01737 767493 info@jbj.co.uk www.jbj.co.uk - registered in England No: 1185469 - jbj Techniques Limited is ISO certificated, committed to international coordination & unification of industrial standards. A range of products ATEX certificated to directive 94/9/E requirements GHM Series Gear Motors The GHM series offer identical configurations to the ALM series but more robust thanks to the cast iron front flange and rear cover. ALM Series Gear Motors For medium to high pressure rates the ALM series is ideal for mobile and industrial sectors. Mono-directional and bi-directional with internal and external drain available. ALPC/GHPC Series Short Multiple Gear Pumps For reduced axial layout. Available with both flanges and covers in aluminium or cast iron. High production rates, performance consistency and absolute reliability ensure this a benchmark product for the hydraulic power pack market. 1P Series Gear Pumps Extensive range and very high performance of these pumps integrated in to micro power packs make them ideal for many applications from aerospace to marine, medical to automotive. 0.25 - 0.5 Series Micro Gear Pumps This product range includes pumps of displacements (up to 200cc/rev) in a full aluminium configuration, able to withstand medium to high pressures and using different versions of flanges (European, German and SAE), porting and shafts. Mono-directional as well as reversible. ALP Series Gear Pumps The GHP series offer identical configurations to theALP series and guarantees extreme reliability in very high pressure applications. Ideal for mobile applications from agricultural to construction machines as the cast iron allows more flange, cover and port options. GHP Series Gear Pumps Modularity and flexibility are the characteristics of these pumps. They allow the assembly of pump modules of the ALP and GHP (from 0.25 to 4) enabling solutions to a wide range of application requirements. Ideal pump for applications which require a fast approach and/or return of the actuator at low loads and slow motion of the actuator at high loads. e.g. log splitters, compactors & presses. Volumetric andmechanical efficiencies as well as low noise levels are further benefits of this range. High/Low 2-Pass Gear Pumps ALP/GHP Series Multiple Modular Gear Pumps ELIKA® The low noise, low pulsation helical gear pump. Groups 2, 3, 4 and multiple pumps. www.jbj.co.uk/gearpumps.html Reduces the noise level by up to 20 dBA. jbj Techniques Limited, UK distributor for www.jbj.co.uk/gear-motors.html #DriveLineHarmony
Gear Motors Basic Design 2 7 5 8 9 3 1 4 8 9 6 3 10 11 BASIC MOTOR’S PARTS 1 - Drive Gear 2 - Driven gear 3 - Bushings 4 - Body 5 - Flange 6 - Cover 7 - Rotary shaft seal 8 - Compensation seals 9 - Anti-extrusion seals - stop Ring - support ring Generally these gear motors usually consist of a gear pair supported by two aluminum bushings, a body, a securing flange and a cover. Shaft of the driving gear projecting beyond the flange mounts a seal ring coupled with a metallic ring to strengthen the solution; both rings are held in place by an elastic securing ring. The body is profiled by means of extrusion and it is made of a special aluminium alloy with high strength for minimized deformation even when subject to high pressure. Marzocchi Pompe has renewed its own range of products, now launched with the new name of GHM1, GHM2 and GHM3, suitable for the widest range of application, both in the industrial and themobile sector. Gear motors convert hydraulic pressure and flow into torque and angular displacement, rotary mechanical power, applied to a load via the shaft. They feature versatility, strength and long useful life. Their simple construction compared to other types of motors (piston, orbital, etc) ensures limited purchase costs and servicing. Thanks to these basic concepts, together with ever-improving product design and features, research-based on many years of experience, accuracy in material selection, production process followed in great detail and tests on mass-produced parts, jbj Techniques can provide Marzocchi gear motors with top quality standards that can work under heavy operating conditions and transmit high hydraulic power. Furthermore, these gear motors feature good hydraulic, mechanical and volumetric efficiency, low noise level and compact dimensions with lowweight/power ratio. The flanges and covers are made out of cast iron, obtained through a process of continuous flow casting and with a final surface treatment of phosphating. Gears are made of special steel. Their manufacturing process includes case-hardening and quench hardening. Then gears are ground and fine finished so to have a high degree of surface finishing. Proper tooth profile design and geometric proportions ensure low pulsation levels and low noise levels during motor operation. Bushings aremade of special low-friction and hi-resistant aluminium alloy andmanufactured fromdie-casting that have excellent characteristics of high strength and anti-friction properties. Also equipped with anti-friction DU bearings with tight tolerance. Special and symmetric compensation zones onto bushings, insulated by special preformed seals with special anti-extrusion ring, allow fully free axial and radial movement to the bushings, which is proportional to motor operating pressure. In this way, internal leakage is dramatically reduced, thus ensuring very good pump performance (both in terms of mechanical and total efficiencies) and proper lubrication of pumpmoving parts. www.jbj.co.uk/gear-motors.html #DriveLineHarmony 10 11 6
Gear Motors GHM Series Product Range Produced in three different groups with very good power/weight ratio and power/size ratio allowing a wide range of displacements within each group (between 2.8 and 87 cc/rev). The wide range of allowed speeds, the excellent functionality also on their use in series, with strong counter-pressures and limited drain, give to motors of the GHM series very good characteristics even starting under load. The drain is always external and it is through a thread port on the cover. Arange of flanges, shafts, inlet and pressure ports are available. These motors are without external drain and can be used with counter-pressures of maximum 6 bars; they can be used in both left (GHM...S) or right (GHM...D) configuration. The available displacements for the GHM1 group are between 1.4 to 11 cc/rev, for the group GHM2 between 4.5 to 28.2 cc/rev while for the group GHM3 between 20 and 87 cc/rev. For applications that require counterpressures higher than 6 bar please contact jbj Techniques technical office, email: info@jbj.co.uk or telephone: +44(0)1737 767493. Mono-directional motors. Bi-directional motors. 7 www.jbj.co.uk/gear-motors.html #DriveLineHarmony 1.4 2.1 2.8 3.5 4.1 5.2 6.2 7.6 9.3 11.0 GHM1 Series 4.5 6.4 7.08.3 9.6 11.5 14.1 16.0 25.5 28.2 GHM2 Series 23.7 21.1 17.9 20 22 26 33 39 44 52 78 87 GHM3 Series 71 61 3 Displacement (cm /rev) "VV"Version suitable for fluid at high temperatures. "V"Version suitable for fluid at high temperatures. "H"Version suitable for fluid at low temperature. For special uses are also available: Range between -10°C and +120°C. In the range between -10°C and +80°Cmaximum pressures as stated in the individual product tables are allowed; beside that figures in the ‘PC’ column of the tables should not be exceeded. Range between -10°C and +150°Cwithmaximumpressure 20 bar Range between -40°C and +120°C. In the range between -10 °C and +80°C maximum pressures as stated in the individual product table; below and beside that figures in the ‘PC’ column of the tables should not be exceeded. Special Versions Range between -40°C and +80°C. In the range between -10 °C and +80°C maximum pressures as stated in the product table; below that figures in the ‘PC’ column of the tables should not be exceeded. The above descriptions are to be specified in the SEALfield of the ordering code. "ST"Version suitable for fluid at high or low temperature.
InstallationNotes Remove all dirt, particles and all foreign bodies from flanges connecting inlet and delivery ports. In the case of amono-directional motor check for the direction of rotation of the pump to be consistent with the inlet side. Before starting the systemon a continuous basis, we suggest to adopt some simple precautions. It is essential for correct running, top performance and longer life of the GHM series hydraulic gear motors to follow the installation and running information provided in this catalogue. Ensure that intake of the supply pump and return pipes ends are always below fluid level and as far fromeach other as possible. Some general considerations should be made regarding the hydraulic system, in which the motor is to be fitted. Special attention should be given to hydraulic system design and assembly, especially to intake, delivery, return and drain pipes and position of system parts (valves, filters, tanks, heat exchangers and accumulators). Check for the proper alignment of motor shaft and that of the driven part. It is necessary that the connection does not induce axial or radial loads. Protect drive shaft seal duringmotor painting. Check if contact area between seal ring and shaft is clean: dust could cause quicker wear and leakage. Disconnect supply pump drain during startup to bleed air off the circuit. Proper safety devices and reliable instruments to avoid fluid turbulence and prevent air, water or foreign bodies from entering into the system are of major importance. It is also very important to equip the hydraulic systemwith a proper filtering unit. At first startup, set pressure limiting valves at minimum value possible. Do not allow the motor to run at speed lower than minimum allowed with pressure higher than the figures indicated in the ‘PI’ column of model specific data tables. Do not start the systemat low temperatures under load conditions or after long stops. Start the system for a fewminutes and turn on all components. Bleed air off the circuit to check its proper filling. It is widely known that most motors early failures are due to contaminated fluids. The extreme reduction of the tolerances required in the design of the motors and therefore their operation with minimum clearances, are heavily influenced by a fluid that is not perfectly clean. It is proved that particles circulating in the fluid act as abrasive agents, damaging the surfaces they touch and increasing the quantity of contaminant. For this reason, ensure that system is perfectly clean during startup and keep it clean for its whole operating life. Necessary interventions to check and limit contamination should be performed in a preventive and corrective way. Preventive actions include: proper cleaning of the systemduring assembly, deburring, eliminating the welding scumand fluid filtering before filling up. Check fluid level in the tank after loading all components. Lastly, gradually increase pressure, continuously check fluid and moving parts temperatures. Check rotation speed until you reach set operating values that must be within themodel specific limits indicated in this catalogue. CleaningAnd Filtering The System Starting contamination level of system fluid should not exceed class 18/15 (ref. ISO 4406). Even fresh fluids might exceed this contamination level; therefore always pre-filter the fluid when filling up or topping up the system. Fit a proper tank; its capacity should be proportional to the volume displaced in one working minute. Gear Motors GHM Series Installation and Running Information 8 www.jbj.co.uk/gear-motors.html #DriveLineHarmony
Gear Motors GHM Series Installation and Running Information 9 www.jbj.co.uk/gear-motors.html #DriveLineHarmony It is recommended to use a filtering systemhaving absolute filtering capability of 5 μmor lower in the systems using sophisticated valve slaves. Ratiobx = 75 25-40 μm 12-15 μm 6 -12 μm ISO4406 Class 19/16 18/15 17/14 It is then very important to limit not only maximum dimensions, but also the number of smaller particles that pass through the filter. It goes without saying that with an operating pressure increase and according to the system sophistication degree, filtering should becomemore andmore efficient. The filtering system shall always ensure contamination levels not exceeding the values indicated below: Fluid contamination level check and correction during operation can be obtained through filters that retain the particles present in the fluid itself. Two parameters tell which filter is most suitable: absolute filtering power andbfiltering ratio. Low absolute filtering power and highbfiltering ratio for small particles help ensuring good filtration. Pressure <140 bar 140 to 210 bar >210 bar NAS 1638 Class 10 9 8 Fluid kinematic viscosity ranges are the following: If fluids other than the above mentioned ones are used, please always indicate type of used fluid and operating conditions so that jbj Techniques technical officecan consider possible problems with compatibility or useful life of systemparts. For the standardmodels, the temperature of the fluid should be between -10°C and +80°C. Size 6 9 10 12 13 16 20 22 25 30 34 37 40 Use specific mineral oil based hydraulic fluids having good anti-wear, anti-foaming (rapid deaeration), antioxidant, anti-corrosion and lubricating properties. Fluids should also comply with DIN 51525 and VDMA24317 standards and get through 11th stage of FZG test. Min. Speed (rpm) 800 700 500 value allowed at startup <2000 cSt Size 33 40 50 60 66 80 94 110 120 135 Hydraulic Fluids The versatility of the GHM series motors can be perceived from the wide range of rotation speeds they can be subject to: maximum values are indicated in product tables and change according to themodel, whileminimum values are as follows: Group GHM1 Min. Rotation Speed Group GHM2 recommended value 10 to 100 cSt allowed value (uppon verification) 6 to 500 cSt Group GHM3 Size 4 5 6 7 9 11 13 16 Min. Speed (rpm) 700 Min. Speed (rpm) 600 500 400
Gear Motors GHM Series Installation and Running Information 10 www.jbj.co.uk/gear-motors.html #DriveLineHarmony Speed (rpm) 2500 2000 1800 1500 1000 Pressure Definition Product tables show threemax. pressure levels (PC, PI and PP) to which eachmotor can be used. PC =max pressure continually as output counterpressure. PI =max inlet pressure continually. PP=max peak inlet pressure. The value of themaximum continuous PI pressure can be reached only if the following ranges of rotation are not overcome. Group GHM1 Size 4 5 6 7 9 11 13 16 Speed (rpm) 3500 2500 2000 1800 Group GHM2 Size 6 9 10 12 13 16 20 22 25 30 34 37 40 Speed (rpm) 3000 2500 2600 1800 1500 Group GHM3 Size 33 40 50 60 66 80 94 110 120 135 Hydraulic systempipes should show no sudden changes of direction, sharp bends and sudden differences in cross-section. They should not be too long or out of proportion. Pipe cross-section should be sized so that fluid velocity does not exceed recommended values. It is advisable to carefully consider the possible diameter reduction of the inlet or outlet pipes fitted on flange fittings. Reference values are the following: Drain line 0.5 to 1.6m/s Supply &Delivery Lines Direction of Rotation therefore with right. "D" rotation, if its rotation will be clockwise and therefore the inlet port will be on the left while the outlet port will be on the right. Vice-versa it will be amono-directional left GHM...S therefore with left "S" rotationmaintaining of course the same view of observation. The motors of the GHM series can be supplied both in mono-directional version and bi-directional. The direction of rotation is defined in the following way: looking at the front of themotor with the driver shaft positioned upward and sticking toward the observer, it will be amono-directional right "D". GHM...Dmotor Please contact jbj Techniques technical department, email: info@jbj.co.uk or telephone: +44 (0)1737 767493 for system operating conditions other than indicated in the product tables. Input and delivery line 2 to 6m/s S = counter-clockwise rotation INPUT OUTPUT D = clockwise rotation INPUT OUTPUT R = reversible rotation The bi-directional GHM series motors, "R" have both functional characteristics of the mono-directional motors with clockwise and counterclockwise rotation.
*HDU 0RWRUV *+0 6HULHV ,QVWDOODWLRQ DQG 5XQQLQJ ,QIRUPDWLRQ ZZZ MEM FR XN JHDU PRWRUV KWPO 'ULYH/LQH+DUPRQ\ 'S SUHVVXUH GLႇHUHQWLDO >EDU@ 4 ÀRZ UDWH >OLWHU PLQ @ &RQWDFW MEM 7HFKQLTXHV WHFKQLFDO RႈFH HPDLO LQIR#MEM FR XN RU WHOHSKRQH IRU IXUWKHU GHWDLOV RQ HႈFLHQF\ &DOFXODWH K\GUDXOLF SRZHU 3 GHOLYHUHG E\ DPRWRU VXEMHFW WR D SUHVVXUH GLႇHUHQWLDO EHWZHHQ LQSXW DQG RXWSXW DV IROORZV 3 4 'S KWRW >N:@ KWRW WRWDO SXPS HႈFLHQF\ KKP KYRO 9DOXHV IRU KYRO DQGKKP DQG FRQVHTXHQWO\KWRW GHSHQG RQ SUHVVXUH GLႇHUHQWLDO EHWZHHQ VXSSO\ DQG GHOLYHU\ URWDWLRQ VSHHG ÀXLG IHDWXUHV WHPSHUDWXUH DQG YLVFRVLW\ DQG ¿OWHULQJ GHJUHH 7KH SURSHU YDOXHV IRU ÀRZ UDWH WRUTXH DQG VXSSOLHG DFFRUGLQJ WR SUHVVXUH GLႇHUHQWLDO URWDWLRQ VSHHG DQG VHW WHVW FRQGLWLRQV FDQ EH IRXQG RQ WKH 3HUIRUPDQFH &XUYHSDJHV &DOFXODWH ÀRZ UDWH 4 DV IROORZV )UHTXHQWO\ 8VHG )RUPXODV Y 4 $>P V@ 'ULYH )OXLG YHORFLW\ &DOFXODWH WKH YHORFLW\ Y RI D ÀXLG LQ D SLSH DV IROORZV 7KH OLQN EHWZHHQ WKH PRWRU DQG WKH GULYHQ GHYLFH PXVW EH YLD D PHFKDQLFDO SRZHU WUDQVPLVVLRQ FRXSOLQJ WKDW ZLOO QRW WUDQVIHU UDGLDO DQG RU D[LDO WKUXVW WR WKH VKDIW RI WKH PRWRU RWKHUZLVH ZHDU RI WKH LQWHUQDO FRPSRQHQWV ZLOO TXLFNO\ RFFXU MEM 7HFKQLTXHV KDYH D ZLGH UDQJH RI VXLWDEOH FRXSOLQJV WR VXLW D ZLGH UDQJH RI DSSOLFDWLRQV DQG ZH FDQ DGYLVH RQ ZKLFK FRXSOLQJ GHSHQGLQJ RQ WKH FLUFXPVWDQFHV RI WKH DSSOLFDWLRQ ,Q FDVH RI D[LDO DQG RU UDGLDO ORDGV RQ WKH PRWRU¶V VKDIW 7 RSWLRQ LV DYDLODEOH IRU VRPH *+0 PRGHOV DQG 5$ RSWLRQ LV DYDLODEOH IRU VRPH *+0 W\SHV )RU IXUWKHU GHWDLOV FRQWDFW MEM 7HFKQLTXHV WHFKQLFDO RႈFH HPDLO LQIR#MEM FR XN RU WHOHSKRQH 4 ÀRZ UDWH >OLWHU PLQ@ $ LQVLGH DUHD RI SLSH >FPð@ $EVRUEHG ÀRZ UDWH Q URWDWLRQ VSHHG >URWDWLRQV SHU PLQXWH@ 9 GLVSODFHPHQW >FPñ URWDWLRQ@ KYRO SXPS YROXPHWULF HႈFLHQF\ WDNH DV DQ LQGLFDWLYH YDOXH IRU URWDWLRQ VSHHGV UDQJLQJ EHWZHHQ DQG URWDWLRQV SHU PLQXWH 'HOLYHUHG WRUTXH &DOFXODWH QHFHVVDU\ WRUTXH 0 RI DPRWRU VXEMHFW WR SUHVVXUH GLႇHUHQWLDO EHWZHHQ LQSXW DQG RXWSXW DV IROORZV 0 9 'S KKP >1P@ 4 9 Q KYRO >OLWUH PLQ@ 9 GLVSODFHPHQW >FPñ URWDWLRQ@ 'S SUHVVXUH GLႇHUHQWLDO >EDU@ KKP K\GURPHFKDQLFDO HႈFLHQF\ WDNH DV LQGLFDWLYH YDOXH XQGHU FROG FRQGLWLRQV DQG XQGHU ZRUNLQJ FRQGLWLRQV 'HOLYHUHG SRZHU
D Type Rotation Size Ports* Seals* Options* omit A AQ Clockwise S Counter Clockwise GHM1 Drain** R Reversible Motor Standard Types omit = European flange + shaft T0 + ports E + standard seals. A= flangeA+ shaft C1 + ports FA+ standard seals. GHM1A-D-2-S1 = clockwise rotation, 1.4 cc/rev, SAEA-A2 bolt flange, splined shaft 9T (S1), threaded ports, standard seals. GHM1-D-2-FG-V = clockwise rotation, 1.4 cc/rev, European flange,1:8 tapered shaft, threaded ports (FG), high temperature seals (V). Examples GHM1-D-2 = clockwise rotation, 1.4 cc/rev, European flange,1:8 tapered shaft, flanged ports E type, standard seals. AQ= flangeAQ+ shaft C2 + ports FA+ standard seals. GHM1-R-4-E1 = reversiblemotor, 2.8 cc/rev, European flange,1:8 tapered shaft, flanged ports E type, standard seals, external drain (E1). The product data sheets show our standard model types. The synoptic tables for flanges, shafts and ports show all the possible configurations. For further details about the availability of each configuration please contact jbj Techniques technical office, email: info@jbj.co.uk or telephone: +44 (0)1737 767493 Gear Motors GHM1 Series Ordering Code Shaft* (*) = to be specified if different from standard “motor type”. ... E2 = external drain ⁹⁄ -18 UNF*** omit (T range = -10°C + 80°C) ... (***) = "E2" drain port is machined in compliance with threaded port with O-ring seal in truncated housing SAE J1926/1 (ISO 11926-1). V RA (**) = only for R rotation. E0 = internal drain Options ... Drain E1 = external drain G1/4 Seals Thread depth 12,7 mm. 12 www.jbj.co.uk/gear-motors.html #DriveLineHarmony ... ... 4 5 6 7 9 11 13 16 ...
Gear Motors GHM1 Series Accessories supplied with the standard motor: woodruff key (code 522054), M10x1 exagonal nut (code 523015), washer (code 523004). Standard ports: M6 threads depth 13 mm. G1/4 drain port thread depth 12 mm. 13 www.jbj.co.uk/gear-motors.html #DriveLineHarmony 1500 rev/min P P P Speed L M I C P GHM1-R-4-E1 2,8 3,9 270 260 290 5000 42 83 Type Displacement Flow at Maximum Pressure Maximum Dimensions 3 cm /rev litres/mim bar bar bar rpm mm mm GHM1-R-5-E1 3,5 4,9 270 260 290 5000 43 85 GHM1-R-6-E1 4,1 5,9 270 260 290 4000 44 87 GHM1-R-7-E1 5,2 7,4 260 250 275 4000 45,5 90 GHM1-R-9-E1 6,2 8,8 260 250 275 3800 47 93 GHM1-R-11-E1 7,6 10,8 230 220 245 3200 49 97 GHM1-R-13-E1 9,3 13,3 210 200 225 2600 51,5 102 GHM1-R-16-E1 11,0 15,7 200 190 215 2200 54 107
Gear Motors GHM1A Series Mounting flange 50-2 (A-A) in compliance with SAE J744c. Accessories supplied with the standard motor: key (code 522070). G1/4 drain port thread depth 12 mm. “D” standard ports are machined in compliance with threaded port with O-ring seal in truncated housing SAE J1926/1 (ISO 11926-1). 14 www.jbj.co.uk/gear-motors.html #DriveLineHarmony 1500 rev/min P P P Speed L M D I C P GHM1A-R-16-E1 11,0 15,7 200 190 215 2500 56 109 ⁷⁄ -14 UNF GHM1A-R-11-E1 7,6 10,8 230 220 245 3500 51 99 ⁷⁄ -14 UNF GHM1A-R-13-E1 9,3 13,3 210 200 225 3000 53,5 104 ⁷⁄ -14 UNF GHM1A-R-7-E1 5.2 7.4 260 250 275 3500 47.5 92 ³⁄ -16 UNF 3 cm /rev litres/mim bar bar bar rpm mm mm mm Type Displacement Flow at Maximum Pressure Maximum Dimensions GHM1A-R-5-E1 3,5 4,9 270 260 290 5000 45 87 ³⁄ -16 UNF GHM1A-R-4-E1 2.8 3.9 270 260 290 5000 44 85 ³⁄ -16 UNF GHM1A-R-9-E1 6.2 8.8 260 250 275 3000 49 95 ³⁄ -16 UNF GHM1A-R-6-E1 4.1 5.9 270 260 290 4000 46 89 ³⁄ -16 UNF
Gear Motors GHM1AQ Series Accessories supplied with the standard motor: key (code 522223). G1/4 drain port thread depth 12 mm. "D" standard ports are machined in compliance with threaded port with O-ring seal in truncated housing SAE J1926/1 (ISO 11926-1). 15 www.jbj.co.uk/gear-motors.html #DriveLineHarmony Type Displacement Flow at Maximum Pressure Maximum Dimensions 1500 rev/min P P P Speed L M D I C P 3 cm /rev litres/mim bar bar bar rpm mm mm mm GHM1AQ-R-4-E1 2.8 3.9 270 260 290 5000 61 102 ³⁄ -16 UNF GHM1AQ-R-5-E1 3.5 4.9 270 260 290 5000 62 104 ³⁄ -16 UNF GHM1AQ-R-6-E1 4.1 5.9 270 260 290 4000 63 106 ³⁄ -16 UNF GHM1AQ-R-7-E1 5.2 7.4 260 250 275 3500 64.5 109 ³⁄ -16 UNF GHM1AQ-R-9-E1 6.2 8.8 260 250 275 3000 66 112 ³⁄ -16 UNF GHM1AQ-R-11-E1 7.6 10.8 230 220 245 3500 68 116 ⁷⁄ -14 UNF GHM1AQ-R-16-E1 11,0 15,7 200 190 215 2500 73 126 ⁷⁄ -14 UNF GHM1AQ-R-13-E1 9.3 13.3 210 200 225 3000 70,5 121 ⁷⁄ -14 UNF
T0 C0 A C1 S1 AQ C2 S2 G1 G0 Max Torque 100 Nm Max Torque 55 Nm Max Torque 60 Nm Max Torque 100 Nm Max Torque 45 Nm Max Torque 60 Nm Max Torque 90 Nm Max Torque 45 Nm Flanges Shafts Gear Motors Flanges & Shafts GHM1 Series 16 www.jbj.co.uk/gear-motors.html #DriveLineHarmony A range of composite bellhousings to accommodate electric motor flanges from 300 mm diameter to 800 mm diameter. See pages 40 to 44 of the Pump Drive Components technical specification catalogue. www.jbj.co.uk/hydraulic-adaptors.html jbj's in-house design teamandmanufacturing facility provide tailored solutions for your applications at competitive prices with quick delivery. The package consists of a bellhousing and flexible drive coupling that are fully machined to suit the pump and any driving interface; diesel or petrol engine, electric or hydraulic motor. Acollection of different ways of connecting hydraulic pumps andmotors to various driver devices. Allow close coupling of hydraulic pumps directly to the flywheel / flywheel housing of diesel engines, electric and hydraulic motors.
GHM1…4 to GHM1…9 ³⁄ -16 UNF ⁹⁄ -18 UNF GHM1…11 to GHM1…16 ⁷⁄ -14 UNF ³⁄ -16 UNF GHM1…4 to GHM1…16 Rc¹⁄ Rc¹⁄ E FG FC FA GHM1…4 to GHM1…16 30 13 M6 30 13 M6 GHM1…4 to GHM1…5 G¹⁄ G³⁄ GHM1…6 to GHM1…16 G¹⁄ G¹⁄ Tightening torques of the fittings screws are specified on page 52 (accessories section). Ports Gear Motors Ports GHM1 Series 17 www.jbj.co.uk/gear-motors.html #DriveLineHarmony Tightening torques for Rc¹⁄ fitting: 50 Nm. Please check with the fittings suppliers. Tightening torques for 9/16-18 UNF fitting: 30 Nm. Tightening torques for 3/4-16 UNF fitting: 60 Nm. Tightening torques for 7/8-14 UNF fitting: 70 Nm. Please check with the fittings suppliers. Tightening torques for G¹⁄ fitting: ⁵⁰ Nm. Tightening torques for G³⁄ fitting: ³⁵ Nm. Please check with the fittings suppliers. Bi-directional Motor Mono-directional motor Output -Input Input Type A B C A B C Bi-directional Motor Mono-directional motor Output -Input Type A A Input Bi-directional Motor Mono-directional motor Output -Input Type Input A A Bi-directional Motor Mono-directional motor Output -Input Type Input A A
5 18 www.jbj.co.uk/gear-motors.html #DriveLineHarmony Gear Motors Performance Curves GHM1 Series Each curve has been obtained at 50°C, using oil with viscosity 30 cSt at these pressure. 7 9 25-270 bar 5 6 25-280 bar 4 25-300 bar 11 25-230 bar 16 25-170 bar 13 25-190 bar
19 www.jbj.co.uk/gear-motors.html #DriveLineHarmony Gear Motors Performance Curves GHM1 Series Delivered power P [kW]. Delivered torque M [Nm]. Drive speed n [giri/min] [rpm]
20 www.jbj.co.uk/gear-motors.html #DriveLineHarmony Gear Motors Performance Curves GHM1 Series Delivered power P [kW]. Delivered torque M [Nm]. Drive speed n [giri/min] [rpm]
D Type Rotation Size Ports* Seals* Options* omit A A2 BK1 Clockwise S Counter Clockwise GHM2 Drain** R Reversible Motor Standard Types A3 = flangeA3 + shaft C3 + ports FA+ standard seals. GHM2A-R-6-OR-E2 = Reversible motor, 4.5 cc/rev, SAE A 2 bolt flange, cylindrical shaft C1, threaded ports FA, standard seal, OR seal on pilot, external drain (E2). BK2 = flange BK2 + shaft T2 + ports D + standard seals. GHM2-D-6 = Clockwise rotation, 4.5 cc/rev, European flange,1:8 tapered shaft, flanged ports E type, standard seals. Examples GHM2BK2-D-6-E = Clockwise rotation, 4.5 cc/rev, German square flange, 1:5 tapered shaft , European flanged ports (E), standard seals. GHM2A-D-6-KA= Clockwise rotation, 4.5 cc/rev, SAEA2 bolt flange, cylindrical shaft, standard seals, UNF threaded rear ports (KA). BK7 = flange BK7 + shaft G0 + ports D + standard seals. BK4 = flange BK4 + shaft T2 + ports D + standard seals. A= flangeA+ shaft C1 + ports FA+ standard seals. The product data sheets show our standard model types. The synoptic tables for flanges, shafts and ports show all the possible configurations. For further details about the availability of each configuration please contact jbj Techniques technical office, email: info@jbj.co.uk or telephone: +44 (0)1737 767493 BK1 = flange BK1 + shaft T1+ ports D + standard seals. omit = European flange + shaft T0 + ports E + standard seals. GHM2-R-13-E1 = Reversiblemotor, 9.6 cc/rev, European flange, 1:8 tapered shaft , flanged ports E type, standard seals, external drain (E1). Gear Motors GHM2 Series Ordering Code Shaft* omit (T range = -10°C + 80°C) V Options OR**** ... ... T KA Drain E1 = external drain G1/4 E2 = external drain 9/16-18 UNF*** E4 = external drain 7/16-20 UNF*** (only for KA ports) (*) = to be specified if different from standard “motor type”. (**) = only for R rotation. (***) = Drain ports are machined in compliance with threaded port with O-ring seal in truncated housing SAE J1926/1 (ISO 11926-1). Seals (****) = only for A and BK1 motor types. E0 = internal drain 21 www.jbj.co.uk/gear-motors.html #DriveLineHarmony 6 9 10 12 13 16 20 22 25 30 34 37 40 BK4 BK2 BK7
Gear Motors GHM2 Series Accessories supplied with the standard motor: woodruff key (code 522057), M12x1.5 hexagonal nut (code 523016), washer (code 523005). G1/4 drain port thread depth 12 mm. The tapered shaft is also available with 3,2 mm key ("T3"). Standard ports: M8 threads depth 17 mm. 22 www.jbj.co.uk/gear-motors.html #DriveLineHarmony Type Displacement Flow at Maximum Pressure Maximum Dimensions 1500 rev/min P P P Speed L M d h H I C P GHM2-R-9-E1 6,4 9,1 280 270 295 4000 47 95 13 M6 30 GHM2-R-10-E1 7 10 280 270 295 4000 47,5 96 13 M8 40 GHM2-R-12-E1 8,3 11,8 280 270 295 3500 48,5 98 13 M8 40 GHM2-R-13-E1 9,6 13,7 280 270 295 3000 49,5 100 13 M8 40 GHM2-R-16-E1 11,5 16,4 280 270 295 4000 51 103 19 M8 40 GHM2-R-6-E1 4,5 6,4 280 270 295 4000 45,5 92 13 M6 30 GHM2-R-20-E1 14,1 20,1 260 250 275 4000 53 107 19 M8 40 3 cm /rev litres/mim bar bar bar rpm mm mm mm GHM2-R-34-E1 23,7 33,7 230 220 245 3000 60,5 122 19 M8 40 GHM2-R-37-E1 25,5 36,4 210 200 225 2800 62 125 19 M8 40 GHM2-R-22-E1 16,0 22,8 260 250 275 4000 54,5 110 19 M8 40 GHM2-R-40-E1 28,2 40,1 200 190 215 2500 64 129 19 M8 40 GHM2-R-30-E1 21,1 30,1 230 220 245 3200 58,5 118 19 M8 40 GHM2-R-25-E1 17,9 25,5 260 250 275 3600 56 113 19 M8 40
Gear Motors GHM2A Series Accessories supplied with the standard motor: key (code 522067). Mounting flange 82-2 (A) in compliance with SAE J744c. 1/4-28 UNF thread depth 16 mm. Standard ports are machined in compliance with threaded port with O-ring seal in truncated housing SAE J1926/1 (ISO 11926-1). G1/4 drain port thread depth 12 mm. 23 www.jbj.co.uk/gear-motors.html #DriveLineHarmony 3 cm /rev litres/mim bar bar bar rpm mm mm GHM2A-R-10-E1 7 10 280 270 295 4000 47,5 96 GHM2A-R-20-E1 14,1 20,1 260 250 275 3200 53 107 1500 rev/min P P P Speed L M I C P Type Displacement Flow at Maximum Pressure Maximum Dimensions GHM2A-R-6-E1 4,5 6,4 280 270 295 4000 45,5 92 GHM2A-R-9-E1 6,4 9,1 280 270 295 4000 47 95 GHM2A-R-12-E1 8,3 11,8 280 270 295 4000 48,5 98 GHM2A-R-13-E1 9,6 13,7 280 270 295 4000 49,5 100 GHM2A-R-16-E1 11,5 16,4 280 270 295 4000 51 103 GHM2A-R-25-E1 17,9 25,5 260 250 275 2500 56 113 GHM2A-R-30-E1 21,1 30,1 230 220 245 2200 58,5 118 GHM2A-R-34-E1 23,7 33,7 230 220 245 2000 60,5 122 GHM2A-R-37-E1 25,5 36,4 210 200 225 1800 62 125 GHM2A-R-40-E1 28,2 40,1 200 190 215 1800 64 129 GHM2A-R-22-E1 16,0 22,8 260 250 275 2800 54,5 110
Gear Motors GHM2A3 Series Accessories supplied with the standard motor: key (code 522068). Mounting flange 101-2 (B) in compliance with SAE J744c. G1/4 drain port thread depth 12 mm. Standard ports are machined in compliance with threaded port with O-ring seal in truncated housing SAE J1926/1 (ISO 11926-1). 1/4-28 UNF thread depth 16 mm. 24 www.jbj.co.uk/gear-motors.html #DriveLineHarmony 3 cm /rev litres/mim bar bar bar rpm mm mm GHM2A3-R-9-E1 6,4 9,1 280 270 295 4000 66 114 GHM2A3-R-6-E1 4,5 6,4 280 270 295 4000 64,5 111 Type Displacement Flow at Maximum Pressure Maximum Dimensions 1500 rev/min P P P Speed L M I C P GHM2A3-R-12-E1 8,3 11,8 280 270 295 4000 67,5 117 GHM2A3-R-30-E1 21,1 30,1 230 220 245 2200 77,5 137 GHM2A3-R-16-E1 11,5 16,4 280 270 295 4000 70 122 GHM2A3-R-34-E1 23,7 33,7 230 220 245 2000 79,5 141 GHM2A3-R-25-E1 17,9 25,5 260 250 275 2500 75 132 GHM2A3-R-37-E1 25,5 36,4 210 200 225 1800 81 144 GHM2A3-R-10-E1 7 10 280 270 295 4000 66,5 115 GHM2A3-R-40-E1 28,2 40,1 200 190 215 1800 83 148 GHM2A3-R-22-E1 16,0 22,8 260 250 275 2800 73,5 129 GHM2A3-R-20-E1 14,1 20,1 260 250 275 3200 72 126 GHM2A3-R-13-E1 9,6 13,7 280 270 295 4000 68,5 119
Gear Motors GHM2BK1 Series Accessories supplied with the standard motor: woodruff key (code 522055), M12x1.5 hexagonal nut (code 523016), washer (code 523005). Standard ports: M6 threads depth 13 mm. G1/4 drain port thread depth 12 mm. 25 www.jbj.co.uk/gear-motors.html #DriveLineHarmony GHM2BK1-R-22-E1 16,0 22,8 260 250 275 4000 47,5 110 20 3 cm /rev litres/mim bar bar bar rpm mm mm mm GHM2BK1-R-9-E1 6,4 9,1 280 270 295 4000 41 95 15 GHM2BK1-R-12-E1 8,3 11,8 280 270 295 4000 48,3 98 15 GHM2BK1-R-6-E1 4,5 6,4 280 270 295 4000 39,8 92 15 GHM2BK1-R-25-E1 17,9 25,5 260 250 275 4000 55,8 113 20 GHM2BK1-R-13-E1 9,6 13,7 280 270 295 4000 43,1 100 20 GHM2BK1-R-37-E1 25,5 36,4 210 200 225 2600 61,8 125 20 GHM2BK1-R-34-E1 23,7 33,7 230 220 245 3000 55 122 20 GHM2BK1-R-10-E1 7 10 280 270 295 4000 47,3 96 15 GHM2BK1-R-20-E1 14,1 20,1 260 250 275 4000 47,5 107 20 GHM2BK1-R-30-E1 21,1 30,1 230 220 245 3400 47,5 118 20 GHM2BK1-R-16-E1 11,5 16,4 280 270 295 4000 47,5 103 20 Type Displacement Flow at Maximum Pressure Maximum Dimensions 1500 rev/min P P P Speed L M D I C P GHM2BK1-R-40-E1 28,2 40,1 200 190 215 2600 63,8 129 20
Gear Motors GHM2BK2 Series Standard ports: M6 threads depth 13 mm. Accessories supplied with the standard motor: woodruff key (code 522055), M12x1.5 exagonal nut (code 523016), washer (code 523005). To mount the motor: n.2 M10 screws with a torque wrench setting fixed at 46 ± 4 Nm. G1/4 drain port thread depth 12 mm. 26 www.jbj.co.uk/gear-motors.html #DriveLineHarmony GHM2BK2-R-37-E1 25,5 36,4 210 200 225 2600 59 122 20 GHM2BK2-R-13-E1 9,6 13,7 280 270 295 4000 40,3 97 20 GHM2BK2-R-25-E1 17,9 25,5 260 250 275 4000 53 110 20 Type Displacement Flow at Maximum Pressure Maximum Dimensions GHM2BK2-R-16-E1 11,5 16,4 280 270 295 4000 44,7 100 20 GHM2BK2-R-10-E1 7 10 280 270 295 4000 44,5 93 15 GHM2BK2-R-6-E1 4,5 6,4 280 270 295 4000 37 89 15 GHM2BK2-R-40-E1 28,2 40,1 200 190 215 2600 61 126 20 GHM2BK2-R-9-E1 6,4 9,1 280 270 295 4000 38,2 92 15 GHM2BK2-R-34-E1 23,7 33,7 230 220 245 3000 52,2 119 20 GHM2BK2-R-30-E1 21,1 30,1 230 220 245 3400 44,7 115 20 GHM2BK2-R-20-E1 14,1 20,1 260 250 275 4000 44,7 104 20 GHM2BK2-R-12-E1 8,3 11,8 280 270 295 4000 45,5 95 15 1500 rev/min P P P Speed L M D I C P GHM2BK2-R-22-E1 16,0 22,8 260 250 275 4000 44,7 107 20 3 cm /rev litres/mim bar bar bar rpm mm mm mm
Gear Motors GHM2BK4 Series To mount the motor: n.2 M10 screws with a torque wrench setting fixed at 46 ± 4 Nm. G1/4 drain port thread depth 12 mm. Accessories supplied with the standard motor: woodruff key (code 522055), M12x1.5 hexagonal nut (code 523016), washer (code 523005). Standard ports: M6 threads depth 13 mm. 27 www.jbj.co.uk/gear-motors.html #DriveLineHarmony Type Displacement Flow at Maximum Pressure Maximum Dimensions 1500 rev/min P P P Speed L M D I C P 3 cm /rev litres/mim bar bar bar rpm mm mm mm GHM2BK4-R-10-E1 7 10 280 270 295 4000 44,5 93 15 GHM2BK4-R-9-E1 6,4 9,1 280 270 295 4000 38,2 92 15 GHM2BK4-R-16-E1 11,5 16,4 280 270 295 4000 44,7 100 20 GHM2BK4-R-22-E1 16,0 22,8 260 250 275 4000 44,7 107 20 GHM2BK4-R-37-E1 25,5 36,4 210 200 225 2600 59 122 20 GHM2BK4-R-40-E1 28,2 40,1 200 190 215 2600 61 126 20 GHM2BK4-R-6-E1 4,5 6,4 280 270 295 4000 37 89 15 GHM2BK4-R-12-E1 8,3 11,8 280 270 295 4000 45,5 95 15 GHM2BK4-R-13-E1 9,6 13,7 280 270 295 4000 40,3 97 20 GHM2BK4-R-20-E1 14,1 20,1 260 250 275 4000 44,7 104 20 GHM2BK4-R-25-E1 17,9 25,5 260 250 275 4000 53 110 20 GHM2BK4-R-30-E1 21,1 30,1 230 220 245 3400 44,7 115 20 GHM2BK4-R-34-E1 23,7 33,7 230 220 245 3000 52,2 119 20
Gear Motors GHM2BK7 Series Standard ports: M6 threads depth 13 mm. To mount the motor: n.2 M10 screws with a torque wrench setting fixed at 46 ± 4 Nm. G¹⁄ drain port thread depth 12 mm. 28 www.jbj.co.uk/gear-motors.html #DriveLineHarmony GHM2BK7-R-22-E1 16,0 22,8 260 250 275 4000 45 107,5 20 GHM2BK7-R-20-E1 14,1 20,1 260 250 275 4000 45 104,5 20 GHM2BK7-R-40-E1 28,2 40,1 200 190 215 2600 61,3 126,5 20 GHM2BK7-R-25-E1 17,9 25,5 260 250 275 4000 53,5 110,5 20 GHM2BK7-R-37-E1 25,5 36,4 210 200 225 2600 59,3 122,5 20 GHM2BK7-R-34-E1 23,7 33,7 230 220 245 3000 52,5 119,5 20 GHM2BK7-R-30-E1 21,1 30,1 230 220 245 3400 45 115,5 20 GHM2BK7-R-10-E1 7 10 280 270 295 4000 44,8 93,5 15 Type Displacement Flow at Maximum Pressure Maximum Dimensions 1500 rev/min P P P Speed L M D I C P 3 cm /rev litres/mim bar bar bar rpm mm mm mm GHM2BK7-R-6-E1 4,5 6,4 280 270 295 4000 37,3 89,5 15 GHM2BK7-R-9-E1 6,4 9,1 280 270 295 4000 38,5 92,5 15 GHM2BK7-R-12-E1 8,3 11,8 280 270 295 4000 45,8 95,5 15 GHM2BK7-R-13-E1 9,6 13,7 280 270 295 4000 40,6 97,5 20 GHM2BK7-R-16-E1 11,5 16,4 280 270 295 4000 45 100,5 20
T0 C0 S0 A C1 S1 C2 S2 A3 C3 S5 Max Torque 200 Nm Max Torque 135 Nm Max Torque 140 Nm Max Torque 185 Nm Max Torque 160 Nm Max Torque 200 Nm Max Torque 140 Nm Max Torque 140 Nm Max Torque 140 Nm Flanges Shafts Gear Motors Flanges & Shafts GHM2 Series 29 www.jbj.co.uk/gear-motors.html #DriveLineHarmony www.jbj.co.uk/hydraulicadaptors.html jbj's in-house design team and manufacturing facility provide tailored solutions for your applications at competitive prices with quick delivery. The package consists of a bellhousing and flexible drive coupling that are fully machined to suit the pump and any driving interface; diesel or petrol engine, electric or hydraulic motor. A r a n g e o f c o m p o s i t e bellhousings to accommodate electric motor flanges from 300 mm d i ame t e r t o 800 mm diameter. See pages 40 to 44 of the Pump Drive Components t e c h n i c a l s p e c i fi c a t i o n catalogue. A collection of different ways of connecting hydraulic pumps and motors to various driver devices. Allow close coupling of hydraulic pumps directly to the flywheel / flywheel housing of diesel engines, electric and hydraulic motors.
Flanges Shafts Gear Motors Flanges & Shafts GHM2 Series 30 www.jbj.co.uk/gear-motors.html #DriveLineHarmony T1 S3 BK1 BK2 T2 S4 BK4 T2 S4 BK7 G0 Max Torque 180 Nm Max Torque 140 Nm Max Torque 180 Nm Max Torque 140 Nm Max Torque 180 Nm Max Torque 140 Nm Max Torque 100 Nm www.jbj.co.uk/hydraulicadaptors.html jbj's in-house design team and manufacturing facility provide tailored solutions for your applications at competitive prices with quick delivery. The package consists of a bellhousing and flexible drive coupling that are fully machined to suit the pump and any driving interface; diesel or petrol engine, electric or hydraulic motor. A r a n g e o f c o m p o s i t e bellhousings to accommodate electric motor flanges from 300 mm d i ame t e r t o 800 mm diameter. See pages 40 to 44 of the Pump Drive Components t e c h n i c a l s p e c i fi c a t i o n catalogue. A collection of different ways of connecting hydraulic pumps and motors to various driver devices. Allow close coupling of hydraulic pumps directly to the flywheel / flywheel housing of diesel engines, electric and hydraulic motors.
E EP FG FC GHM2...6 to GHM2…9 30 13 M6 30 13 M6 GHM2…10 to GHM2…13 40 13 M8 40 13 M8 GHM2…16 to GHM2…25 40 19 M8 40 13 M8 GHM2…30 to GHM2…40 40 19 M8 40 19 M8 GHM2...6 40 13 M8 30 13 M6 GHM2...10 to GHM2…13 30 13 M6 30 13 M6 GHM2…16 to GHM2…40 40 19 M8 30 13 M6 GHM2...6 to GHM2…16 G¹⁄ G¹⁄ GHM2…20 to GHM2…40 G³⁄ G¹⁄ GHM2...6 to GHM2…16 Rc¹⁄ Rc¹⁄ GHM2…20 to GHM2…40 Rc³⁄ Rc¹⁄ Bi-directional Motor Mono-directional motor Output -Input Input Type A B C A B C Bi-directional Motor Mono-directional motor Output -Input Type A B C A B C Input Bi-directional Motor Mono-directional motor Output -Input Type A A Input Bi-directional Motor Mono-directional motor Output -Input Type A A Input Tightening torques of the fittings screws are specified on page 52 (accessories section). Tightening torques for G1/2 fitting: 50 Nm. Tightening torques for G3/4 fitting: 60 Nm. Please check with the fittings suppliers. Tightening torques of the fittings screws are specified on page 52 (accessories section). Tightening torques for Rc1/2 fitting: 50 Nm. Tightening torques for Rc3/4 fitting: 60 Nm. Please check with the fittings suppliers. Ports Gear Motors Ports GHM2 Series 31 www.jbj.co.uk/gear-motors.html #DriveLineHarmony
KA FA D A GHM2...6 to GHM2…40 1¹⁄ -12 UNF ⁷⁄ -14 UNF GHM2…6 to GHM2…12 40 15 M6 35 15 M6 GHM2…13 to GHM2…40 40 20 M6 35 15 M6 GHM2...6 to GHM2…22 17.48 38.1 ⁵⁄ -18 UNC 13 17.48 38.1 ⁵⁄ -18 UNC 13 GHM2…25 22.23 47.63 ³⁄ -16 UNC 19 17.48 38.1 ⁵⁄ -18 UNC 13 GHM2…30 to GHM2…40 22.23 47.63 ³⁄ -16 UNC 19 22.23 47.63 ³⁄ -16 UNC 19 Ports Gear Motors Ports GHM2 Series 32 www.jbj.co.uk/gear-motors.html #DriveLineHarmony Bi-directional Motor Mono-directional motor Output -Input Input Type A B C A B C Bi-directional Motor Mono-directional motor Output -Input Input Type A A Bi-directional Motor Mono-directional motor Output -Input Input Type A B C D A B C D KA Option Outlet and Inlet Ports are located in the cover. FG and FA versions are available (for details about dimensions, please refer to the specific tables). Tightening torques for 7/8-14 UNF fitting: 70 Nm. Tightening torques for 1 1/16-12 UNF fitting: 70 Nm. Please check with the fittings suppliers Tightening torques of the fittings screws are specified on page 52 (accessories section). Tightening torques of the fittings screws are specified on page 52 (accessories section).
20 22 25 25-270 bar 30 34 25-240 bar 6 9 10 12 13 16 25-290 bar 40 25-210 bar 37 25-230 bar 33 www.jbj.co.uk/gear-motors.html #DriveLineHarmony Gear Motors Performance Curves GHM2 Series Delivered flow Q (litres/min) Drive speed n (rpm) Each curve has been obtained at 50°C, using oil with viscosity 30 cSt at these pressure.
34 www.jbj.co.uk/gear-motors.html #DriveLineHarmony Gear Motors Performance Curves GHM2 Series Delivered power P [kW]. Delivered torque M [Nm]. Drive speed n [giri/min] [rpm]
35 www.jbj.co.uk/gear-motors.html #DriveLineHarmony Gear Motors Performance Curves GHM2 Series Delivered power P [kW]. Delivered torque M [Nm]. Drive speed n [giri/min] [rpm]
36 www.jbj.co.uk/gear-motors.html #DriveLineHarmony Gear Motors Performance Curves GHM2 Series Delivered power P [kW]. Delivered torque M [Nm]. Drive speed n [giri/min] [rpm]
37 www.jbj.co.uk/gear-motors.html #DriveLineHarmony Gear Motors Performance Curves GHM2 Series Delivered power P [kW]. Delivered torque M [Nm]. Drive speed n [giri/min] [rpm]
... 33 40 50 60 66 80 94 110 120 135 D Type Rotation Size Ports* Seals* Options* omit A A2 BK1 5 Clockwise S Counter Clockwise GHM3 Drain** R Reversible omit = European flange + shaft T0 + ports E + standard seals A2 = flangeA2 + shaft C1+ portsA+ standard seals Motor Standard Types A= flangeA+ shaft C1 + portsA+ standard seals Examples GHM3A-R-40-E1 = reversiblemotor, 26 cc/rev, SAEB 2 bolt flange, cylindrical shaft, European flanged portsA, standard seals, external drain (E1). 5 = flange 5 + shaft T2 + ports E + standard seals GHM3A-D-30-E = clockwise rotation, 20 cc/rev, SAEB 2 bolt flange, cylindrical shaft, European flanged ports (E), standard seals. The product data sheets show our standard model types. The synoptic tables for flanges, shafts and ports show all the possible configurations. For further details about the availability of each configuration please contact jbj Techniques technical office, email: info@jbj.co.uk or telephone: +44 (0)1737 767493 GHM3-D-30-C0 = clockwise rotation, 20 cc/rev, European flange, cylindrical shaft (C0), flanged ports E type, standard seals. BK1 = flange BK1 + shaft T1 + ports D + standard seals GHM3-D-30 = clockwise rotation, 20 cc/rev, European flange,1:8 tapered shaft, flanged ports E type, standard seals. Gear Motors GHM3 Series Ordering Code Shaft* E3 = drain G1/4 ... E1 = external drain G3/8 ... (**) = only for R rotation Seals omit (T range = -10°C + 80°C) (*) = to be specified if different from standard “motor type” Options Drain E2 = drain 3/4-16 UNF *** E4 = drain 9/16-18 UNF *** (***) = Drain ports are machined in compliance with threaded port with O-ring seal in truncated housing SAE J1926/1 (ISO 11926-1). V E0 = internal drain 38 www.jbj.co.uk/gear-motors.html #DriveLineHarmony
