Fluid Power Accessories Pressure switch KT 35 Description The pressure switch type KT 35 is a pressure controlled electric switch, consisting of a piston activated microswitch with silver contacts. The pressure is field adjustable within the pressure range. Operation KT 35 switching when pressure rises/falls. To adjust pressure setting, untighten locking screw and twist upper part to desired pressure and then tighten the locking screw. Features • High pressure range • Withstands high pressure water spraying • High reliability • Tested to over 1 x 10 6 pressure cycles • High bursting pressure • Built in microswitch with silver contacts • Piston type Optional electrical connection For other combinations, electrical connections or special requirements, please contact jbj Techniques Limited technical office, tel: 01737 767493 or email: info@jbj.co.uk Ordering Code 1 2 3G / 8” thread: 30325 - 00 - XXX 1 = Type 00 = 25 - 150 bar 2 = Pressure set at XXX bar 1G / 4” thread: 30356 - 02 - XXX 01 = 100 - 350 bar 02 = 10 - 35 bar Symbols 58 #DriveLineHarmony www.jbj.co.uk/accessories.html
