B1 & B2 Series VANE PUMPS 01 13
Versatility, power, compactness and low running costs Versatility, power, compactness and low running costs are the main characteristics of this range of vane pumps. All the components subject to wear are contained in a cartridge unit that can be easily removed for inspection and/or replacement without disconnecting the pump from the circuit, drastically reducing expensive machine down time. All the components subject to wear are contained in a cartridge unit that can be easily removed for inspection and/or replacement without disconnecting the pump from the circuit, drastically reducing expensive machine down time. The cartridge contains a rotor, vanes and inserts, a cam ring and two covers. During operation the rotor is driven by a splined shaft coupled to the drive unit. As the rotation speed increases, centrifugal forces, in combination with the pressure generated behind the vanes, push the vanes outwards, where they follow the profile of the cam of the ring with a sufficient contact pressure to ensure adequate hydraulic sealing. The two opposed pumping chambers formed by the elliptical profile of the cam cancel out radial loads on the shaft bearings, thereby giving them extremely long lifetimes. The versatility of this series of pumps enables them to meet the requirements of the most varied industrial applications. In fact, as well as their proven high reliability and excellent volumetric efficiency in all working conditions, they operate with particularly low noise levels. This is made possible by the special profile of the cam ring and the use of a 12 vane rotor that reduces the amplitude of the supply pressure pulses, thereby reducing induced vibrations. These vane pumps are extremely compact and are supplied with ISO norm mechanical couplings and SAE norm hydraulic fittings. This makes them very easy to install and guarantees their interchangeability with other similar pumps (eg. Vickers, Caterpillar, Denison). More detailed technical information is available from jbj Techniques Limited. jbj Techniques technical office, telephone: 01737 767493 email: info@jbj.co.uk www.jbj.co.uk/vanepumps.html ii www.jbj.co.uk/vane-pumps.html #DriveLineHarmony
Hydraulic Vane Pumps Hydraulic Vane Pumps B1 & B2 Series iii www.jbj.co.uk/vane-pumps.html #DriveLineHarmony The details contained within this catalogue are reproduced in accordance with the latest information at publication of this catalogue. Errors & Omissions Excepted Last update: 30/01/2013 page Fixed displacement hydraulic vane pumps “B1/B2” series . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 B1 Single pump technical characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 B1 Single pump installation dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 B2 Single pump technical characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 B2 Single pump installation dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Operating instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
BD SERIES Fixed displacement high pressure hydraulic vane pumps. » three versions of single pump (from 10 to 227 l/min at 1000 rpm) » four versions of double pump (from 20 to 385 l/min at 1000 rpm) with input powers of over 328 kW at max pressure and speed. HD SERIES Fixed displacement high pressure hydraulic vane pumps. » single pump (from 11 to 99 l/min at 1000 rpm) » double pump (from 22 to 200 l/min at 1000 rpm) With maximum powers of over 126 kW at the max pressure and speed. BV SERIES Fixed displacement hydraulic vane pumps. » four versions of single pump (from 8 to 230 l/min at 1200 rpm) » six versions of double pump (from 55 to 370 l/min at 1200 rpm) With maximum powers of over 223 kW. BQ SERIES Fixed displacement hydraulic vane pumps. » five versions of single pump (from 8 to 230 l/min at 1200 rpm) » seven versions of double pump (from 55 to 370 l/min at 1200 rpm) With maximum powers of over 223 kW. TQ / TV SERIES Through-drive hydraulic vane pumps. Fixed displacement vane pump, hydraulically balanced, with capacity determined by the type of cartridge used and the speed of rotation. The pump is available in five different displacements from 47 to 79 l/min at 1200 rpm and 7 bar. HQ SERIES Fixed displacement hydraulic vane pumps. » 2 versions of single pump (from 39 to 88 l/min at 1000 rpm) and » 2 versions of double pump (from 46 to 134 l/min at 1000 rpm) with Maximum powers of over 103 kW. B1 / B2 SERIES Fixed displacement hydraulic vane pumps. B1 pumps are available in eight different versions (from 4.5 to 31.8 l/pm at 1200 rpm), with maximum power of up to 18 kW. B2 pumps are available in seven different versions (from 27.27 to 59.09 l/pm at 1200 rpm), with maximum power of up to 27 kW. Hydraulic Vane Pumps High Pressure Hydraulic Vane Pump Types iv www.jbj.co.uk/vane-pumps.html #DriveLineHarmony
FIXED DISPLACEMENT HYDRAULIC VANE PUMPS “B1/B2” SERIES Versatility, reliability, high long-term volumetric efficiency and low noise level are the hallmark of the B1 and B2 series of vane pumps. B1 and B2 pumps combine these qualities, with low running costs to offer a valid alternative to other types of pump for both industrial and mobile use, particularly where noise level must be kept low. B1 pumps are available in eight different versions (from 1 to 7 gpm at 1200 rpm), with maximum power of up to 18 kW; B2 pumps are available in seven different versions (from 6 to 13 gpm at 1200 rpm), with maximum power of up to 27 kW. Both are supplied with different mechanical and hydraulic connections, for extremely simple installation and complete interchangeability with other types of pump. B1/B2 1
B1 single pump Fixed displacement vane pump, hydraulically balanced, with capacity determined by the type of ring used and the speed of rotation. The pump is available in eight different displacements, from 3.29 cc to 22.8 cc. General description Hydraulic fluids: mineral oils, phosphate ester based fluids, water emulsions in oil, water-glycol fluids. Viscosity range (with mineral oil) : from 13 to 860 cSt. (13 to 54 cSt. recommended) . Filtration: for the inlet - 149 micron abs., for the return line - 25 micron abs. or better (with synthetic fluids: for the return line - 10 micron abs. or better) . Inlet pressure (with mineral oil) : from -0,17 to +0,35 bar (-2.5 + 5 psi) , (with synthetic fluids and water-in-oil emulsion) : from -0,10 to +0,35 bar (-1.5 + 5 psi) Operating temperature: with mineral oil -10°C to +70°C (+30°C to +60°C recommended),with water based fluids +15°C to +50°C. Drive: direct and coaxial by means of a flexible coupling. Use limits with special fluids Maximum pressure Speed range (rpm) Pump syntetic fluid water-glycol water-in-oil syntetic fluid, water-glycol type emulsion water-in-oil emulsion All 140 (2000) 126 (1800) 105 (1500) 650 1800 bar (psi) bar (psi) bar (psi) min max B1G10 3,29 (0.20) 3,21 (0.85) 3,78 (1) 4,70 (1.25) 175 (2500) 650 4800 B1G15 5,50 (0.33) 5,42 (1.43) 6,32 (1.70) 7,86 (2.10) 175 (2500) 650 4800 B1G20 6,53 (0.40) 6,45 (1.70) 7,57 (2) 9,40 (2.50) 175 (2500) 650 4500 B1G30 9,82 (0.60) 9,72 (2.57) 11,35 (3) 14,20 (3.75) 175 (2500) 650 4000 B1G40 13,10 (0.80) 12,91 (3.41) 15,14 (4) 18,90 (5.00) 175 (2500) 650 3400 B1G50 16,39 (1.00) 16,25 (4.29) 18,92 (5) 23,60 (6.25) 175 (2500) 650 3200 B1G60 19,50 (1.19) 19,44 (5.14) 22,71 (6) 28,40 (7.50) 150 (2200) 650 3000 B1G70 22,80 (1.39) 22,36 (5.91) 26,49 (7) 33,10 (8.75) 140 (2000) 650 2800 cm3/g (in3/r) l/min (gpm) l/min (gpm) l/min (gpm) bar (psi) min max Pump Geometric Rated capacity at 7 bar Max pressure Speed range type displacement 1000 rpm 1200 rpm 1500 rpm with mineral oil with min. oil (rpm) Technical characteristics oil viscosity: 25 c.St. (10W), temperature: 45°C, inlet pressure: 0 BAR 2
B1 single pump Model code breakdown B1 G ** * * * * (L) Inlet port connection B= 1" GAS threaded P= 1" NPT threaded S= SAE 1-5/16" 12 UNF-2B threaded Nominal size 10 15 20 30 40 50 60 70 Outlet port connection B= 1/2" GAS threaded P= 1/2" NPT threaded S= SAE 3/4" 16 UNF-2B threaded Rotation (viewed from shaft end) L= left hand rotation (omit if right hand rot.) Shaft end options 01= Straight with square key (standard) 03= Threaded with woodruff key 11= Splined "SAE A" 9 teeth 16/32 Outlet port positions (Outlet viewed from cover end) A= Outlet opposite inlet, B= Outlet 90° CCW from inlet, C= Outlet in line with inlet, D= 90° Outlet CW from inlet (see table) PORT ORIENTATIONS Installation dimensionsmm Pump length Pump type A B B1G10 116 67.4 B1G15 116 67.4 B1G20 116 67.4 B1G30 116 67.4 B1G40 120 73.7 B1G50 120 73.7 B1G60 127 78.8 B1G70 127 78.8 Approx. weight: 4,5-6,8 kg. (10-15 lbs.) 3
B2 single pump Fixed displacement vane pump, hydraulicaly balanced, with capacity determined by the type of ring used and the speed of rotation. The pump is avai lable in seven di fferent displacements, from 19.5 cc to 42.4 cc. General description Hydraulic fluids: mineral oils, phosphate ester based fluids, water emulsions in oil, water-glycol fluids. Viscosity range (with mineral oil) : from 13 to 860 cSt. (13 to 54 cSt. recommended) . Filtration: for the inlet - 149 micron abs., for the return line - 25 micron abs. or better (with synthetic fluids: for the return line - 10 micron abs. or better) . Inlet pressure (with mineral oil) : from -0,17 to +0,35 bar (-2.5 + 5 psi) , (with synthetic fluids and water-in-oil emulsion) : from -0,10 to +0,35 bar (-1.5 + 5 psi) Operating temperature: with mineral oil -10°C to +70°C (+30°C to +60°C recommended),with water based fluids +15°C to +50°C. Drive: direct and coaxial by means of a flexible coupling. Use limits with special fluids Maximum pressure Speed range (rpm) Pump syntetic fluid water-glycol water-in-oil syntetic fluid, water-glycol type emulsion water-in-oil emulsion B2G6-G8 140 (2000) 125 (1800) 110 (1500) 600 1800 B2G9 140 (2000) 110 (1500) 95 (1350) 600 1500 B2G11-G13 125 (1800) 110 (1500) 95 (1350) 600 1500 bar (psi) bar (psi) bar (psi) min max Technical characteristics oil viscosity: 25 c.St. (10W), temperature: 45°C, inlet pressure: 0 BAR cm3/g (in3/r) l/min (gpm) l/min (gpm) l/min (gpm) bar (psi) min max Pump Geometric Rated capacity at 7 bar Max pressure Speed range type displacement 1000 rpm 1200 rpm 1500 rpm with mineral oil with min. oil (rpm) B2G06 19,50 (1.19) 18,90 (5.00) 22,71 (6) 28,39 (7.50) 175 (2500) 450 3000 B2G07 22,78 (1.39) 22,15 (5.85) 26,49 (7) 33,11 (8.75) 175 (2500) 450 3000 B2G08 26,55 (1.62) 27,70 (7.32) 30,28 (8) 37,85 (10.00) 175 (2500) 450 3000 B2G09 29,66 (1.81) 28,61 (7.55) 34,06 (9) 42,57 (11.25) 175 (2500) 450 2800 B2G11 36,38 (2.22) 35,35 (9.34) 41,63 (11) 52,04 (13.75) 175 (2500) 450 2800 B2G12 39,00 (2.38) 37,92 (10.02) 45,42 (12) 56,77 (15.00) 150 (2200) 450 2500 B2G13 42,44 (2.59) 41,32 (10.92) 49,20 (13) 61,50 (16.25) 140 (2000) 450 2500 4
B2 single pump Pump length Pump type A B B2G06 125 72 B2G07 132 78 B2G08 132 78 B2G09 132 78 B2G11 137 83 B2G12 140 87 B2G13 140 87 Approx. weight: 7,3-8,2 kg. (16-18 lbs.) PORT ORIENTATIONS Installation dimensionsmm Model code breakdown B2 G ** * * * * (L) Inlet port connection B= 1-1/4" GAS threaded P= 1-1/4" NPT threaded S= SAE 1-5/8" 12 UNF-2B threaded Nominal size 06 07 08 09 11 12 13 Outlet port connection B= 3/4" GAS threaded P= 3/4" NPT threaded S= SAE 1-1/16" 12 UNF-2B threaded Rotation (viewed from shaft end) L= left hand rotation (omit if right hand rot.) Shaft end options 01= Straight with square key (standard) 03= Threaded with woodruff key 11= Splined "SAE A" 11 teeth 16/32 (see table) Outlet port positions (Outlet viewed from cover end) A= Outlet opposite inlet, B= Outlet 90° CCW from inlet, C= Outlet in line with inlet, D= 90° Outlet CW from inlet 5
Maximum speed: the maximum speeds given in this catalogue are valid for an atmospheric pressure of 1 bar (14.7 psi) and with ambient temperature in the range of +30°C to +50°C. Higher speeds than those given cause a reduction in the volumetric efficiency, due to cavitation phenomena in the inlet area inside the pump. Sustained excess speed causes a rapid deterioration of the internal components reducing the lifetime of the pump. Minimum speed: Refer to the technical characteristics table of the pump. However, it is possible to operate at lower speeds with certain pump configurations and with appropriate operating temperatures. Inlet pressure: the inlet pressure, measured at the inlet port, should remain within the prescribed limits. Note that pressures lower than minimum limit cause cavitation and pressures above the maximum limit cause abnormal loads on the shaft and the bearings. In both cases this causes a significant reduction in the lifetime of the cartridge. Maximum outlet pressure: the maximum outlet pressure is different for each type of fluid used as can be seen from the corresponding table. With optimal temperature and filtration conditions a pressure peak of +10% is permissible for a maximum time of 0.5 sec. Mounting and drive connections: consider the following indications when preparing the installation drawings for the system: • the pump is designed to operate with keyed shaft coupled axially and by means of a flexible coupling to the drive; • the clearance between the keyed shaft and the corresponding sleeve coupling has to be between 0.004 and 0.030 mm; • avoid axial and radial loads on the shaft; • the mounting flange has to be perpendicular to the drive shaft, with a maximum error of 0.18 mm every 100 mm; • when mounting onto a gearbox, or other component without a flexible coupling, it is advisable to order pumps with splined shaft. In this case the clearance between splines has to be between 0.013 and 0.051 mm on the pitch diameter. Hydraulic circuit: always install a pressure relief valve on the supply line to prevent the pressure from exceeding the allowed maximum. Normally, it is set in accordance with the weakest component in the system. (In the case where it is the pump, set the valve to a pressure 15% higher than the maximum pressure rating of the pump.) Inlet line tubing should have a section equal to or greater than that of the inlet port of the pump. It is advisable to keep the tube connecting the pump to the reservoir as short possible. Particular care has to be taken with the inlet line which has to be hermetically sealed to avoid entraining air into the circuit; this varies the characteristics of the hydraulic fluid causing the operating parts to become damaged. Filtration: the inlet line filter must have a flow rate capacity that is higher than that of the pump at its maximum operating speed. The filtration requirements for individual models are given in this catalogue. The use of a filter bypass is recommended for cold starts and should the filter become clogged. Proper maintenance of the filter element is essential for the correct operation of the entire system. In normal conditions replace the filter element after the first 50 hours of operation. Subsequently, replace it at least every 500 hours. Regarding the filter on the return line, the same general conditions apply as for the inlet line and it should be positioned in an accessible location for ease of maintenance. Tank: if possible, the reservoir should be positioned above the pump. Otherwise, ensure that the minimum level of the fluid contained in it is higher than the pump inlet line opening. It is important to avoid draining the inlet line with the pump at standstill. The opening of the return line into the reservoir must remain below the minimum level of the fluid in the reservoir. It must not be positioned too close to the opening of the inlet line to avoid the possibility of any air bubbles passing into the inlet line. Baffles inside the reservoir may be useful in avoiding the problem. Rapid temperature changes can cause condensation on the underside of the lid of the reservoir with the formation of droplets of water that can fall into the oil. To avoid this problem it is recommended that the lid should have small vents so that the air space in the reservoir is ventilated. The vents have to be screened, though, to prevent the entry of dust or the sudden expulsion of fluid. Start-up: use the following procedure when the pump is started-up for the first time: completely fill the pump and the inlet line with fluid; start the engine for approximately one second a number of times at regular intervals of approximately 2 or 3 seconds until the noise level reduces, thereby confirming that it has been primed; with a manometer check to ensure that the outlet pressure increases slightly; once the pump has been primed, maintain low pressure levels activating all parts of the circuit a number of times until air bubbles disappear completely from the return line to the reservoir. This procedure should be carefully as any residual air inside the pump can quickly cause the rotor to seize. Cold starting: when starting the pump, especially with low ambient temperatures, operate with moderate speed and pressure until the average temperature in the entire circuit is within the given limits. The information provided in this catalogue is subject to change without notice Operating instructions B1/B2 © 2008 B& C 6
Notes ....................................................................................................................................................................................................................................................................................................................................................................... ....................................................................................................................................................................................................................................................................................................................................................................... ....................................................................................................................................................................................................................................................................................................................................................................... ....................................................................................................................................................................................................................................................................................................................................................................... ....................................................................................................................................................................................................................................................................................................................................................................... ....................................................................................................................................................................................................................................................................................................................................................................... ....................................................................................................................................................................................................................................................................................................................................................................... ....................................................................................................................................................................................................................................................................................................................................................................... ....................................................................................................................................................................................................................................................................................................................................................................... ....................................................................................................................................................................................................................................................................................................................................................................... ....................................................................................................................................................................................................................................................................................................................................................................... ....................................................................................................................................................................................................................................................................................................................................................................... ....................................................................................................................................................................................................................................................................................................................................................................... ....................................................................................................................................................................................................................................................................................................................................................................... ....................................................................................................................................................................................................................................................................................................................................................................... ....................................................................................................................................................................................................................................................................................................................................................................... ....................................................................................................................................................................................................................................................................................................................................................................... ....................................................................................................................................................................................................................................................................................................................................................................... ....................................................................................................................................................................................................................................................................................................................................................................... ....................................................................................................................................................................................................................................................................................................................................................................... ....................................................................................................................................................................................................................................................................................................................................................................... ....................................................................................................................................................................................................................................................................................................................................................................... ....................................................................................................................................................................................................................................................................................................................................................................... ....................................................................................................................................................................................................................................................................................................................................................................... ....................................................................................................................................................................................................................................................................................................................................................................... ....................................................................................................................................................................................................................................................................................................................................................................... ....................................................................................................................................................................................................................................................................................................................................................................... ....................................................................................................................................................................................................................................................................................................................................................................... ....................................................................................................................................................................................................................................................................................................................................................................... ....................................................................................................................................................................................................................................................................................................................................................................... ....................................................................................................................................................................................................................................................................................................................................................................... ....................................................................................................................................................................................................................................................................................................................................................................... ....................................................................................................................................................................................................................................................................................................................................................................... ....................................................................................................................................................................................................................................................................................................................................................................... ....................................................................................................................................................................................................................................................................................................................................................................... ....................................................................................................................................................................................................................................................................................................................................................................... ....................................................................................................................................................................................................................................................................................................................................................................... ....................................................................................................................................................................................................................................................................................................................................................................... ....................................................................................................................................................................................................................................................................................................................................................................... ....................................................................................................................................................................................................................................................................................................................................................................... ....................................................................................................................................................................................................................................................................................................................................................................... ....................................................................................................................................................................................................................................................................................................................................................................... ....................................................................................................................................................................................................................................................................................................................................................................... ....................................................................................................................................................................................................................................................................................................................................................................... .......................................................................................................................................................................................................................................................................................................................................................................
Getting the most out of your machinery often depends on close integration between all components. An organisation that manufactures and integrates all the diverse components of a drivetrain provides the experience to help you select the best component combination for your application. jbj Techniques’ in-house design team and manufacturing facility provide tailored solutions for your applications at competitive prices with quick delivery. The following examples are a simplistic view of how jbj Techniques assists customers. Hydraulic Adaptors Designed primarily to allow the close coupling of hydraulic pumps to a variety of prime movers, such as diesel / petrol engines, electric, air or hydraulic motors, they can also be used in the connection from prime mover to alternative driven parts i.e. gear boxes, generators, water or vacuum pumps etc. An additional range of engine front PTO adaptors, which provide additional connection between the engine pulley and the driven part are also available. The kit comprises of a and flexible bellhousing drive that are fully machined to suit the coupling driving and driven components. These can be to suit either shaft to shaft, flange (flywheel) to shaft or even flange to flange connections. Getting the most out of your equipment will demand close integration between all components. In specifying jbj Techniques as your preferred supplier, you will have selected a company with the experience to specify, manufacture and integrate all of the diverse components that will ensure the best component combination for your application. jbj's in house design team and manufacturing facility provide tailored solutions for your applications at competitive pricing and on-time deliveries. Pump shaft alignment is key to preventing unnecessary wear and damage to the pump shaft seal and bearing. Improper alignment may lead to premature pump failure. Also to be considered are unwanted torsional resonant frequencies in the system which can quickly cause damage to components in the drivetrain and reduce system life and performance. Improper pump installation can lead to premature failure, increased maintenance costs and reduced production levels of final product. jbj Techniques can advise on the correct installation of into Industrial / hydraulic pumps mobile / marine / machine tool / agricultural / offshore industries and can specify complete driveline systems from their extensive range of components which are available from stock or manufactured to order, albeit simple or complex, standard or bespoke. Electric Motor – Hydraulic Pump Adaptors (safe area) jbj Techniques Limited offer the most comprehensive range of in Europe. bellhousings Designed to connect electric motors with frame size IEC D56 - D400 (0.06kW – 750kW) and can be compatible with electric motor 'B5' or 'B14' flange configurations. Accompanying the metric frame units above is a complete range of mountings to suit Nema and imperial frame motors with 'C' face or 'D' flange fitments. With fully machined , torsionally flexible couplings or available, jbj ensure torsionally rigid couplings the most suitable combination is selected for the application in hand. As an example spider couplings are available in various materials including aluminium, grey cast iron, nodular iron, steel and stainless steels and can be finish machined with parallel, taper or splined bores to DIN, SAE, ANSI or ISO standards. Bellhousings can be manufactured in aluminium or cast iron material as standard, however, units can be produced in a variety of exotic materials on request. The aluminium product range is produced in either monoblock or composite formats giving great flexibility in design and allows for early delivery time, often with same or next day delivery possibilities. For applications where low noise levels are a quality products for mechanical & fluid power #DriveLineHarmony www.jbj.co.uk an excellence in engineering
ensuring a continuing high quality service in which customers can have complete confidence. “ “ requirement then a complete range of antivibration and noise reduction components add to the range. Electric motor – Hydraulic Pump Adaptors (hazardous area) Designed to meet the exacting safety standards of the offshore and chemical process industries, jbj Techniques produce certificated to adaptor kits Directive 2014/34/EU II2GD-IM2-TX -50 C< Service Temp < +105 C. Harmonised standards BS EN 1127:1, BS EN 13463:1, BS EN13463:5, BS EN 50303, BS EN 1834-1,BS EN 1834-3. Generally manufactured in Cast or Nodular iron, bellhousings can be produced in steel, stainless steel or alternative exotic materials on customer request. Couplings supplied for these applications are the jbj Techniques 'JXL' pin and bush range which provide an anti-static and flameproof drive which meet zone 1 area requirements, conforming to all of the above standards. Also available are spider and gear couplings which are certified to zone 2 standards. (Contact jbj Techniques for details). An important development of equipment for use within hazardous areas is the wet mount series of bellhousings. Commissioned to research and develop a product that would control the high temperature generated by a piston pump shaft seal when working within cycling applications. A little considered issue is the frictional heat generated at the shaft seal when the application requires the pump to cycle between different pressures causing the seal temperature to increase. This process will often take the seal temperature out and above the levels required by the relevant ATEX standards requirement. This specially designed assembly allows a pumped cooling flow to be passed over the seal face and through an auxiliary cooler, this in turn reduces the seal face temperature which can be maintained at an acceptable level. With a vast array of components to select from, jbj are well placed to provide all required components to support the required cooling system. Diesel Engine – Hydraulic Pump Adaptors A complete range of bellhousing and couplings exist for the connection of a diesel engine flywheel to a specified driven component, be it an oil hydraulic pump, water pump, generator or similar device. With the bellhousing available in various materials to suit all application areas. With a standard range to connect Diesel engines with SAE dimensions from SAE '6' to SAE '0' jbj are well placed to satisfy the majority of customer requirements. Couplings to complete the assembly are available in either torsionally flexible or torsionally rigid design ad can be supplied to suit SAE flywheel dimensions from SAE 6.5” to SAE 18”. For hydraulic pumps to be mounted to engines that do not conform to SAE dimensions, we offer a full range of assembly parts, some of which (but not all) are shown here » for diesel engines All bellhousings within this range can be finished machined to accept any, piston, vane or gear pump interfaces requested by customer. As with the electric motor range of product jbj offer complete solutions for ATEX environments, using our well proven 'JXL' coupling range which has standard design to connect to the engine flywheel. Directive 2014/34/EU II2GD-IM2-TX -50°C ≤ Service Temp ≤ +105°C. Harmonised Standards: BS EN 1127:1 BS EN 13463:1 BS EN 13463:5 BS EN 50303. Petrol Engine – Hydraulic Pump Adaptors Petrol engine adaptors have been developed for use with industrial petrol engines. Design exists to suit Honda, Briggs and Stratton, Kawasaki, Kubota, Hatz, Mag, Robin, Suzuki, Winsconsin, to name but a few, all adaptors can be finished to accept most hydraulic pumps. Adaptors to suit engine crankshaft drives and for vertical mounting are available on request. #DriveLineHarmony www.jbj.co.ukl to Large Combinations Small Individual Components
