Concentric AB-FERRA F12 SERIES-2011-06 6 MULTIPLE PUMP DIMENSIONS (Interframe) FT12A1/WP09A1 FT12A1 SECTION 1 Size Code Displacement A B with SAE “B” Flange ‘05’ with SAE “A” Flange ‘03’ # cc/rev c.i.r. mm [in] mm [in] kg [lb] kg [lb] 160 16 0.976 99.0 [3.9] 68.3 [2.7] 6.5 [14.3] 5.9 [13.0] 190 19 1.159 102.8 [4.0] 70.2 [2.8] 6.6 [14.6] 6.0 [13.2] 230 23 1.404 107.9 [4.2] 72.7 [2.9] 6.8 [15.0] 6.2 [13.7] 270 27 1.648 113.0 [4.4] 75.3 [3.0] 7.0 [15.4] 6.4 [14.1] 300 30 1.831 116.9 [4.6] 77.2 [3.0] 7.2 [15.9] 6.6 [14.6] 330 33 2.014 120.7 [4.8] 79.1 [3.1] 7.3 [16.1] 6.7 [14.8] 350 35 2.136 123.3 [4.9] 80.4 [3.2] 7.4 [16.3] 6.8 [15.0] 410 41 2.502 130.9 [5.2] 84.2 [3.3] 7.7 [17.0] 7.1 [15.7] WP09A1 SECTION 2 Size Code Displacement C D # cc/rev c.i.r. mm [in] mm [in] kg [lb] 005 5 0.305 74.6 [2.9] 24.8 [1.0] 2.0 [4.4] 008 8 0.488 79.1 [3.1] 27.1 [1.1] 2.1 [4.6] 011 11 0.674 83.5 [3.3] 29.3 [1.2] 2.2 [4.9] 016 16 0.976 90.9 [3.6] 33.0 [1.3] 2.4 [5.3] 019 19 1.159 95.4 [3.8] 35.2 [1.4] 2.6 [5.7] 023 23 1.404 101.3 [4.0] 38.2 [1.5] 2.7 [6.0] 027 27 1.648 107.2 [4.2] 41.1 [1.6] 2.9 [6.4] 030 30 1.831 111.7 [4.4] 43.4 [1.7] 3.0 [6.6] 133 [5.24] CW ROTATION OUTLET INLET 146 [5.75] 2X 14.3 [.56] 14.7 [.58] 177 [6.97] A B 101.55 [3.99] D 101.60 [4.00] C 21.68 [.85] 21.80 [.86] 20.5 [.81] 21.0 [.83] 40.7 [1.60] 41.7 [1.64] 90.8 [3.57] 107 [4.21] 70.8 [2.79] All dimensions are mm [in]. quality products for mechanical & fluid power ~ jbj Techniques Limited, www.jbj.co.uk UK distributor for Concentric Hydraulics
