• Overall efficiencies up to 94%. • Stepless adjustable speed and torque. • IEC electric motor interfaces available. Efficient and cost saving • Low maintenance costs due to the robust design. • Energy recovery and energy storage. Performance • Using one central provider for various drive operations. • Motor internal leakage provides constant cooling of the rotating group. • Strong drive shaft capable of withstanding radial and axial loads.. • Wide speed range (3 – 5250 rpm ). • High starting torque (full torque is available across the whole speed range from zero high to max. speed). Further advantages of hydraulic drive concepts • Experienced sales and engineering department, actively involved in finding solutions for customer drive applications, be they hydraulic, pneumatic or mechanical. • Small quantity units always considered. • Involved in all hydraulic and pneumatic tasks, such as engineering hydraulic / pneumatic controls and hydraulic power units. Service from jbj Techniques Ltd and working partner Düsterloh Fluidtechnik GmbH AE21 21,3 64 76 3 2400 210 250 AE45 45,0 135 161 10 2000 210 250 AE4 4,0 12 14 5 3750 210 250 AE16 16,0 48 57 5 2500 210 250 Displacement Torque Speed Range Pressure Motor cont.* max.** min. max. cont. max. [ccm/rev] [Nm] [Nm] [rpm] [rpm] [bar] [bar] AE3 2,9 9 10 10 5250 210 250 AE5 5,1 16 19 3 3000 210 250 AE10 11,4 34 41 10 3000 210 250 AE32 31,5 95 113 5 2000 210 250 AE40 40,5 122 145 3 2000 210 250 AE22 22,5 68 81 10 2000 210 250 AE71 70,4 212 252 10 2250 210 250 AE140 141,1 425 505 5 1200 210 250 AE180 181,5 546 650 3 1000 210 250 AE125 126,7 381 454 3 1420 210 250 AE100 98,5 296 353 5 1725 210 250 cont.* max.** min. max. cont. max. [ccm/rev] [Nm] [Nm] [rpm] [rpm] [bar] [bar] AEHP40 43,7 132 158 1 2000 210 250 RMHP110 109,5 217 310 1 750 210 250 The high precision series of hydraulic motors with exceptional speed consistency, even at speed down to 1 rpm. RMHP90 88,4 174 252 1 900 210 250 Displacement Torque Speed Range Pressure Motor Axial Piston Motors AE3 - AE180 SERIES High-precision hydraulic motors 1 www.jbj.co.uk/hydraulic-motors.html #DriveLineHarmony
