbj.co.uk or telephone: +44 (0)1737 767493 Frequently Used Formulas Fluid velocity Calculate the velocity (v) of a fluid in a pipe as follows: v =Q / 6 •A[m/s] Q= flow rate [litre/min] A = inside area of pipe [cm²] Absorbed flow rate Calculate flow rate (Q) as follows: Q= V • n • 10 -3 / hvol [litre/min] V = displacement [cm³/rotation] n = rotation speed [rotations per minute] hvol = pump volumetric efficiency (take 0.95 as an indicative value for rotation speeds ranging between 1000 and 2000 rotations per minute) Absorbed torque Calculate necessary torque (M) of a pump subject to pressure differential between inlet and delivery as follows: M= (V • Dp) / (62.8 • hhm) [Nm] V = displacement [cm³/rotation] Dp = pressure differential [bar] hhm= hydromechanical efficiency (take 0.80 as indicative value under cold conditions and 0.85 under working conditions). Gear Pumps Micro Series Installation and Running Information 11 www.jbj.co.uk/gear-pumps.html #DriveLineHarmony S D INLET OUTLET INLET OUTLET R
- omit RO High pressure Gear Pumps Micro Series Information 12 Absorbed power Calculate hydraulic power (P), transferred to fluid froma pump subject to a pressure differential between inlet and delivery as follows: P= (Q • Dp) / (600 • htot) [kW] Q= flow rate [litre/min.] Dp = pressure differential [bar] htot = total pump efficiency (hhm • hvol) Values for hvol and hhm (and consequently htot) depend on pressure differential between supply and delivery, rotation speed, fluid features (temperature and viscosity) and filtering degree. Contact jbj Techniques technical office, email: info@jbj.co.uk or telephone: +44 (0)1737 767493 for further details on efficiency. The proper values for flow rate, torque and supplied according to pressure differential, rotation speed and set test conditions, can be found on the Performance Curve pages. These pumps are hydraulic machines converting mechanical power into hydraulic power. This section deals with rotary positive-displacement pumps. In this type of pump, a given volume of fluid flows from inlet to outlet at each shaft rotation (theoretical displacement). Pressure depends on delivery line resistance to fluid flow. As gear pumps only transfer fluid, they are subject to pressure generated by the circuit. Therefore, if system flow rate and motor rotation speed are known, it is easy to select the right pump displacement and its model. The diagram indicating flow rate variations according to speed and pressure, shows that not all the theoretically available fluid is transferred from inlet to outlet because of pump internal leakage. Leakage can be greatly reduced through pressure axial compensating systems (as described at the beginning of this catalogue) but never eliminated. Leakage increases as circuit pressure increases. Apump requires energy, just like any other hydraulic machine. Part of this power is given to the fluid to increase pressure required by the circuit, the remaining part is used to cure pump internal friction. Therefore, for proper pump operation, supplied torque shall be higher than theoretical torque. The following diagrams show, for each single displacement, the typical required power as a function of rotation speed and pressure generated by the system and allow you to easily spot the product suitable for your application. Once the pump flow rate has been selected, different flanges, shafts, inlet and outlet port position and type are available to suit most applications. In the product tables, the flow, shown at 1500 rpm, has been evaluated using a value of volumetric efficiency of 95%. All the drawings represent pumps with clockwise rotation. Reversing the direction of rotation also involves reversing of the suction side with the delivery side ports. www.jbj.co.uk/gear-pumps.html #DriveLineHarmony D Group Rotation Size Ports* Special Versions 0.25 0.5 Clockwise S Counter Clockwise R Reversible Shaft* 18 24 30 Ordering Code tang tapered* C G - KK KA KX KE V High temperature ST Special temperature TR Reinforced shaft seal Pressure relief valve not mounted - mounted** VM ... Type - K U UK L
Type Displacement Flow at Maximum Pressure Maximum Dimensions 1500 rev/min P P P Speed M L D I 2 3 3 cm /rev litres/mim bar bar bar rpm mm mm 0.25 D 18 0.19 0.29 190 210 230 7000 54 24 M10 x 1 0.25 D 24 0.26 0.38 190 210 230 7000 55 24.5 M10 x 1 0.25 D 30 0.32 0.48 190 210 230 7000 56 25 M10 x 1 0.25 D 36 0.38 0.58 190 210 230 7000 57 25.5 M10 x 1 0.25 D 48 0.51 0.77 190 210 230 7000 59 26.5 M10 x 1 0.25 D 60 0.64 0.96 190 210 230 7000 61 27.5 M10 x 1 0.5 D 0.50 0.50 0.75 190 210 230 7000 63 28.5 G¹⁄ 0.5 D 0.75 0.63 0.94 190 210 230 7000 64 29 G¹⁄ 0.5 D 1.00 0.88 1.31 190 210 230 7000 66 30 G¹⁄ 0.5 D 1.30 1.00 1.50 190 210 230 6000 67 30.5 G¹⁄ 0.5 D 1.60 1.25 1.88 190 210 230 5000 69 31.5 G¹⁄ 0.5 D 2.00 1.50 2.25 190 210 230 4000 71 32.5 G¹⁄ www.jbj.co.uk/gear-pumps.html #DriveLineHarmony 4 12 -0.053 -0.02 Ø22 n.2 6.6 25.68 D 7.32 50 16 9.6 5.5 M 5 L 21 8 8 80 66 55 D -0.014 +0 2 6.8 M6 -0.01 +0 6 9.5 -0.05 -0.01 5 Ø8 5.5 B B 524980 A A "KK" Port "G" Shaft A-A B-B Opzioni: OUTLET INLET OUTLET Micro Hydraulic Gear Pumps 0.25 - 0.5 Series M10x1 threads depth 9 mm. G¹⁄ threads depth 9 mm. OPTIONS “KK”: also D inlet and outlet ports are present on the body, as well as on the correspondent standard version. 13
Cover: G¹⁄ thread depth 12 mm. OPTIONS “KE”: M10 x 1 thread depth 9 mm, G¹⁄ thread depth 9 mm. www.jbj.co.uk/gear-pumps.html #DriveLineHarmony 14 Micro Hydraulic Gear Pumps K 0.25 - K 0.5 Series Type Displacement Flow at Maximum Pressure Maximum Dimensions 1500 rev/min P P P Speed M L D I 2 3 3 cm /rev litres/mim bar bar bar rpm mm mm K 0.25 D 18 0.19 0.29 190 210 230 7000 54 24 M10 x 1 K 0.25 D 24 0.26 0.38 190 210 230 7000 55 24.5 M10 x 1 K 0.25 D 30 0.32 0.48 190 210 230 7000 56 25 M10 x 1 K 0.25 D 36 0.38 0.58 190 210 230 7000 57 25.5 M10 x 1 K 0.25 D 48 0.51 0.77 190 210 230 7000 59 26.5 M10 x 1 K 0.25 D 60 0.64 0.96 190 210 230 7000 61 27.5 M10 x 1 K 0.5 D 0.50 0.50 0.75 190 210 230 7000 63 28.5 G¹⁄ K 0.5 D 0.75 0.63 0.94 190 210 230 7000 64 29 G¹⁄ K 0.5 D 1.00 0.88 1.31 190 210 230 7000 66 30 G¹⁄ K 0.5 D 1.30 1.00 1.50 190 210 230 6000 67 30.5 G¹⁄ K 0.5 D 1.60 1.25 1.88 190 210 230 5000 69 31.5 G¹⁄ K 0.5 D 2.00 1.50 2.25 190 210 230 4000 71 32.5 G¹⁄ 16 9.6 5.5 n.2 6.6 M 80 66 25.68 7.32 55 50 L D 5 21 8 8 M6 12 4 6.8 -0.014 +0 2 -0.053 -0.02 Ø22 7.5 G1/4 9.5 -0.05 -0.01 5 Ø8 5.5 -0.01 +0 6 A A 524980 B B Albero "G" "G" Shaft B-B Porta "KE" "KE" Port A-A INLET OUTLET MANDATA OUTLET
www.jbj.co.uk/gear-pumps.html #DriveLineHarmony 15 Micro Hydraulic Gear Pumps 0.25 KA - 0.5 KA Series 50 M 5 80 66 25.68 55 7.32 12 n.2 6.6 -0.05 -0.01 5 9.5 Ø8 5.5 21 8 8 M6 4 -0.014 +0 2 6.8 G1/4 7.5 -0.053 -0.02 Ø22 16 G1/8 -0.01 +0 6 A A B B Albero "G" "G" Shaft B-B A-A OUTLET INLET G¹⁄ thread depth 8 mm. G¹⁄ thread depth 12 mm. Type Displacement Flow at Maximum Pressure Maximum Dimensions 1500 rev/min P P P Speed M I 2 3 3 cm /rev litres/mim bar bar bar rpm mm 0.25 D 18 KA 0.19 0.29 190 210 230 7000 54 0.25 D 24 KA 0.26 0.38 190 210 230 7000 55 0.25 D 30 KA 0.32 0.48 190 210 230 7000 56 0.25 D 36 KA 0.38 0.58 190 210 230 7000 57 0.25 D 48 KA 0.51 0.77 190 210 230 7000 59 0.25 D 60 KA 0.64 0.96 190 210 230 7000 61 0.5 D 0.50 KA 0.50 0.75 190 210 230 7000 63 0.5 D 0.75 KA 0.63 0.94 190 210 230 7000 64 0.5 D 1.00 KA 0.88 0.31 190 210 230 7000 66 0.5 D 1.30 KA 1.00 1.50 190 210 230 6000 67 0.5 D 1.60 KA 1.25 1.88 190 210 230 5000 69 0.5 D 2.00 KA 1.50 2.25 190 210 230 4000 71
M10x1 threads depth 9 mm. G¹⁄ threads depth 9 mm. To mount the pump: n. 2 M5 screws, with a torque wrench setting fixed at 5.4 ± 0.5 Nm. OPTIONS “KK”: also D inlet and outlet ports are present on the body, as well as on the correspondent standard version. www.jbj.co.uk/gear-pumps.html #DriveLineHarmony 16 Micro Hydraulic Gear Pumps U 0.25 - U 0.5 Series Type Displacement Flow at Maximum Pressure Maximum Dimensions 1500 rev/min P P P Speed M N L D I 2 3 3 cm /rev litres/mim bar bar bar rpm mm mm mm U 0.25 D 18 0.19 0.29 190 210 230 7000 54 44.5 24 M10 x 1 U 0.25 D 24 0.26 0.38 190 210 230 7000 55 45.5 24.5 M10 x 1 U 0.25 D 30 0.32 0.48 190 210 230 7000 56 46.5 25 M10 x 1 U 0.25 D 36 0.38 0.58 190 210 230 7000 57 47.5 25.5 M10 x 1 U 0.25 D 48 0.51 0.77 190 210 230 7000 59 49.5 26.5 M10 x 1 U 0.25 D 60 0.64 0.96 190 210 230 7000 61 51.5 27.5 M10 x 1 U 0.5 D 0.50 0.50 0.75 190 210 230 7000 63 53.5 28.5 G¹⁄ U 0.5 D 0.75 0.63 0.94 190 210 230 7000 64 54.5 29 G¹⁄ U 0.5 D 1.00 0.88 1.31 190 210 230 7000 66 56.5 30 G¹⁄ U 0.5 D 1.30 1.00 1.50 190 210 230 6000 67 57.5 30.5 G¹⁄ U 0.5 D 1.60 1.25 1.88 190 210 230 5000 69 59.5 31.5 G¹⁄ U 0.5 D 2.00 1.50 2.25 190 210 230 4000 71 61.5 32.5 G¹⁄ 4 -0.053 -0.02 Ø22 32 7.68 50 7.32 D 9.6 5.5 M L 5 N 21 8 8 30 55 D -0.014 +0 2 M6 -0.01 +0 6 6.8 9.5 -0.05 -0.01 5 Ø8 5.5 n.2 5.5 B B A 524980 A Porta "KK" "KK" Port "G" Shaft A-A Albero "G" B-B 16 OUTLET INLET MANDATA OUTLET
www.jbj.co.uk/gear-pumps.html #DriveLineHarmony 17 Micro Hydraulic Gear Pumps UK 0.25 - UK 0.5 Series Cover: G¹⁄ thread depth 12 mm. To mount the pump: n. 2 M5 screws, with a torque wrench setting fixed at 5.4 ± 0.5 Nm. OPTIONS “KE”: M10x1 thread depth 9 mm, G¹⁄ thread depth 9 mm. 5.5 9.6 32 n.2 5.5 M N 7.68 30 50 7.32 55 16 L D 21 5 8 8 M6 4 6.8 -0.014 +0 2 -0.053 -0.02 Ø22 G1/4 7.5 -0.05 -0.01 5 9.5 Ø8 5.5 -0.01 +0 6 524980 A A B B Albero "G" "G" Shaft B-B Porta "KE" "KE" Port A-A INLET OUTLET MANDATA OUTLET Type Displacement Flow at Maximum Pressure Maximum Dimensions 1500 rev/min P P P Speed M N L D I 2 3 3 cm /rev litres/mim bar bar bar rpm mm mm mm UK 0.25 D 18 0.19 0.29 190 210 230 7000 54 44.5 24 M10 x 1 UK 0.25 D 24 0.26 0.38 190 210 230 7000 55 45.5 24.5 M10 x 1 UK 0.25 D 30 0.32 0.48 190 210 230 7000 56 46.5 25 M10 x 1 UK 0.25 D 36 0.38 0.58 190 210 230 7000 57 47.5 25.5 M10 x 1 UK 0.25 D 48 0.51 0.77 190 210 230 7000 59 49.5 26.5 M10 x 1 UK 0.25 D 60 0.64 0.96 190 210 230 7000 61 51.5 27.5 M10 x 1 UK 0.5 D 0.50 0.50 0.75 190 210 230 7000 63 53.5 28.5 G¹⁄ UK 0.5 D 0.75 0.63 0.94 190 210 230 7000 64 54.5 29 G¹⁄ UK 0.5 D 1.00 0.88 1.31 190 210 230 7000 66 56.5 30 G¹⁄ UK 0.5 D 1.30 1.00 1.50 190 210 230 6000 67 57.5 30.5 G¹⁄ UK 0.5 D 1.60 1.25 1.88 190 210 230 5000 69 59.5 31.5 G¹⁄ UK 0.5 D 2.00 1.50 2.25 190 210 230 4000 71 61.5 32.5 G¹⁄
Type Displacement Flow at Maximum Pressure Maximum Dimensions 1500 rev/min P P P Speed M N I 2 3 3 cm /rev litres/mim bar bar bar rpm mm mm U 0.25 D 18 KA 0.19 0.29 190 210 230 7000 54 44.5 U 0.25 D 24 KA 0.26 0.38 190 210 230 7000 55 45.5 U 0.25 D 30 KA 0.32 0.48 190 210 230 7000 56 46.5 U 0.25 D 36 KA 0.38 0.58 190 210 230 7000 57 47.5 U 0.25 D 48 KA 0.51 0.77 190 210 230 7000 59 49.5 U 0.25 D 60 KA 0.64 0.96 190 210 230 7000 61 51.5 U 0.5 D 0.50 KA 0.50 0.75 190 210 230 7000 63 53.5 U 0.5 D 0.75 KA 0.63 0.94 190 210 230 7000 64 54.5 U 0.5 D 1.00 KA 0.88 1.31 190 210 230 7000 66 56.5 U 0.5 D 1.30 KA 1.00 1.50 190 210 230 6000 67 57.5 U 0.5 D 1.60 KA 1.25 1.88 190 210 230 5000 69 59.5 U 0.5 D 2.00 KA 1.50 2.25 190 210 230 4000 71 61.5 G¹⁄ thread depth 8 mm. G¹⁄ thread depth 12 mm. To mount the pump: n. 2 M5 screws, with a torque wrench setting fixed at 5.4 ± 0.5 Nm. www.jbj.co.uk/gear-pumps.html #DriveLineHarmony 18 Micro Hydraulic Gear Pumps U 0.25 KA - U 0.5 KA Series 32 50 M N 21 8 5 7.68 30 55 7.32 n.2 5.5 -0.05 -0.01 5 9.5 Ø8 5.5 M6 7.5 G1/4 -0.014 +0 2 6.8 -0.053 -0.02 Ø22 16 G1/8 -0.01 +0 6 8 4 A A B B "G" Shaft B-B A-A OUTLET INLET
0,00 0,25 0,50 0,75 1,00 1,25 1,50 1,75 2,00 2,25 2,50 500 1000 1500 2000 2500 3000 3500 4000 4500 60 48 36 30 24 18 n [min ] Q [l/min] -1 18 24 30 36 25 - 230 bar 48 60 Each curve has been obtained at 50°C, using oil with viscosity 30 cSt at these pressure. 0.25 18 0 50 100 150 200 250 300 350 400 450 500 1000 1500 2000 2500 3000 3500 4000 n [min P [W] M [Nm] -1] 0,0 0,2 0,4 0,6 0,8 1,0 1,2 230 bar 50 bar 100 bar 150 bar 190 bar 25 bar 25 bar 230 bar 190 bar 150 bar 100 bar 50 bar 0 50 100 150 200 250 300 350 400 450 500 550 600 1000 1500 2000 2500 3000 3500 4000 0,0 0,2 0,4 0,6 0,8 1,0 1,2 1,4 230 bar 50 bar 100 bar 150 bar 190 bar 25 bar 25 bar 230 bar 190 bar 150 bar 100 bar 50 bar n [min ] P [W] M [Nm] -1 0.2 0.25 0.25 24 Micro Hydraulic Gear Pumps 0.25 Performance Curves Absorbed power P [kW]. Absorbed torque M [Nm]. Drive speed n [rpm] www.jbj.co.uk/gear-pumps.html #DriveLineHarmony 19
www.jbj.co.uk/gear-pumps.html #DriveLineHarmony Absorbed power P [kW]. Absorbed torque M [Nm]. Drive speed n [rpm] 20 Micro Hydraulic Gear Pumps 0.25 Performance Curves 0.25 60 0 50 100 150 200 250 300 350 400 450 500 550 600 650 700 750 800 850 900 950 1000 1050 1100 500 1000 1500 2000 2500 3000 3500 0,0 0,2 0,4 0,6 0,8 1,0 1,2 1,4 1,6 1,8 2,0 2,2 2,4 2,6 2,8 3,0 230 bar 50 bar 100 bar 150 bar 190 bar 25 bar 25 bar 230 bar 190 bar 150 bar 100 bar 50 bar n [min ] P [W] M [Nm] -1 0.25 36 0 50 100 150 200 250 300 350 400 450 500 550 600 650 700 750 800 1000 1500 2000 2500 3000 3500 4000 0,0 0,2 0,4 0,6 0,8 1,0 1,2 1,4 1,6 1,8 2,0 230 bar 50 bar 100 bar 150 bar 190 bar 25 bar 25 bar 230 bar 190 bar 150 bar 100 bar 50 bar n [min ] P [W] M [Nm] -1 0.25 30 0 50 100 150 200 250 300 350 400 450 500 550 600 650 700 1000 1500 2000 2500 3000 3500 4000 0,0 0,2 0,4 0,6 0,8 1,0 1,2 1,4 1,6 230 bar 50 bar 100 bar 150 bar 190 bar 25 bar 25 bar 230 bar 190 bar 150 bar 100 bar 50 bar n [min ] P [W] M [Nm] -1 0.25 48 0 50 100 150 200 250 300 350 400 450 500 550 600 650 700 750 800 850 900 950 1000 1000 1500 2000 2500 3000 3500 4000 0,0 0,2 0,4 0,6 0,8 1,0 1,2 1,4 1,6 1,8 2,0 2,2 2,4 2,6 230 bar 50 bar 100 bar 150 bar 190 bar 25 bar 25 bar 230 bar 190 bar 150 bar 100 bar 50 bar n [min ] P [W] M [Nm] -1 . 5 48 5 30 5 60 0. 6
Absorbed power P [kW]. Absorbed torque M [Nm]. Drive speed n [rpm] www.jbj.co.uk/gear-pumps.html #DriveLineHarmony 21 Micro Hydraulic Gear Pumps 0.5 Performance Curves 0.5 0,00 0,50 1,00 1,50 2,00 2,50 3,00 3,50 4,00 4,50 5,00 5,50 6,00 500 1000 1500 2000 2500 3000 3500 4000 4500 2,00 1,60 1,30 1,00 0,75 0,50 n [min Q [l/min] -1] 0.5 0.50 0 100 200 300 400 500 600 700 800 900 1000 1000 1500 2000 2500 3000 3500 4000 0,0 0,5 1,0 1,5 2,0 2,5 230 bar 50 bar 100 bar 150 bar 190 bar 25 bar 25 bar 230 bar 190 bar 150 bar 100 bar 50 bar n [min P [W] M [Nm] -1] 0.5 0.75 0 100 200 300 400 500 600 700 800 900 1000 1100 500 1000 1500 2000 2500 3000 3500 0,0 0,5 1,0 1,5 2,0 2,5 3,0 230 bar 50 bar 100 bar 150 bar 190 bar 25 bar 25 bar 230 bar 190 bar 150 bar 100 bar 50 bar n [min P [W] M [Nm] -1] 0.5 , 0 .5 0.5 ,75 0,50 0,75 1,00 25 -230 bar 1,30 1,60 25 -190 bar 2,00 25 -150 bar Each curve has been obtained at 50°C, using oil with viscosity 30 cSt at these pressure.
Absorbed power P [kW]. Absorbed torque M [Nm]. Drive speed n [rpm] Micro Hydraulic Gear Pumps 0.5 Performance Curves 0.5 2.00 0 100 200 300 400 500 600 700 800 900 1000 1100 1200 1300 1400 1500 1600 500 1000 1500 2000 2500 3000 3500 0,0 0,5 1,0 1,5 2,0 2,5 3,0 3,5 4,0 4,5 50 bar 100 bar 150 bar 25 bar 25 bar 150 bar 100 bar 50 bar n [min P [W] M [Nm] -1] 0.5 1.30 0 100 200 300 400 500 600 700 800 900 1000 1100 1200 1300 1400 1500 1600 500 1000 1500 2000 2500 3000 3500 0,0 0,5 1,0 1,5 2,0 2,5 3,0 3,5 4,0 4,5 230 bar 50 bar 100 bar 150 bar 190 bar 25 bar 25 bar 230 bar 190 bar 150 bar 100 bar 50 bar n [min P [W] M [Nm] -1] 0.5 1.00 0 100 200 300 400 500 600 700 800 900 1000 1100 1200 1300 1400 500 1000 1500 2000 2500 3000 3500 0,0 0,5 1,0 1,5 2,0 2,5 3,0 3,5 4,0 230 bar 50 bar 100 bar 150 bar 190 bar 25 bar 25 bar 230 bar 190 bar 150 bar 100 bar 50 bar n [min P [W] M [Nm] -1] 0.5 1.60 0 100 200 300 400 500 600 700 800 900 1000 1100 1200 1300 1400 1500 1600 500 1000 1500 2000 2500 3000 3500 0,0 0,5 1,0 1,5 2,0 2,5 3,0 3,5 4,0 4,5 50 bar 100 bar 150 bar 190 bar 25 bar 25 bar 190 bar 150 bar 100 bar 50 bar n [min P [W] M [Nm] -1] 0.5 1, .5 1,00 0.5 , 0 0.5 1, www.jbj.co.uk/gear-pumps.html #DriveLineHarmony 22
www.jbj.co.uk/gear-pumps.html #DriveLineHarmony 23 Micro Hydraulic Gear Pumps High Pressure RO Series SERIE PERALTEPRESSIONI RO Marzocchi production range includes micropumps for hi-pressure applications: the RO version. For these applications, in extreme operating conditions, for micropump protection and longer life, a proper system design and assembly is of major importance; all filtering and cleaning indications shall be strictly followed and all system parts -fluid included- shall be selected for that special operating conditions. RO series micropumps are supplied only with peen-typemilled timing shaft “G”. P1, P2 and P3 values can be attained only if systemdoes not exceed the following rotation speeds: Group 0.25 0.5 Size 18 24 30 36 48 60 0.5 0.75 1.0 1.3 1.6 Min. Speed (rpm) 2500 2000 1500 Please contact jbj Techniques technical department, email: info@jbj.co.uk or telephone: +44 (0)1737 767493 for system operating conditions other than indicated in the product tables. The following diagrams and tables show pressure values P1, P2 and P3 of all RO version sizes for each group, compared to standard values. All RO versionmicro pumps have this marking on the identification label. RO versionmicro pumps look like the standard versions but they bear a green label indicating “High -pressure ROSeries”.
= valore versione RO RO version values = valore versione Standard standard version values 18 24 30 36 48 P2 P2 RO 0 35 70 105 140 175 210 245 280 315 350 PRESSIONE / PRESSURE [bar] MODELLO / MODEL 60 18 24 30 36 48 60 P1 P1 RO 0 35 70 105 140 175 210 245 280 315 350 PRESSIONE / PRESSURE [bar] MODELLO / MODEL 18 24 30 36 48 60 P3 P3 RO 0 35 70 105 140 175 210 245 280 315 350 PRESSIONE / PRESSURE [bar] MODELLO / MODEL 0,50 0,75 1,00 1,30 1,60 P2 P2 RO 0 35 70 105 140 175 210 245 280 315 350 PRESSIONE / PRESSURE [bar] MODELLO / MODEL 0,50 0,75 1,00 1,30 1,60 P1 P1 RO 0 35 70 105 140 175 210 245 280 315 350 PRESSIONE / PRESSURE [bar] MODELLO / MODEL 0,50 0,75 1,00 1,30 1,60 P3 P3 RO 0 35 70 105 140 175 210 245 280 315 350 PRESSIONE / PRESSURE [bar] MODELLO / MODEL P1 P3 P2 P1 P3 P2 Micro Hydraulic Gear Pumps High Pressure RO Series www.jbj.co.uk/gear-pumps.html #DriveLineHarmony 24 0.25 RO 0.5 RO
Type Displacement Flow at Maximum Pressure Maximum Dimensions 1500 rev/min P P P Speed M L D I 2 3 3 cm /rev litres/mim bar bar bar rpm mm mm 0.25 D 18 G RO 0.19 0.29 230 250 270 7000 54 24 M10 x 1 0.25 D 24 G RO 0.26 0.38 230 250 270 7000 55 24.5 M10 x 1 0.25 D 30 G RO 0.32 0.48 230 250 270 7000 56 25 M10 x 1 0.25 D 36 G RO 0.38 0.58 230 250 270 7000 57 25.5 M10 x 1 0.25 D 48 G RO 0.51 0.77 230 250 270 7000 59 26.5 M10 x 1 0.25 D 60 G RO 0.64 0.96 230 250 270 7000 61 27.5 M10 x 1 0.5 D 0.50 G RO 0.50 0.75 230 250 270 7000 63 28.5 G¹⁄ 0.5 D 0.75 G RO 0.63 0.94 230 250 270 7000 64 29 G¹⁄ 0.5 D 1.00 G RO 0.88 1.31 230 250 270 7000 66 30 G¹⁄ 0.5 D 1.30 G RO 1.00 1.50 230 250 270 6000 67 30.5 G¹⁄ 0.5 D 1.60 G RO 1.25 1.88 230 250 270 5000 69 31.5 G¹⁄ www.jbj.co.uk/gear-pumps.html #DriveLineHarmony Micro Hydraulic Gear Pumps 0.25 RO - 0.5 RO Series M10 x 1 threads depth 9 mm. G¹⁄ threads depth 9 mm. OPTION RO models can be supplied with the ports configuration as follows: "K", "KK" and "KE". 25 12 4 25.68 n.2 6.6 -0.053 -0.02 Ø22 D 7.32 50 M L -0.05 -0.01 5 9.5 80 66 55 D 5.5 Ø8 A A A-A OUTLET INLET
www.jbj.co.uk/gear-pumps.html #DriveLineHarmony Micro Hydraulic Gear Pumps U 0.25 RO - U 0.5 RO Series M10 x 1 threads depth 9 mm. G¹⁄ threads depth 9 mm. To mount the pump: n. 2 M5 screws, with a torque wrench setting fixed at 5.4 ± 0.5 Nm. OPTIONS RO models can be supplied with the ports configuration as follows: "K", "KK" and "KE". 26 4 32 7.68 D -0.053 -0.02 Ø22 7.32 50 M 9.5 N L -0.05 -0.01 5 55 Ø8 D 5.5 30 n.2 5.5 A A A-A INLET OUTLET Type Displacement Flow at Maximum Pressure Maximum Dimensions 1500 rev/min P P P Speed M N L D I 2 3 3 cm /rev litres/mim bar bar bar rpm mm mm mm U 0.25 D 18 G RO 0.19 0.29 230 250 270 7000 54 44.5 24 M10 x 1 U 0.25 D 24 G RO 0.26 0.38 230 250 270 7000 55 45.5 24.5 M10 x 1 U 0.25 D 30 G RO 0.32 0.48 230 250 270 7000 56 46.5 25 M10 x 1 U 0.25 D 36 G RO 0.38 0.58 230 250 270 7000 57 47.5 25.5 M10 x 1 U 0.25 D 48 G RO 0.51 0.77 230 250 270 7000 59 49.5 26.5 M10 x 1 U 0.25 D 60 G RO 0.64 0.96 230 250 270 7000 61 51.5 27.5 M10 x 1 U 0.5 D 0.50 G RO 0.50 0.75 230 250 270 7000 63 53.5 28.5 G1/4 U 0.5 D 0.75 G RO 0.63 0.94 230 250 270 7000 64 54.5 29 G1/4 U 0.5 D 1.00 G RO 0.88 1.31 230 250 270 7000 66 56.5 30 G1/4 U 0.5 D 1.30 G RO 1.00 1.50 230 250 270 6000 67 57.5 30.5 G1/4 U 0.5 D 1.60 G RO 1.25 1.88 230 250 270 5000 69 59.5 31.5 G1/4
www.jbj.co.uk/gear-pumps.html #DriveLineHarmony 27 Micro Hydraulic Gear Pumps Single Reversible Pumps As described at the beginning of the single rotation micro pump section, also bi-rotational models are rotary positive-displacement micro pumps with external gears. Their operating concept is the same as single rotation pumps. What changes is that bi-rotational pumps can rotate both clockwise and counterclockwise thanks to their perfectly symmetrical machining on the internal components. Some models have the external drain positioned on the flange or on the cover; connection pipes to the system tank should never be clogged or show reduced cross-section, otherwise pressure values might exceed 6 bar. The bi-rotational micro pump is capable of handling pressurized inflow. Please contact jbj Techniques technical department, email: info@jbj.co.uk or telephone: +44 (0)1737 767493 for system operating conditions other than indicated in the product tables.
Type Displacement Flow at Maximum Pressure Maximum Dimensions 1500 rev/min P P P Speed M L D I 2 3 3 cm /rev litres/mim bar bar bar rpm mm mm 0.25 R 18 0.19 0,29 150 170 190 7000 54 24 M10 x 1 0.25 R 24 0.26 0,38 150 170 190 7000 55 24.5 M10 x 1 0.25 R 30 0.32 0,48 150 170 190 7000 56 25 M10 x 1 0.25 R 36 0.38 0,58 150 170 190 7000 57 25.5 M10 x 1 0.25 R 48 0.51 0,77 150 170 190 7000 59 26.5 M10 x 1 0.25 R 60 0.64 0,96 150 170 190 7000 61 27.5 M10 x 1 0.5 R 0.50 0.50 0,75 150 170 190 7000 63 28.5 G¹⁄ 0.5 R 0.75 0.63 0,94 150 170 190 7000 64 29 G¹⁄ 0.5 R 1.00 0.88 1,31 150 170 190 7000 66 30 G¹⁄ 0.5 R 1.30 1.00 1,50 150 170 190 6000 67 30.5 G¹⁄ 0.5 R 1.60 1.25 1,88 150 170 190 5000 69 31.5 G¹⁄ 0.5 R 2,00 1,50 2,25 150 170 190 4000 71 32,5 G1/4 www.jbj.co.uk/gear-pumps.html #DriveLineHarmony Micro Hydraulic Gear Pumps 0.25 R - 0.5 R Series M10 x 1 threads depth 9 mm. G¹⁄ threads depth 9 mm. Drain port (cover): G¹⁄ thread depth 8 mm. 28
Type Displacement Flow at Maximum Pressure Maximum Dimensions 1500 rev/min P P P Speed M I 2 3 3 cm /rev litres/mim bar bar bar rpm mm 0.25 R 18 KX 0,19 0,29 150 170 190 7000 54 0.25 R 24 KX 0,26 0,38 150 170 190 7000 55 0.25 R 30 KX 0,32 0,48 150 170 190 7000 56 0.25 R 36 KX 0,38 0,58 150 170 190 7000 57 0.25 R 48 KX 0,51 0,77 150 170 190 5000 59 0.25 R 60 KX 0,64 0,96 150 170 190 5000 61 0.5 R 0,50 KX 0,50 0,75 150 170 190 5000 63 0.5 R 0,75 KX 0,63 0,94 150 170 190 5000 64 0.5 R 1,00 KX 0,88 1,31 150 170 190 5000 66 0.5 R 1,30 KX 1,00 1,50 150 170 190 4000 67 0.5 R 1,60 KX 1,25 1,88 150 170 190 3500 69 0.5 R 2,00 KX 1,50 2,25 150 170 190 3000 71 www.jbj.co.uk/gear-pumps.html #DriveLineHarmony Micro Hydraulic Gear Pumps 0.25 R KX - 0.5 R KX Series 29 n.3 9.6 n.3 5.5 16 5 M 19 55 16 9.5 Ø8 12 8 8 21 M6 2 +-00 .014 6.8 Ø22- - 00 . . 00 52 3 n.2 6.6 25.68 7.32 80 66 5- - 00 . . 00 51 6 +-00 .01 5.5 4 50 n.3 524980 A A B B Albero "G" "G" Shaft B-B A-A DRENAGGIO DRAIN
Type Displacement Flow at Maximum Pressure Maximum Dimensions 1500 rev/min P P P Speed M L D I 2 3 3 cm /rev litres/mim bar bar bar rpm mm mm 0.25 R 18 VN KX 0,19 0,29 150 170 190 7000 61,5 24 M10x1 0.25 R 24 VN KX 0,26 0,38 150 170 190 7000 62,5 24,5 M10x1 0.25 R 30 VN KX 0,32 0,48 150 170 190 7000 63,5 25 M10x1 0.25 R 36 VN KX 0,38 0,58 150 170 190 7000 64,5 25,5 M10x1 0.25 R 48 VN KX 0,51 0,77 150 170 190 7000 66,5 26,5 M10x1 0.25 R 60 VN KX 0,64 0,96 150 170 190 7000 68,5 27,5 M10x1 0.5 R 0,50 VN KX 0,50 0,75 150 170 190 7000 70,5 28,5 G1/4 0.5 R 0,75 VN KX 0,63 0,94 150 170 190 7000 71,5 29 G1/4 0.5 R 1,00 VN KX 0,88 1,31 150 170 190 7000 73,5 30 G1/4 0.5 R 1,30 VN KX 1,00 1,50 150 170 190 6000 74,5 30,5 G1/4 0.5 R 1,60 VN KX 1,25 1,88 150 170 190 5000 76,5 31,5 G1/4 0.5 R 2,00 VN KX 1,50 2,25 150 170 190 4000 78,5 32,5 G1/4 www.jbj.co.uk/gear-pumps.html #DriveLineHarmony Micro Hydraulic Gear Pumps 0.25 R VN - 0.5 R VN Series Inlet port: G¹⁄ thread depth 12mm. OPTIONS “KE”: D inlet and outlet ports aremachined on both body sides, only; M10x1 threads depth 9mm, G¹⁄ threads depth 9mm. “L”: available with outlet port machined on the body (“KE” version) or, alternatively, on the flange (“KX” version). Option available for type 0.25, only. Inlet port: G¹⁄ thread depth 9.5 mm. 30 16 n.2 6.6 n.2 5.5 n.2 9.6 M 25.68 66 7.32 53 16 14 G1/8 L D 5 21 8 8 G1/4 M6 12 4 5 2 +-00 .014 6.8 Ø22- - 00 . . 00 52 3 6.5 80 9.8 50 9.5 5- - 00 . . 00 51 Ø8 5.5 6 +-00 .01 76 A A n.2 524980 B B "G" Shaft B-B "L" Port A-A "KE" Port INLET DRAIN INLET OUTLET OUTLET
www.jbj.co.uk/gear-pumps.html #DriveLineHarmony 31 Micro Hydraulic Gear Pumps U 0.25 R - U 0.5 R Series M¹⁰x¹ threads depth 9 mm. G¹⁄ threads depth 9 mm. Drain port (cover): G¹⁄ thread depth 8 mm. To mount the pump: n. 2 M5 screws, with a torque wrench setting fixed at 5.4 ± 0.5 Nm. Type Displacement Flow at Maximum Pressure Maximum Dimensions 1500 rev/min P P P Speed M N L D I 2 3 3 cm /rev litres/mim bar bar bar rpm mm mm mm U 0.25 R 18 0,19 0,29 150 170 190 7000 54 44,5 24 M10x1 U 0.25 R 24 0,26 0,38 150 170 190 7000 55 45,5 24,5 M10x1 U 0.25 R 30 0,32 0,48 150 170 190 7000 56 46,5 25 M10x1 U 0.25 R 36 0,38 0,58 150 170 190 7000 57 47,5 25,5 M10x1 U 0.25 R 48 0,51 0,77 150 170 190 7000 59 49,5 26,5 M10x1 U 0.25 R 60 0,64 0,96 150 170 190 7000 61 51,5 27,5 M10x1 U 0.5 R 0,50 0,50 0,75 150 170 190 7000 63 53,5 28,5 G1/4 U 0.5 R 0,75 0,63 0,94 150 170 190 7000 64 54,5 29 G1/4 U 0.5 R 1,00 0,88 1,31 150 170 190 7000 66 56,5 30 G1/4 U 0.5 R 1,30 1,00 1,50 150 170 190 6000 67 57,5 30,5 G1/4 U 0.5 R 1,60 1,25 1,88 150 170 190 5000 69 59,5 31,5 G1/4 U 0.5 R 2,00 1,50 2,25 150 170 190 4000 71 61,5 32,5 G1/4 M N D 55 L 8 8 5 21 n.2 5.5 M6 7.68 2 +-00 .014 7.32 G1/8 6.8 6 +-00 .01 32 50 2 Ø22- - 00 . . 00 52 3 30 4 D 9.5 5- - 00 . . 00 51 Ø8 5.5 A A B B "G" Shaft B-B A-A DRAIN
Type Displacement Flow at Maximum Pressure Maximum Dimensions 1500 rev/min P P P Speed M N I 2 3 3 cm /rev litres/mim bar bar bar rpm mm mm U 0.25 R 18 KX 0,19 0,29 150 170 190 7000 54 44,5 U 0.25 R 24 KX 0,26 0,38 150 170 190 7000 55 45,5 U 0.25 R 30 KX 0,32 0,48 150 170 190 7000 56 46,5 U 0.25 R 36 KX 0,38 0,58 150 170 190 7000 57 47,5 U 0.25 R 48 KX 0,51 0,77 150 170 190 5000 59 49,5 U 0.25 R 60 KX 0,64 0,96 150 170 190 5000 61 51,5 U 0.5 R 0,50 KX 0,50 0,75 150 170 190 5000 63 53,5 U 0.5 R 0,75 KX 0,63 0,94 150 170 190 5000 64 54,5 U 0.5 R 1,00 KX 0,88 1,31 150 170 190 5000 66 56,5 U 0.5 R 1,30 KX 1,00 1,50 150 170 190 4000 67 57,5 U 0.5 R 1,60 KX 1,25 1,88 150 170 190 3500 69 59,5 U 0.5 R 2,00 KX 1,50 2,25 150 170 190 3000 71 61,5 To mount the pump: n. 2 M5 screws, with a torque wrench setting fixed at 5.4 ± 0.5 Nm. www.jbj.co.uk/gear-pumps.html #DriveLineHarmony 32 Micro Hydraulic Gear Pumps U 0.25 R KA - U 0.5 R KA Series n.3 9.6 n.3 5.5 16 M 5 N 19 55 4 16 9.5 Ø8 21 8 8 n.2 5.5 M6 7.68 2 +-00 .014 6.8 7.32 Ø22- - 00 . . 00 52 3 32 50 30 6 +-00 .01 5- - 00 . . 00 51 5.5 n.3 524980 A A B B Albero "G" "G" Shaft B-B A-A DRENAGGIO DRAIN
www.jbj.co.uk/gear-pumps.html #DriveLineHarmony 33 Micro Hydraulic Gear Pumps U 0.25 R VN - U 0.5 R VN Series Inlet port: G¹⁄ thread depth 12mm. To mount the pump: n. 2 M5 screws, with a torque wrench setting fixed at 5.4 ± 0.5 Nm. OPTIONS “KE”: D inlet and outlet ports aremachined on both body sides, only; M10x1 threads depth 9mm, G¹⁄ threads depth 9mm. “L”: available with outlet port machined on the body (“KE” version) or, alternatively, on the flange (“KX” version). Option available for type 0.25, only. Inlet port: G¹⁄ thread depth 9.5 mm. Type Displacement Flow at Maximum Pressure Maximum Dimensions 1500 rev/min P P P Speed M N L D I 2 3 3 cm /rev litres/mim bar bar bar rpm mm mm mm U 0.25 R 18 VN KX 0,19 0,29 150 170 190 7000 61,5 44,5 24 M10x1 U 0.25 R 24 VN KX 0,26 0,38 150 170 190 7000 62,5 45,5 24,5 M10x1 U 0.25 R 30 VN KX 0,32 0,48 150 170 190 7000 63,5 46,5 25 M10x1 U 0.25 R 36 VN KX 0,38 0,58 150 170 190 7000 64,5 47,5 25,5 M10x1 U 0.25 R 48 VN KX 0,51 0,77 150 170 190 7000 66,5 49,5 26,5 M10x1 U 0.25 R 60 VN KX 0,64 0,96 150 170 190 7000 68,5 51,5 27,5 M10x1 U 0.5 R 0,50 VN KX 0,50 0,75 150 170 190 7000 70,5 53,5 28,5 G1/4 U 0.5 R 0,75 VN KX 0,63 0,94 150 170 190 7000 71,5 54,5 29 G1/4 U 0.5 R 1,00 VN KX 0,88 1,31 150 170 190 7000 73,5 56,5 30 G1/4 U 0.5 R 1,30 VN KX 1,00 1,50 150 170 190 6000 74,5 57,5 30,5 G1/4 U 0.5 R 1,60 VN KX 1,25 1,88 150 170 190 5000 76,5 59,5 31,5 G1/4 U 0.5 R 2,00 VN KX 1,50 2,25 150 170 190 4000 78,5 61,5 32,5 G1/4 16 16 n.2 5.5 n.2 9.6 M N 5 53 7.327.68 G1/8 14 L D 21 88 32 G1/4 n.2 5.5 M6 4 6.8 2 +-00 .014 30 5 50 76 Ø22- - 00 . . 00 52 3 6.5 9.8 9.5 5- - 00 . . 00 51 Ø8 5.5 6 +-00 .01 B B n.2 524980 B B Porta "KE" "KE" Port"L" Port Porta "L" Albero "G" "G" Shaft B-B A-A ASPIRAZIONE INLET DRENAGGIO DRAIN ASPIRAZIONE INLET MANDATA OUTLET MANDATA OUTLET
